Page 2 For the enthusiast user who wants to have insights, curiosities and detailed information about the characteristics and functions of the vehicle, Fiat gives the opportunity to consult a dedicated section which is available in electronic format. ONLINE VEHICLE OWNER HANDBOOK The following symbol ...
Page 3 Dear Customer, We would like to congratulate and thank you for choosing a Fiat 124 Spider. We have written this handbook to help you get to know all the features of your vehicle and use it in the best possible way.
Page 4 ELECTRICAL ACCESSORIES Contact a Fiat Dealership if you decide to add electrical accessories (with the risk of gradually draining the battery) after buying the vehicle. They can calculate the overall electrical requirement and check that the vehicle's electric system can support the required load.
Page 5: How To Use This Manual
HOW TO USE THIS MANUAL ESSENTIAL INFORMATION Each time directions are given in the instructions (left/right or forward/backwards), these must be intended as referred to the point of view of an occupant in the driver's seat. Special cases not complying with this rule will be properly specified in the text. The figures in the Owner Handbook are provided by way of example only: this might imply that some details of the image do not correspond to the actual arrangement of your vehicle.
Page 7 GETTING TO KNOW YOUR VEHICLE KNOWING THE INSTRUMENT PANEL SAFETY STARTING AND OPERATING IN CASE OF EMERGENCY MAINTENANCE AND CARE TECHNICAL SPECIFICATIONS MULTIMEDIA INDEX...
Page 9: Table Of Contents
GETTING TO KNOW YOUR VEHICLE In-depth knowledge of your new vehicle DASHBOARD ....8 starts here. KEYS .....9 IGNITION SWITCH .
Page 10: Dashboard
DASHBOARD 02010200-123-555 1 – Side adjustable vents; 2 – Exterior light control stalk; 3 – Instrument panel; 4 – Windscreen wiper washer stalk; 5 – Center adjustable air vents; 6 – Hazard warning lights button; 7 – Radio 3”/Radio 7” system (where provided); 8 – Passenger Air Bag; 9 –...
Page 11: Keys
KEYS IMPORTANT The driver must carry the Additional keys can be obtained at key to ensure the system functions Fiat Dealership. Up to 6 keys can be used with the keyless functions per properly. KEYS vehicle. Bring all keys to Fiat Dealership KEYLESS ENTRY SYSTEM when additional keys are required.
Page 12 Fiat Dealership, which will take care of their windows or other controls to operate, or Replace with a new battery disposal.
Page 13: Ignition Switch
IGNITION SWITCH Doing so could result in the battery going dead. If the ignition is left in ACC This is the normal running position after (for automatic transmission, the selector the engine is started. The indicator light PUSH BUTTON START lever is in the P position, and the (amber) turns off (the indicator light POSITIONS...
Page 14 (red) remains to ACC or ON. Contact a Fiat started using the following procedure: illuminated and the push button start Dealership as soon as possible.
Page 15 (as shown in fig. 5 ) however contact a Fiat Dealership as off the engine. The ignition position is while the push button start indicator soon as possible.
Page 16: Advanced Keyless Entry System
If the system is deactivated, you will be unable to start the engine by carrying the key. Contact a Fiat Dealership for details. If the advanced keyless entry system has been deactivated, you can start the engine by following the procedure indicated when the key battery goes dead.
Page 17: Vehicle Security Alarm
VEHICLE SECURITY continuously while you are driving, do do not shock or cause an impact to ALARM not shut off the engine. Contact a Fiat the intrusion sensor or the intrusion Dealership and have it checked. If the sensor bezel;...
Page 18: Doors
If you have any problems with the double locking system, contact a Fiat Dealership. System activation Proceed as follows: close both the windows and the convertible top;...
Page 19 close both doors and boot lid; interrupted (fuse blows or the battery is NOTE Confirm that both doors and the insert the auxiliary key in the driver's disconnected), the system can only be boot lid, fuel filler flap are securely door, turn the auxiliary key to the lock deactivated by unlocking a door with locked.
Page 20 The setting change is completed by three seconds when the advanced key Switching the ignition to any position doing any one of the following: is out of the operational range. other than off. – switching the ignition to ACC or Also, the hazard warning lights flash LOCKING / UNLOCKING once (even if the driver is in the...
Page 21: Seats
SEATS Seat recline 10) After closing the doors, always verify To change the seatback angle, lean that they are securely closed: doors not MANUAL ADJUSTMENT forward slightly while raising the lever 3. securely closed are dangerous, if the vehicle is driven with a door not securely Then lean back to the desired position 15) 16) 17) 18) 19) 20) 21) 22) 23) 24) 25) 26) 27) 28) 29) closed, the door could open unexpectedly...
Page 22 23) Do not place objects under the seat. supplementary restraint system and result 15) Make sure the adjustable components in serious injury. Consult a Fiat Dealership if The object could get stuck and cause the of a seat are locked in place. Adjustable...
Page 23: Head Restraints
HEAD RESTRAINTS 25) Make sure luggage and cargo is 30) Do not use the seat warmer with secured before driving. Not securing cargo anything having high moisture retention while driving is dangerous as it could move ability such as a blanket or cushion on the Non-Adjustable Head Restraints or be crushed during sudden braking or a seat.
Page 24: Steering Wheel
STEERING WHEEL MIRRORS WARNING STEERING WHEEL ADJUSTMENT OUTSIDE MIRRORS 34) Any adjustment of the steering wheel 34) 35) 36) position must be carried out only with the To change the angle of the steering vehicle stationary and the engine turned Driver's side wide angle mirror wheel: off.
Page 25 INSIDE DAY / NIGHT control by rotating the switch to the MIRROR center position 0 to prevent accidental movements. FOLDING MIRRORS Rearview mirror adjustment Before driving, adjust the rearview mirror fig. 14 to center on the view Fold the outside mirror rearward through the rear window.
Page 26: Exterior Lights
EXTERIOR LIGHTS IMPORTANT To prevent discharging the 39) Do not stack cargo or objects higher battery, do not leave the lights on while than the seatbacks: cargo stacked higher the engine is off unless safety requires than the seatbacks is dangerous. It can HEADLIGHTS block your view in the rearview mirror, them.
Page 27 and the ignition is switched ON as HIGH BEAMS FRONT FOG LIGHTS The headlights switch between high fingers could be pinched or the wipers The front fog light can be used when and wiper blades damaged when the and low beams by moving the lever the ignition is switched to ON.
Page 28 turn the headlight switch 1 to OFF turn on once the headlights, the exterior To turn the rear fog light on, rotate the position; lights and instrument panel illumination fog light switch 2 to the position (the switch the ignition to a position other are on.
Page 29 Manual type A system malfunction or operation If the indicator light continues to flash conditions are indicated by a warning. The headlight levelling switch is used to after a turn, manually return the lever to Refer to “Warning lights on instrument adjust the angle of the headlights its original position.
Page 30 Select the proper headlight angle from the following chart: Front seat Load Switch position Driver Passenger — — — —...
Page 31: Windscreen Wipers / Washer
WINDSCREEN Variable-speed intermittent wipers if the windshield above the rain WIPERS / WASHER sensor is touched or wiped with a cloth; Set the lever to the intermittent position if the windshield is struck with a hand and choose the interval timing by or other object from either outside or rotating the ring 1.
