Page 1 124 SPIDER 2 0 1 9 O W N E R ’ S M A N U A L...
Page 2 This manual illustrates and describes the operation of VEHICLES SOLD IN CANADA With respect to any Vehicles Sold in Canada, the name features and equipment that are either standard or op- FCA US LLC shall be deemed to be deleted and the name tional on this vehicle.
Page 3 Dear Customer, We would like to congratulate and thank you for choosing a Fiat 124 Spider. We have written this Owner’s Manual to help you get to know all the features of your vehicle and use it in the best possible way.
Page 4 Read This Carefully REFUELING Only refuel with unleaded gasoline with a recommended rating of 91 octane. A rating less than 87 octane is not acceptable. Do not use gasoline containing methanol or ethanol E85. Using these mixtures may cause misfiring and handling issues, as well as damage fundamental components of the fuel supply system.
Page 5 How To Use This Manual ESSENTIAL INFORMATION Each time directions (left/right or forward/backwards) are listed, they are determined by facing forward from the rear of the vehicle or as from the point of view of being seated inside the car. Special cases not complying with this rule will be properly specified in the text.
Page 6 Vehicle Modifications / Alterations Warning! Any change or alteration of the vehicle might seriously affect its safety and road holding, thus causing accidents, in which the occupants could be fatally injured. ACCESSORIES PURCHASED BY THE OWNER If after buying the vehicle, you decide to install electrical accessories that require a permanent electrical supply (e.g. radio, satellite anti-theft system, etc.) or accessories that burden the electrical supply, contact your authorized dealer, whose personnel will check whether the vehicles's electrical system is able to withstand the load required , or whether it needs to be integrated with a more powerful battery.
Page 7 RADIO TRANSMITTERS AND MOBILE PHONES Radio transmitter equipment (vehicle mobile phones, CB radios, amateur radio etc.) cannot be used inside the vehicle unless a separate aerial is mounted externally. Transmission and reception of these devices may be affected by the shielding effect of the vehicle body. As far as the use of EC-approved mobile phones is concerned (GSM, GPRS, UMTS, LTE), follow the usage instructions provided by the mobile phone Manufacturer.
Page 8 This page is intentionally left blank...
Page 9 GRAPHICAL TABLE OF CONTENTS GETTING TO KNOW YOUR VEHICLE GETTING TO KNOW YOUR INSTRUMENT PANEL SAFETY STARTING AND OPERATING IN CASE OF EMERGENCY SERVICING AND MAINTENANCE TECHNICAL SPECIFICATIONS CUSTOMER ASSISTANCE INDEX...
Page 10 This page is intentionally left blank...
Page 11 GRAPHICAL TABLE OF CONTENTS FRONT VIEW 01020304-000-100 Front View 1 — Engine Compartment 3 — Doors 5 — Exterior Lights 2 — Windshield Wiper Blades 4 — Wheels And Tires...
Page 12 REAR VIEW 01020304-001-100 Rear View Rear View 1 — Outside Mirrors 3 — Antenna 5 — Exterior Lights 2 — Convertible Top (Soft Top) 4 — Trunk Lid 6 — Fuel Door...
Page 13 INSTRUMENT PANEL 02010200-129-555 Instrument Panel Instrument Panel 1 — Turn Signal/High Beams Lever 4 — Hazard Warning Lights Button 7 — Driver Air Bag 2 — Instrument Cluster 5 — Passenger Air Bag 8 — Control Buttons 3 — Windshield Wiper And Washers 6 —...
Page 14 INTERIOR OVERVIEW 01020304-002-100 Interior Overview INTERIOR OVERVIEW 1 — Steering Wheel 4 — Climate Control System 7 — Radio Control 2 — Rearview Mirror 5 — Transmission Gear Selector 8 — Seats 3 — Radio Systems 6 — Parking Brake...
Page 15: Table Of Contents
GETTING TO KNOW YOUR VEHICLE KEYS ....14 IGNITION SWITCH ... .20 ADVANCED KEYLESS ENTRY SYSTEM —...
Page 16: Keys
KEYS To use the Emergency Key, push the Do not leave children or animals inside mechanical latch on the back side of parked vehicles in hot weather. Interior Key Fob the key fob and pull out the emergency heat build-up may cause serious injury or key.
Page 17 Note: Key Fob Buttons Not operating the key fob for ten seconds. The doors, trunk lid, and fuel filler Lock Button door will lock, and the beep will Pushing any button except the To lock the doors, trunk lid, and fuel activate at the current volume (if the unlock button on the key fob.
Page 18 Operational Range Note: The engine may not start if the Replacing The Key Fob Battery key fob is placed in or around the Proceed as follows: The system operates only when the following areas: driver is in the vehicle or within 1.
Page 19 2. Insert a coin, a flat blade screw Note: Be careful not to allow the driver, or the tip of your emergency key rubber ring shown in call-out (6) to be into the now exposed slot and carefully scratched or damaged. If the rubber pry in the direction of the arrows to ring comes out, reinstall it before open the cover (3) slightly.
Page 20 Contact with devices for electronic 2. Manual Transmission: Continue to The engine cannot be started unless purchases or security passage touch. depress the clutch pedal firmly until the the clutch pedal is fully depressed engine has completely started. (manual transmission) or the brake pedal is fully depressed (automatic 3.
Page 21 Emergency Operation For Starting Non-FCA genuine electronic General Information The Engine equipment is installed in the vehicle. The following regulatory statement If the key warning light (red) illuminates, There is equipment which discharges applies to all radio frequency (RF) or the keyless ignition start indicator radio waves near the vehicle.
Page 22: Ignition Switch
IGNITION SWITCH START/STOP button without depressing Some indicator lights/warning lights the clutch or brake pedal. should be inspected before the engine Push Button Start is started. Do not leave the ignition in the ON Positions When the keyless ignition has been position while the engine is not The system operates only when the key placed in the ON position, the sound of...
Page 23: Advanced Keyless Entry System - If Equipped
ADVANCED Key Fob Left-In-Trunk Warning Beep Be sure the parking brake is fully KEYLESS ENTRY disengaged before driving; failure to do so Key Fob Left-In-Vehicle Warning SYSTEM — IF can lead to brake failure and a collision. Beep EQUIPPED Always fully apply the parking brake If you have a problem with the key fob, when leaving your vehicle, or it may roll Advanced Keyless Entry...
Page 24 Battery life is about one year. deactivated, you will be unable to start Locking/Unlocking The Doors And Replace the battery with a new one if the engine by carrying the key fob. The Trunk Lid Warning light (green) flashes in Contact an authorized dealer for the instrument cluster.
Page 25: Vehicle Security Alarm System - If Equipped