Page 32 With headlight washers normally. If they do not resume When the headlights are on, the WARNING functioning, contact a Fiat Dealership headlight washers operate as soon as possible. Drive to the side of automatically once every fifth time the the road and park off the right-of-way.
Page 33: Climate Control System
R1234yf (indicated on a specific plate in restored, even after the vehicle is restarted, the engine compartment). The use of other contact a Fiat Dealership. coolants affects the efficiency and condition 9) Do not operate the windscreen wiper of the system. Also the compressor with blades lifted from the windscreen.
Page 34 MANUAL CLIMATE CONTROL SYSTEM 06010300-122-099...
Page 35 CONTROL SWITCHES 1 – Temperature control dial. Turn it clockwise for hot and anticlockwise for cold. 2 – Fan control dial. The fan has seven speeds. 3 – Mode selector dial. Turn the mode selector dial to select air flow mode. The mode selector dial can be set at the intermediate positions (●) between each mode.
Page 36 AUTOMATIC CLIMATE CONTROL SYSTEM 06010900-122-990...
Page 37: Power Windows
CONTROL SWITCHES POWER WINDOWS 1 – Temperature control dial. 2 – Fan control dial. The fan has seven CONTROLS speeds. AUTO position: the amount of air flow will be automatically controlled 45) 46) in accordance with the set temperature. The ignition must be switched ON for Except AUTO position: the air flow the power windows to operate.
Page 38 procedure can be done on both door POWER WINDOW LOCK SWITCH switches. The power window auto WARNING This feature prevents the passenger's function will only resume on the power power window from operating. Keep window that has been reset: 45) Make sure the opening is clear before this switch in the locked position while close the doors and the convertible closing a window: closing a power window...
Page 39: Internal Equipment
If the problem is resolved, disconnect the device from the socket 06040400-L12-002 and switch the ignition off. If the problem is not resolved, contact a Fiat Only use genuine FCA accessories or Dealership. the equivalent requiring no greater than 120 W (DC 12V, 10A).
Page 40: Boot Lid
BOOT LID function: a locked boot lid can also be a malfunction in the electrical system opened while the key is being carried. and the boot lid cannot be unlocked, the boot lid can be opened by OPENING performing the emergency procedure (refer to “When the boot lid cannot be 47) 48) opened”...
Page 41 Do not prostration. Do not leave your children or pets alone in a car at any time. Do not emergency measure, contact a Fiat slam it. leave the car, the boot lid unlocked. Dealership as soon as possible.
Page 42: Bonnet
BONNET OPENING 51) 52) 53) 55) Proceed as follows: with the vehicle parked, pull the release handle 1 fig. 35 to unlock the bonnet; 07030201-122-001 07030201-123-002 release support rod 3 fig. 37 from its CLOSING locking device, then insert it in the padded area 4 fig.
Page 43: Convertible Top (Soft Top)
40 to unlock it; therefore do not attempt to forcefully push the bonnet back down. Otherwise, it could deform the bonnet or cause injury. If the active bonnet has activated, always consult an expert repairer, contact a Fiat Dealership immediately. 04110102-L36-006 04110102-L22-002...
Page 44 IMPORTANT If the power windows do IMPORTANT If the power windows do not go down automatically, fully open not go down automatically, fully open the windows. the windows. standing outside of the vehicle, hold IMPORTANT To raise the convertible the convertible top along the front edge top from inside the vehicle, use the 6 and pull it toward the vehicle rear;...
Page 45 generated from the defogger could damage the convertible top and the internal material. Before lowering or raising the convertible top, stop in a safe place off the right-of-way and park on a level surface. Make sure nothing is on the convertible top or near the back window when raising or lowering the 04110103-124-001...
Page 46 harden, becomes stained, or have an 16) When using steam washers or uneven gloss. WARNING high-pressure water washers, maintain a Do not lower the convertible top suitable distance and do not exceed a when it's wet. If the convertible top maximum temperature of 60°C.
Page 47 KNOWING THE INSTRUMENT PANEL This section of the owner handbook CONTROL PANEL AND gives you all the information you need INSTRUMENTS ....46 to understand, interpret and use the WARNING LIGHTS AND instrument panel correctly.
Page 48 CONTROL PANEL AND INSTRUMENTS 05020100-121-001 1. Odometer/Trip meter and Trip computer button/Dashboard illumination - 2. Tachometer - 3. Speedometer - 4. Automatic transmission info display - 5. Odometer/Trip computer info/Engine coolant temperature gauge/Fuel gauge/Outside temperature/Speed limiter/Cruise Control/INFO switch display...
Page 49 RIGHT-HAND DRIVE VERSIONS 05020100-667-888 1. Odometer/Trip meter and Trip computer button/Dashboard illumination - 2. Tachometer - 3. Speedometer - 4. Automatic transmission info display - 5. Odometer/Trip computer info/Engine coolant temperature gauge/Fuel gauge/Outside temperature/Adjustable speed limiter/Cruise Control/INFO switch display...
Page 50 ODOMETER / TRIP METER Trip meter INSTRUMENT PANEL ILLUMINATION The trip meter can record the total The display mode can be changed from distance of two trips. One is recorded in Brightness adjustment odometer to “Trip meter A” to “Trip “Trip A”, and the other is recorded in The brightness of the instrument cluster meter B”...
Page 51 If you have any problems with your trip speedometer. two digits (tenths and ones place) computer, contact a Fiat Dealership. The vehicle speed alarm can be set fig. 54; using the following procedure: press the INFO switch to display the vehicle speed alarm mode;...
Page 52 press the INFO switch and set the Manually shifting up Indication Condition (versions with automatic transmission) two lower digits (tenths and ones place) to the desired vehicle speed. The Using selector lever: to shift up to a The selected gear Numeral numerical value changes each time the higher gear, tap the selector lever back...
Page 53 WARNING LIGHTS AND MESSAGES IMPORTANT The warning light in the instrument panel appears together with a dedicated message and/or acoustic signal when applicable. These indications are indicative and precautionary and as such must not be considered as exhaustive and/or alternative to the information contained in the Owner Handbook, which you are advised to read carefully in all cases. Always refer to the information in this chapter in the event of a failure indication.
Page 54 The light turns on when the ignition is switched on for an operation check, and turns off a few seconds later or when the engine is started. If the light does not turn on or remains turned on, have the vehicle inspected at Fiat Dealership.
Page 55 IMPORTANT Do not drive with both the ABS warning light and brake warning light illuminated. Contact a Fiat Dealership to have the brakes inspected as soon as possible. Driving when the brake system warning light and ABS warning light are illuminated simultaneously is dangerous.
Page 56 If the light remains illuminated even though the oil level is normal or after adding oil, stop the engine immediately and contact a Fiat Dealership. DOOR-AJAR WARNING LIGHT The light turns on if any door is not closed securely.
Page 57 A system malfunction is indicated if the warning light constantly flashes, constantly illuminates or does not illuminate at all when the ignition is switched ON. If any of these occur, contact a Fiat Dealership as soon as possible. The system may not operate in an accident.
Page 58 (amber) flashes, the engine may not start. If the engine cannot be started, try starting it using the emergency operation for starting the engine, and contact a Fiat Dealership as soon as possible. Refer to “Emergency operation for starting operation” in “Starting the engine” paragraph.
Page 59 If this occurs, your brakes will function normally as if the vehicle had no ABS. Should this happen contact a Fiat Dealership as soon as possible. NOTE When the engine is jump-started to charge the battery, uneven rpm occurs and the ABS warning light may illuminate.
Page 60 If the tire pressure monitoring system has a malfunction, the tire pressure warning light flashes for about 1 minute when the ignition is switched ON and then stay on. Contact a Fiat Dealership as soon as possible. When the warning light illuminates, and the warning beep sound is heard (about 3 seconds), tire pressure is too low in one or more tires.
Page 61 Versions without Radio 7” The warning light turns on continuously if there is a malfunction in the battery management system or there is a malfunction in the brake switch. Contact a Fiat Dealership as soon as possible. Versions with Radio 7”...
Page 62 Warning lights What it means LED HEADLIGHT WARNING LIGHT (where provided) This light illuminates if there is a malfunction in the LED headlight. Contact a Fiat Dealership as soon as possible. LOW FUEL WARNING LIGHT The light turns on when the remaining fuel is about 9.0 litres.
Page 63 Warning light What it means TCS / DSC SYSTEM INDICATOR LIGHT The warning light turns on when the in case of intervention of TCS/DSC systems. This means that the vehicle is in critical stability and grip conditions. DSC OFF INDICATOR LIGHT The warning light turns on when the ESC system is deactivated.
Page 64 Green warning lights Warning light What it means LEFT DIRECTION INDICATOR The warning light turns on when the direction indicator control stalk is moved downwards or, together with the right direction indicator, when the hazard warning light button is pressed. RIGHT DIRECTION INDICATOR The warning light turns on when the direction indicator control stalk is moved upwards or, together with the left direction indicator, when the hazard warning light button is pressed.
Page 65 Warning light What it means KEY INDICATOR LIGHT Warning light flashing When the push button start is pressed from ON to ACC or OFF, the warning light may flash for approximately 30 seconds indicating that the remaining battery power of the key is low. Replace with a new battery before the key becomes unusable.
Page 66 The light turns on when the ignition is switched on for an operation check, and turns off a few seconds later or when the engine is started. If the light does not turn on or remains turned on, contact a Fiat Dealership.
Page 67 120 km/h warning (where provided). monitored again by Fiat Dealership or a tire temperature around the centre display repair station. 64) Do not ignore the TPMS warning light.
Page 68: Table Of Contents
SAFETY The chapter that you are about to read ACTIVE SAFETY SYSTEMS ..67 is very important: it describes the safety AUXILIARY DRIVING SYSTEMS ..71 systems with which the vehicle is OCCUPANT PROTECTION equipped and provides instructions on SYSTEMS .
Page 69: Active Safety Systems
Contact a Fiat Dealership. For the operation of the systems, see malfunction. the following pages. IMPORTANT In addition to the warning...
Page 70 TCS/DSC is not switched off, contact a NOTE The DSC may not operate automatically activates when the Fiat Dealership. The DSC may have a correctly unless the following are ignition is switched ON. malfunction.
Page 71 The active bonnet cannot be reused an electric tester. Otherwise, the active if it has been activated. Contact a Fiat bonnet may activate mistakenly or not Dealership. operate normally. Contact a Fiat...
Page 72 front bumper. In addition, it may the front bumper gets hit while the 69) Do not rely on the Traction Control activate depending on the level of vehicle is being driven at a speed System (TCS) as a substitute for safe impact from even a light object, small insufficient to activate the system;...
Page 73: Auxiliary Driving Systems
75) If the active bonnet has activated, SYSTEMS manufacturer on the vehicle placard or always contact a Fiat Dealership. If the tire inflation pressure label (if your bonnet release handle is pulled after the TPMS (Tire Pressure...
Page 74 Contact a Fiat Dealership. then remain continuously illuminated. a run-flat tire (where provided), This sequence will continue upon A system error activation may occur in...
Page 75 The easiest way to Replacing tires and wheels consult a Fiat Dealership. do it is to have a Fiat Dealership change IMPORTANT When replacing/repairing your tire and complete ID signal code the tires or wheels or both, have the IMPORTANT When reinstalling a registration.
Page 76 Tire Pressure Monitoring System HLA (Hill Launch Assist) FUNCTION initialization (versions with conventional tires) Hill Launch Assist (HLA) is a function which assists the driver in accelerating In the following cases, system from a stop while on a slope. When the initialization must be performed so that driver releases the brake pedal and the system operates normally:...
Page 77: Occupant Protection Systems
TPMS, which should be carried out IMPORTANT Do not rely completely on only by a Fiat Dealership. Hill Launch Assist. Hill Launch Assist is 78) Changes in outside temperature may an auxiliary device for accelerating from cause tire pressures to vary.
Page 78: Seat Belts
SEAT BELTS Persons with serious medical conditions also should wear seat belts. SEAT BELT Check with your doctor for any special PRECAUTIONS instructions regarding specific medical 79) 80) conditions. Seat belts help to decrease the Emergency locking mode possibility of severe injury during When the seat belt is fastened, it will accidents and sudden stops.
Page 79 Refer to “Seat belt warning beep” in it is still not retracting properly, have it fits snugly against your body. “Knowing the instrument panel” inspected: contact a Fiat Dealership. chapter. IMPORTANT Always wear the seat belt with it correctly routed in its guide 1 fig.
Page 80 Contact shoulders, as applicable; wearing the lap sure all occupants are properly restrained. a Fiat Dealership to inspect all seat belt section of the belt across the abdominal Not wearing a seat belt is extremely systems in use during an accident before area must be avoided.
Page 81: Sba System (Seat Belt Alert)
SBA SYSTEM SEAT BELT deploy when the passenger occupant (Seat Belt Alert) PRETENSIONER AND classification sensor detects a LOAD LIMITING passenger sitting on the passenger's SEAT BELT WARNING SYSTEMS seat. For details, refer to the passenger LIGHT occupant classification sensor. PRETENSIONERS The LED on dashboard trim turns on if IMPORTANT The pretensioner system...
Page 82: Child-Restraint Precautions
Unless all safety procedures are followed, FCA strongly urges the use of WARNING injury could result. Contact a Fiat child-restraint systems for children small Dealership for safely dispose of the enough to use them. pretensioner system or scrap a 88) Wear seat belts only as recommended pretensioner system equipped vehicle.
Page 83 IMPORTANT A seat belt or passenger seat with the air bag system activated. In the event of an impact the child-restraint system can become very air bag activation may cause fatal hot in a closed vehicle during warm injuries to the transported child. weather.
Page 84 CATEGORIES OF CHILD-RESTRAINT SYSTEMS NOTE When purchasing, ask the manufacturer of the child-restraint system which type of child-restraint system is appropriate for your child and vehicle. Child-restraint systems are classified into the following 5 groups according to the UNECE 44 regulation. Group Weight Up to 9 months old...
Page 85 CHILD-RESTRAINT SYSTEM TYPES In this Owner Handbook, explanation of child restraint systems secured with seat belts is provided for the following three types of popular child-restraint systems: baby seat, child seat, junior seat. IMPORTANT Installation position is determined by the type of child-restraint 06070809-INF-001 03030202-BOO-001 system.
Page 86 Junior seat installation position CHILD SEAT INSTALLATION POSITION A junior seat is used in the front-facing position only. 102) 104) 105) 106) 106) Refer to the table “Child restraint A child seat is used in front-facing and system suitability for various seat rear-facing positions depending on the positions”...
Page 87 CHILD RESTRAINT SYSTEM SUITABILITY FOR VARIOUS SEAT POSITION Provided information in the table shows your child-restraint system suitability for various seating position. For installation suitability of other manufacturer child-restraint system, carefully consult the manufacturer's instructions which accompany the child-restraint system. ISOFIX anchor-secured child-restraint systems When installing a child-restraint system to the passenger seat, refer to the child-restraint system manufacturer's instructions and the Using ISOFIX anchor.
Page 88 Seat positions Weight group Size class Fixture Vehicle ISOFIX positions Passenger seat ISO/R2 ISO/R3 ISO/F2 GROUP 1 9 kg – 18 kg ISO/F2X ISO/F3 IL (2) GROUP 2 15 kg – 25 kg IL (3) GROUP 3 22 kg – 36 kg IL (3) (1) For the CRS which do not carry the ISO/XX size class identification (A to G), for the applicable weight group, the car manufacturer shall indicate the vehicle specific ISOFIX child-restraint system(s) recommended for each position.
Page 89 i-Size child restraint systems An i-Size child-restraint system can be installed to the specified seat as follows: Passenger seat i-Size child restraint systems X = Seating position not suitable for i-Size “universal” child-restraint systems. IMPORTANT An i-Size child restraint system refers to a child-restraint system which has acquired i-Size category certification for the UNECE 129 regulation.
Page 90 Seat belt-secured child-restraint systems Passenger seat Child restraint System group Age group Weight group system type (Air bag disabled) (Air bag enabled) Up to approximately GROUP 0 Less than 10 kg Baby seat 9 months old Up to approximately GROUP 0+ Less than 13 kg Baby seat 2 years old...
Page 91 INSTALLING CHILD held, the seat will move suddenly and RESTRAINT SYSTEMS could cause injury. Proceed as follows: 107) 108) open the convertible top; Anchor bracket slide the passenger seat as far back Anchor brackets for securing child as possible and then slide it forward restraint systems are provided in the about 100 mm so that your hand can vehicle.
Page 92 held, the seat will move suddenly and the ISOFIX anchors for the attachment could cause injury. of a child restraint system. secure the child restraint system Proceed as follows: using the ISOFIX anchor, following the open the convertible top; child restraint system manufacturer's make sure the ignition is switched instruction;...
Page 93 94) Always secure a child in a proper 97) Even in a moderate collision, the 99) Seating a child in a child-restraint child-restraint system. Holding a child in child-restraint system can be hit by a system on the passenger seat is your arms while the vehicle is moving is deploying air bag and moved violently dangerous under certain conditions.
Page 94 100) Do not allow a child or anyone to lean 103) Always install a rear-facing child seat 106) Before installing child-restraint system over or against the side window of a in the correct seat position. Installing a on the passenger seat, move the vehicle with side air bags.
Page 95: Supplementary Restraint System Srs - Air Bag
SUPPLEMENTARY cannot provide adequate protection 110) Make sure the child restraint system RESTRAINT SYSTEM during an accident. Seat belt usage is is properly secured. A child restraint SRS - AIR BAG necessary to: system that is not secured is dangerous. In a sudden stop or collision, it can become a keep the occupant from being SUPPLEMENTAL...
Page 96 SUPPLEMENTARY RESTRAINT SYSTEM COMPONENTS 03040300-121-002 1 Driver/Passenger inflators and air bags 2 Crash sensors and diagnostic module (SAS unit) 3 Seat belt pretensioners 4 Front air bag sensors 5 Side crash sensors 6 Air bag/seat belt pretensioner system warning light 7 Side inflators and air bags 8 Passenger air bag deactivation indicator light 9 Passenger occupant classification sensor...
Page 97 HOW THE SRS AIR BAGS WORK 115) 116) 117) 118) 119) 120) 121) 122) 123) 124) 125) 128) 129) Your vehicle is equipped with the following types of SRS air bags. SRS air bags are designed to work together with the seat belts to help to reduce injuries during an accident.
Page 98 bag only on the side in which the sensor detects a passenger sitting on vehicle was hit. the passenger's seat. Warning Light/Beep A system malfunction or operation conditions are indicated by a warning. Refer to “Warning lights and messages” paragraph in “Knowing your instrument panel”...
Page 99 SRS AIR BAG DEPLOYMENT CRITERIA This chart indicates the applicable SRS equipment that will deploy depending on the type of collision (the illustrations are the representative cases of collisions). Types of collision SRS equipment A severe frontal/near frontal A severe side collision (*) A rear collision collision SRS equipment...
Page 100 X: the SRS air bag equipment is designed to deploy in a collision. (*) In a side collision, the seat belt pretensioners and the side air bags deploy (only on the side in which the collision occurs). (**) The passenger front and side air bags and the seat belt pretensioner are designed to deploy when the passenger occupant classification sensor detects a passenger sitting on the passenger's seat.
Page 101 LIMITATIONS TO SRS AIR Limitations to side collision detection Side collisions may not be detected as In severe collisions such as those severe enough to deploy the SRS air described in "SRS Air Bag deployment bag equipment: criteria" paragraph, the applicable SRS side impacts involving trees or poles air bag equipment will deploy.
Page 102 deploying if the passenger air bag deactivation indicator light turns on. To reduce the chance of injuries caused by deployment of the passenger air bag, the system deactivates the passenger front and side air bags and also the seat belt pretensioner system when the passenger air bag deactivation indicator light turns on.
Page 103 Owner Handbook. Then, if the passenger air bag deactivation OFF indicator light still does not turn on, and contact a Fiat Dealership as soon as possible. If the passenger air bag deactivation indicator light turns on when an...
Page 104 ON or they do not turn on as indicated in the passenger air bag deactivation indicator light on/off condition chart, do not allow an occupant to sit in the passenger seat and contact a Fiat Dealership as soon as possible. The system may not work...
Page 105 114) EXTREME HAZARD! Never use a 116) Do not sit too close to a door or lean WARNING rear-facing child-restraint system on the against doors in vehicles with side air bags. passenger seat with an air bag that could Sitting too close to the side air bag deploy.
Page 106 Always have an expert bag modules. It also includes installing Furthermore, the bag could be cut open repairer, we recommend a Fiat Dealership extra electrical equipment on or near releasing the gas. Do not hang net bags, inspect a damaged door. Modifying a door system components or wiring.
Page 107 Only a trained makes it difficult for the passenger the passenger air bag deactivation expert repairer, we recommend a Fiat occupant classification sensor to detect indicator light on/off condition chart. For Dealership that can fully evaluate these the occupant correctly is dangerous.
Page 108: Recording Of Vehicle Data
RECORDING OF an agreement from the vehicle owner 23) To allow the sensors to function VEHICLE DATA (agreements from lessor and lessee for properly, always perform the following: leased vehicle) is obtained; adjust the seats as far back as possible This vehicle is equipped with a and always sit upright against the officially requested by the police or...
Page 109: Constant Monitoring
CONSTANT MONITORING The following components of the air bag systems and the active bonnet are monitored by a diagnostic system: Crash sensors, and diagnostic module (SAS unit) Front air bag sensors Air bag modules Side crash sensors Air bag/Seat belt pretensioner system warning light Seat belt pretensioners Related wiring...
Page 110 STARTING AND OPERATING Let’s get to the "heart" of the vehicle: STARTING THE ENGINE ..109 seeing how you can exploit all of its PARKING BRAKE ... .109 potential to the full.
Page 111 STARTING THE PARKING BRAKE 131) The brake servo is not active until the ENGINE engine is started, so you would need to apply much more force than usual to the brake pedal. 133) 134) 135) 132) Do not start the engine by pushing, 130) 131) 132) IMPORTANT Driving with the parking towing or driving downhill.
Page 112 The brakes could fail and cause a serious accident. As soon as you hear a operation and does not indicate a screeching noise contact a Fiat Dealership. malfunction. NOTE When the brake pedal is depressed hard or depressed more quickly, a motor/pump operation noise may be heard.
Page 113 at least 2 seconds with the clutch pedal AUTOMATIC lever from the side without having to rest your elbow on the center console fully pressed before engaging reverse to TRANSMISSION box. prevent damage to the gears and (where provided) grating. If shifting to R is difficult, shift back into neutral, release the clutch pedal, and try again.
Page 114 IMPORTANT Shifting into a driving gear M (Manual) or reverse when the engine is running M is the manual shift mode position. faster than idle can damage the Gears can be shifted up or down by transmission. operating the selector lever. Refer to “Manual shift mode”.
Page 115 IMPORTANT If you change to manual shifts down. take the vehicle to a Fiat Dealership. shift mode without depressing the Auto-shift down accelerator pedal when driving in D...
Page 116: Cruise Control
DRIVING TIPS CRUISE CONTROL 140) If the engine is running faster than idle, do not shift from N or P into a driving 142) 143) gear. It's dangerous to shift from N or P Passing This is an electronically controlled into a driving gear when the engine is running faster than idle.
Page 117 IMPORTANT When the MODE switch is warning light (green) turns on. pressed during cruise control system The cruise control speed setting cannot operation, the system switches to the be performed under the following adjustable speed limiter. conditions: Without Speed limiter: press the Automatic transmission: the OFF/CANCEL switch.
Page 118 146) In the event of device faults or failures, Versions with Speed limiter: the return to the set speed. go to a Fiat Dealership. MODE switch for the adjustable speed 147) The cruise control can be dangerous limiter is pressed;...
Page 119 SPEED LIMITER ACTIVATION / SETTING A DESIRED DEACTIVATION SPEED (where provided) Activation Proceed as follows: press the ON switch to turn the Press the ON switch to operate the 148) 149) system on; system. The adjustable speed limiter The speed limiter can be set between press the SET/- to set the speed.
Page 120 The set speed can be set by pressing PARKING SENSOR SENSOR DETECTION RANGE the SET/- switch while the system is in SYSTEM stand-by status. The sensors detect obstructions within (where provided) the following range: Lateral detection range: about WARNING 150) 151) 50 cm Rear detection range: about 26) 27) 28)
Page 121 27) Only have the bumpers repainted or WARNING any retouches to the paintwork in the area of the sensors carried out by a Fiat Dealership. Incorrect paint application 150) Do not rely completely on the parking could affect the operation of the parking sensor system and be sure to confirm the sensors.
Page 122 Fuel filler cap control system could be damaged. To remove the fuel filler cap, turn it Contact a Fiat Dealership for details. anticlockwise fig. 93. Attach the REFUELLING removed cap to the inner side of the PROCEDURE fuel flap.
Page 123 REAR CAMERA 153) Before refuelling, stop the engine, and (PARKVIEW REAR always keep sparks and flames away from BACKUP CAMERA) the filler neck: fuel vapour is dangerous. It could be ignited by sparks or flames (only versions with Radio 7” system) causing serious burns and injuries.
Page 124 (location or installation angle) this could compromise the hermetic may have been altered. Contact a Fiat seal. Dealership. IMPORTANT The camera cover is IMPORTANT If the display shows "no made of plastic.
Page 125 IMPORTANT The guide lines are fixed fig. 99. Continue checking the vehicle's on the screen. They are not surroundings and then stop the vehicle in the best possible position (if the synchronized with the driver’s actions on the steering wheel. Always use the parking space has division lines, check whether the vehicle width guide lines utmost caution and check the area...
Page 126 between the displayed image, such as adjust the brightness, contrast, tint, indicated below, and the actual and color using the slider. If you need to WARNING conditions when parking, always verify reset, press the reset button; the safety at the rear of the vehicle and select the icon on the screen to close 158) Parking and other potentially the surrounding area directly with your...
Page 127: Towing Trailers
TOWING TRAILERS IMPORTANT Your car is not designed for towing. 29) It is vital, for correct operation, that the camera is always kept clean and free from mud, dirt, snow or ice. Be careful not to scratch or damage the camera while cleaning it.
Page 128: In Case Of Emergency
IN CASE OF EMERGENCY A punctured tyre or a burnt-out bulb? HAZARD WARNING LIGHTS ..127 REPLACING A BULB..127 At times, a problem may interfere with REPLACING FUSES ..136 our journey.
Page 129 Fiat The emergency stop signal system Dealership; does not operate at vehicle speeds use the protective cover and carton under about 60 km/h.
Page 130 IMPORTANT When the weather is cold or damp or after heavy rain or washing, the surface of headlights or rear lights may steam up and/or form drops of condensation on the inside. This is a natural phenomenon due to the difference in temperature and humidity between the inside and the outside of the glass which does not indicate a...
Page 131 Exterior light Light bulbs Type Power (versions with Full-LED — Full-LED headlights) Front positions (versions with halogen headlights) (versions with Full-LED High-beams — Full-LED headlights) High-beam/Daytime Running (versions with halogen headlights) 55/15 W Lights (DRL) (versions with Full-LED Daytime Running Lights (DRL) —...
Page 132 Interior light Category Light bulb Wattage UNECE Overhead light — Boot lid light — (*) UNECE stands for United Nations Economic Commission for Europe.
Page 133 REPLACING EXTERIOR Headlights (high beam) with LIGHT BULBS Daytime Running Lights (LED versions) Headlights (low beam) (versions with halogen bulb) Proceed as follows: if you are changing the right bulb, Proceed as follows: start the engine, turn the steering wheel if you are changing the right bulb, all the way to the right, and turn off start the engine, turn the steering wheel...
Page 134 Fog lights Proceed as follows: if you are changing the right bulb, start the engine, turn the steering wheel all the way to the right, and turn off engine. If you are changing the left bulb, turn the steering wheel to the left; make sure the ignition is switched off, and the headlight switch is off;...
Page 135 Brake lights / Tail lights Go to a Fiat Dealership when the replacement of this lights is necessary. Side direction indicator lights Proceed as follows: make sure the ignition is switched off, and the headlight switch is off; if you are changing the right bulb,...
Page 136 remove the two nuts 5 fig. 115 and a screw 4; pull the unit rearward 6 fig. 116 to remove it; turn the socket and bulb assembly 7 fig. 117 counterclockwise and remove 07031501-213-002 08070604-123-100 07031501-212-002 Rear direction indicator lights Proceed as follows: remove the retainers 1 fig.
Page 137 fig. 118 = reverse light / 2 = rear fog light; disconnect the bulb from the socket; install the new bulb in the reverse order of the removal procedure. 07031501-216-001 08020499-000-012 Number plate lights Proceed as follows: 07031501-220-001 make sure the ignition is switched off, and the headlight switch is off;...
Page 138 30) Where possible, it is advisable to have vehicle and under the bonnet. bulbs changed at a Fiat Dealership. Proper FUSES ON THE LEFT operation and direction of the external SIDE OF THE VEHICLE lights are essential for driving in safety and comply with law.
Page 139 FUSES UNDER THE When removing the cover, remove it BONNET slowly according to the following Make sure the ignition is switched off, procedure: and other switches are off and remove disengage the rear lock 1 fig. 122 by the fuse block cover. If the lock is pressing down on the front tab with forcefully opened, the fuse block cover your fingers;...
Page 140 FUSE BLOCK (ENGINE COMPARTMENT) 07031602-121-001...
Page 141 DESCRIPTION FUSE RATING PROTECTED COMPONENT HORN2 7.5 A Horn — — — INTERIOR 15 A Overhead light AUDIO2 15 A Audio system METER1 10 A Instrument cluster SRS1 7.5 A Air bag — — — RADIO 7.5 A Audio system AUDIO1 25 A Audio system...
Page 142 DESCRIPTION FUSE RATING PROTECTED COMPONENT CABIN + B 50 A For protection of various circuits — — — — — — EVPS 30 A — FAN1 30 A Cooling fan FAN2 40 A Cooling fan DEFOG 30 A Rear window defogger 30 A For protection of various circuits HEATER...
Page 143 FUSES ON THE LEFT SIDE OF THE VEHICLE 07031602-03F-002...
Page 144 DESCRIPTION FUSE RATING PROTECTED COMPONENT RHT R 30 A — RHT L 30 A — — — — — — — F.OUTLET 15 A Accessory sockets — — — AT IND 7.5 A AT shift indicator (where provided) MIRROR 7.5 A Power control mirror R_DECK R 30 A...
Page 145: Tire Service Kit
TIRE SERVICE KIT WARNING (where provided) 169) 170) 171) 172) 173) 174) 175) 164) If the fuse blows again contact a Fiat Dealership. 165) Never replace a fuse with another with a higher amp rating; DANGER OF FIRE. TOOL STORAGE...
Page 146 of effectiveness is indicated on the shake the tire sealant well. If the bottle label); bottle is shaken after the injection hose – the tear or puncture exceeds about is screwed on, tire sealant could spray 4 mm; out from the injection hose. Tire sealant –...
Page 147 IMPORTANT Do not throw away the empty tire sealant bottle after use. Return the empty tire sealant bottle to a Fiat Dealership when replacing the tire. The empty tire sealant bottle will need to be used to extract and dispose of 08020202-03A-005 the used sealant from the tire.
Page 148 If the tire does not reach the specified tire inflation pressure within 10 minutes, it may have received extensive damage. In this case, the repair using the tire service kit was not successful. Contact a Fiat Dealership.
Page 149 169) Punctures on the sides of the tire may condition to ensure the safety and the Fiat Dealership and have the flat tire effectiveness of the tire service kit. Carefully not be repaired. Do not use the kit if the tire replaced.
Page 150 JUMP STARTING IMPORTANT Do not attempt jump starting if the battery is wet. The battery PREPARATIONS FOR could break and explode! JUMP STARTING JUMP-STARTING 176) 177) 178) 179) 180) 181) 182) 183) 184) 185) PROCEDURE IMPORTANT If the procedure below is Jump-starting is dangerous if done carried out incorrectly can cause severe incorrectly.
Page 151 if the battery cover has been 180) Do not allow the positive (+) terminal removed, install it in the reverse order of to contact any other metal object that removal. could cause sparks. Flames and sparks near open battery cells are dangerous. IMPORTANT Verify that the covers are Hydrogen gas, produced during normal securely installed.
Page 152 TOWING THE 185) Connect the negative lead to a good VEHICLE ground point (see figure) away from the battery. Connecting the end of the second ATTACHING THE TOW jumper lead to the negative (–) terminal of HOOKS the discharged battery is dangerous. A spark could cause the gas around the 35) 36) 37) battery to explode and injure someone.
Page 153 the towing eyelet and towing hook or 37) The front and rear tow hooks should be rope; used only for emergencies on the road. You do not attach any rope other than to are allowed to tow the vehicle for short the towing eyelet and towing hook.
Page 154 If towing service is not available in an EMERGENCY emergency, the vehicle may be towed TOWING with all four wheels on the ground using TOWING DESCRIPTION the towing hook at the front of the Proper lifting and towing are necessary vehicle.
Page 155 MAINTENANCE AND CARE Correct maintenance permits the INTRODUCTION... . .154 performance of the vehicle to be ENGINE COMPARTMENT ..160 maintained over time, as well as limited BATTERY RECHARGING .
Page 156 The ignition and fuel systems are highly a reliable and qualified service shop Improper do-it yourself maintenance important to the emission control perform the work, preferably at Fiat during the warranty period may affect system and to efficient engine Dealership.
Page 157 check and, if necessary, replace HEAVY-DUTY USE OF THE PERIODIC CHECKS VEHICLE pollen filter; Every 1,000 km or before long trips If the vehicle is used under one of the check and, if necessary, replace air check and, if necessary, top up: following conditions: cleaner.
Page 158 SCHEDULED SERVICING PLAN The checks listed in the Scheduled Servicing Plan, after reaching 120,000 km/8 years, must be cyclically repeated starting from the first interval, thus following the same intervals as before. Thousands of miles Thousands of kilometers Years Check tire condition/wear and adjust pressure, if ●...
Page 159 Thousands of miles Thousands of kilometers Years Check endfloat of wheel bearings and front and ● ● ● ● ● rear joints ● ● ● ● ● Check windscreen wiper blade position/wear Check operation of the wiper/washer system ● ● ●...
Page 160 "Technical specifications" chapter); stricltly comply with the replacement intervals in the Scheduled Servicing Plan. It is advisable to contact a Fiat Dealership for spark plug replacement. (3) Areas that are not dusty: recommended maximum mileage 120.000 km. Regardless of the mileage, the belt must be replaced every 6 years.
Page 161 WARNING IMPORTANT 186) Do not perform maintenance work if 38) Do not leave items in the engine you lack sufficient knowledge and compartment. After you have finished experience or the proper tools and checking or doing servicing in the engine equipment to do the work.
Page 162 ENGINE COMPARTMENT CHECKING LEVELS 189) 190) 07030300-121-003-high.jpg 1. Window and headlight washer fluid 2. Engine oil dipstick 3. Engine oil cap 4. Engine coolant fluid 5. Brake/clutch fluid 6. Battery...
Page 163 191) Engine oil changing NOTE Changing the engine oil should be done by Fiat Dealership. Inspecting engine oil level ENGINE COOLANT Proceed as follows: 192) 193) 194) be sure the vehicle is on a level surface;...
Page 164 146 (1 = upper level / 2 = AUTOMATIC lower level). Do not overfill. TRANSMISSION CONTROL UNIT The transmission control oil level should only be checked at a Fiat Dealership. BATTERY MAINTENANCE 198) 199) 200) 201) 07030601-121-002 07031202-ALL-001 To get the best service from a battery: keep it securely mounted;...
Page 165 A low 194) The cooling system is pressurized. If Contact a Fiat Dealership for a battery brake/clutch fluid level is dangerous. A low necessary, only replace the cap with level could indicate brake lining wear or a replacement purchase.
Page 166 Go to a Fiat connect the charger cables to the IMPORTANT Charging should be slow Dealership if you want to install accessories battery terminals, observing the polarity;...
Page 167 IMPORTANT Using snow chains with tires with non-original dimensions may Contact a Fiat Dealership for tire rotation. damage the vehicle. After adjusting the tire pressure, IMPORTANT Using different size or type initialization of the tire pressure (M+S, snow, etc.) tires between front...
Page 168 monitoring system is necessary to 51) Keep your speed down when snow make the system operate normally. WARNING chains are fitted; do not exceed 50 km/h Refer to “Tire Pressure Monitoring (30 mph). Avoid potholes, steps and System Initialization” paragraph in pavements and avoid driving for long 206) If the tires are "unidirectional", do not distances on roads not covered with snow...
Page 169 BODYWORK IMPORTANT Chipped paint can lead to left in the sun or with the bonnet hot: this may alter the shine of the rust forming on your vehicle. Before this paintwork. happens, repair the damage by using PRESERVING THE FCA touch-up paint according to the Exterior plastic parts must be cleaned PAINTWORK instructions in this section.
Page 170 IMPORTANT Do not spray water in the 53) Avoid washing with rollers and/or engine compartment. Otherwise, it WARNING brushes in washing stations. Wash the could result in engine-starting problems vehicle only by hand using neutral pH or damage to electrical parts. detergents;...
Page 171 213) If a seat belt appears frayed or has Wipe off the remaining detergent using abrasions, have it replaced by a Fiat a cloth soaked in clean water and Dealership. If a seat belts is used under wrung out well.
Page 172 TECHNICAL SPECIFICATIONS Everything you may find useful for IDENTIFICATION DATA..171 understanding how your vehicle is ENGINE ....172 made and works is contained in this WHEEL AND TIRE chapter and illustrated with data, tables...
Page 173: Identification Data
IDENTIFICATION DATA MODEL PLATE Model plate is located on the left side of door pillar fig. 148. 10010109-333-333 10010109-321-321 Vehicle Identification Number fig. 150. ENGINE NUMBER Engine number label is located on the engine. 10010103-121-001 CHASSIS NUMBER / VEHICLE IDENTIFICATION NUMBER (Ireland / U.K.) Chassis number: open the cover shown in fig.
Page 174 ENGINE 218) Version 1.4 Turbo Multi Air 140HP Cycle Otto Number and position of cylinders 4 in line Piston bore and stroke (mm) 72.0 x 84.0 Total displacement (cm³) 1368 Compression ratio 9.8:1 Maximum power (EEC) (kW) Maximum power (EEC) (HP) corresponding engine speed (rpm) 5000 Maximum torque (EEC) (Nm)
Page 175 When replacing tires, FCA recommends that you replace tires of the same type originally fitted to your vehicle. For details, contact a Fiat Dealership. Check the tire pressure label for tire size and inflation pressure (refer to “Tire inflation pressure”...
Page 176 RIMS AND TIRES PROVIDED Rims Standard tire Winter tire 6 1/2 J x 16 195/50 R16 84V (*) 195/50 R16 84 M+S (**) 7J x 17 205/45 R17 84W (*) 205/45 R17 84 M+S (***) (*) 3-season type (**) Load index and speed symbol: 84Q/84S/84H/84V (***) Load index and speed symbol: 84Q/84S/84H/84V/84W COLD TIRE INFLATION PRESSURE Add +0.3 bar to the prescribed pressure when the tires are warm.
Page 177 WARNING 219) If winter tyres with a lower speed rating than that indicated in the Registration Document are used, do not exceed the maximum speed corresponding to the speed rating of the tyres used. IMPORTANT 55) Keep your speed down when snow chains are fitted;...
Page 178 WEIGHTS Curb weight: 1050 kg...
Page 179 DIMENSIONS Dimensions are expressed in mm and refer to the vehicle equipped with its standard-supplied tyres. Height is measured with vehicle unladen. BOOT VOLUME: 140 litres 10000555-122-333 4,055 (*) / 4,075 (**) 2,310 1,230 1,495 1,740 1,505 (*) Without license plate holder. (**) With license plate holder.
Page 180: Fluid Capacities
FLUID CAPACITIES Item Capacities Fuel tank (litres) Engine oil (without oil filter replacement) (litres) Engine oil (with oil filter replacement) (litres) (**) Coolant (versions with manual transmission) (litres) / 6.7 (**) Coolant (versions with automatic transmission) (litres) / 6.5 Manual transmission oil (litres) Automatic transmission fluid (litres) Rear differential oil (litres) LSD oil (litres)
Page 181: Fluids And Lubricants
FLUIDS AND LUBRICANTS Your vehicle is equipped with an engine oil that has been thoroughly developed and tested in order to meet the requirements of the Scheduled Servicing Plan. Constant use of the prescribed lubricants guarantees the fuel consumption and emission specifications. Lubricant quality is crucial for engine operation and duration.
Page 182 Original fluids and Lubricant Characteristics Specification Replacement interval lubricants TUTELA TRANSMISSION SAE 75W-90 grade. API 9.55550-MZ11 GEAR SYNTH LL Manual transmission oil GL4 specification Contractual Technical Reference N° F004.C16 TUTELA TRANSMISSION GI/V Automatic transmission JWS 3309, type T-IV. 9.55550-AV1 Lubricants and greases Contractual Technical for drive transmission Reference N°...
Page 183 IMPORTANT 56) The use of products with specifications other than those indicated above could cause damage to the engine not covered by the warranty.
Page 184 PERFORMANCE Top speed after the initial period of usage of the vehicle. Version km/h 1.4 Turbo Multi Air 140HP...
Page 185 FUEL CONSUMPTION The fuel consumption value given in the table below are determined on the basis of the type-approval tests laid down by specific European Directives. IMPORTANT The type of route, traffic conditions, weather conditions, driving style, general condition of the vehicle, trim level/equipment/accessories, use of the climate control system, vehicle load, presence of roof racks and other situations that adversely affect the aerodynamics or wind resistance lead to different fuel consumption values than those measured.
Page 186 EMISSIONS The CO emission level given in the following table refer to combined consumption. EMISSIONS ACCORDING TO THE EUROPEAN DIRECTIVE Version IN FORCE (g/km) 1.4 Turbo Multi Air 140HP...
Page 187 PRESCRIPTIONS FOR HANDLING THE VEHICLE AT THE END OF ITS LIFE (where provided) FCA has been committed for many years to safeguarding the environment through the constant improvement of its production processes and manufacturing products that are increasingly "eco-compatible". To grant customers the best possible service in terms of respecting environmental laws and in response to European Directive 2000/53/EC governing vehicles at the end of their life, FCA is offering its customers the chance to hand over their vehicle at the end of its life without incurring any additional costs.
Page 188 MULTIMEDIA TIPS, CONTROLS AND GENERAL INFORMATION....187 This chapter describes the main RADIO 3” ....188 functions of Radio 3”...
Page 189 Otherwise the Reception may be interfered with by the system might be damaged. presence of mountains, buildings or Contact a Fiat Dealership as soon as bridges, especially when you are far possible to have the system repaired. away from the broadcaster.
Page 190 RADIO 3” FRONT PANEL 06020300-121-001...
Page 191 STEERING WHEEL VOLUME SWITCHES seconds have elapsed to start playback CONTROLS from the beginning of the current track. Press up the volume switch + to The controls for the main system increase the volume. Press down the MUTE SWITCH functions are present on the steering volume switch –...
Page 192 AF (Alternative Frequency); OPERATING THE RADIO MW/LW, FM1, or FM2 and then press REG (Regional Programme); its channel preset button. The station Radio ON: press a band selector ALC (Automatic volume adjustment); frequency or the channel number will be button FM/AM to turn the radio on. BASS (Low pitch sound);...
Page 193 problem. If the Bluetooth ® system button to switch to the USB mode and begins to track down to the beginning does not connect automatically after start playback. of the previous track. 1 or 2 minutes have elapsed, make Press the track down button after Track search sure that the Bluetooth ®...
Page 194 Say: [Beep] “Yes” or “No”. If “Yes”, using the device, perform a search go to next step. If “No”, the procedure for the Bluetooth ® device (Peripheral device) returns to Step 9 select “124 Spider” from the device Prompt: “Your new pairing code is list searched by the device and input YYYY.
Page 195 RADIO 7” higher or lower frequency whether MUTE SWITCH programmed or not. Press the mute switch once to mute STEERING WHEEL audio, press it again to resume audio Radio stations which have been CONTROLS output. previously stored in the favourite radio The controls for the main system can be called up by pressing the seek If the ignition is switched off with the...
Page 196 Touch panel operation enhancement)/Rear (rear speaker displays the Entertainment volume enhancement); Touch & Tap: touch or tap on the item screen. Balance (Left/right volume balance): indicated on the screen. The operation NAV displays the Navigation screen Left (left speaker volume is launched and the next item is (only navigation-equipped enhancement)/Right (right speaker...
Page 197 Communication: Bluetooth® displays the station list (AM Automatic radio station related functions are available. only). Select “Update Station selection. When Navigation: Navigation screen List” to display the frequencies long-pressed, the radio (where provided) is displayed. If of up to ten radio stations on the frequency changes the SD card for the navigation auto memory preset list Select...
Page 198 You can customize settings in the setup Displays the favorites list. Press display as follows: and hold to store the currently “Display”: refer to “Volume/Display/ tuned station to the favorites list. Sound controls” paragraph in Radio 7 Searches your desired station supplement;...
Page 199 sure that the Bluetooth ® setting on NOTE Adjust the audio volume using devices compatible with SMS the device is normal and attempt to the portable audio device, commander function SMS messages is downloaded reconnect the Bluetooth ® device from switch, or audio control switch.
Page 200 NOTE For navigation map updates visit phonebook or the name of a person from the mobile phone. the http://124spiderinfotainment.com whose phone number has been NOTE A maximum of 1000 contacts website. registered in the Bluetooth ® can be registered to the phonebook. hands-free.
Page 201 information about the next manoeuvre, i Displays the screen where traffic street or town. There is an area at the information and the GPS reception top left part of screen which indicates conditions can be set and verified. the next operation. Displays both the Cancels waypoint/route.
Page 202 SELECTING THE DESTINATION OF names that match the string appear in a entering a few letters, select to open A ROUTE list after entering a couple of characters the list of POI with names containing (to open the list of results before it the entered character sequence.
Page 203 the route. Additionally, the route can be Guidance Settings: a function for zooming in on approaching revised by selecting other options. guidance-related setting is available intersections turns on/off automatically. during route guidance. Buildings: show or hide 3D town SELECTING A NEW DESTINATION Warning Settings: a setting related models, 3D artistic or block Proceed as follows:...
Page 204 IMPORTANT INFORMATION AND RECOMMENDATIONS WARNING BRAKE SYSTEM Do not coast with the engine stalled or turned off, find a safe place to stop. Coasting with the engine stalled or turned off is dangerous. Braking will require more effort, and the brake's power-assist could be depleted if you pump the brake. This will cause longer stopping distances or even an accident.
Page 205 Be extremely careful if it is necessary to downshift on slippery surfaces: downshifting into lower gear while driving on slippery surfaces is dangerous. The sudden change in tyre speed could cause the tyres to skid. This could lead to loss of vehicle control and an accident.
Page 208 MAINTAIN YOUR VEHICLE IN TIP TOP CONDITIONS WITH Mopar Vehicle Protection offers a series of service contracts that are designed to give all our customers the pleasure of driving their vehicle without any hitch's and concerns. Our product portfolio consists of a wide and flexible range of extended warranty and maintenance plans endorsed by FCA.
Page 209 NOTES...
Page 212 INDEX CO2 emissions ....184 Fuse block (engine compartment) ..... .138 Coming Home light system .
Page 213 ane change signals ...27 Pretensioners....79 Side Air Bags ....95 Load limiter (pretensioner) .
Page 214 FCA Italy S.p.A. - MOPAR - Technical Services - Service Engineering Largo Senatore G. Agnelli, 3 - 10040 Volvera - Torino (Italia) Print no. 603.99.904 - 06/2016 - 2 Edition...
Page 215 At Fiat Service authorised workshops you can find technicians directly trained by us, offering quality and professionalism for all service operations. Fiat workshops are always close to you for the regular servicing operations, season checks and practical recommendations by our experts.
Page 216 The data contained in this publication is intended merely as a guide. FCA Italy S.p.A. reserves the right to modify the models and versions described in this booklet at any time for technical and commercial reasons. If you have any further questions please consult your FIAT dealer. Printed in recycled paper without chlorine.

This manual is also suitable for:

124 spider

Fiat Spider 124 Owner's Handbook Manual

Quick Links

Related Manuals for Fiat Spider 124

Summary of Contents for Fiat Spider 124

This manual is also suitable for:

Table of Contents
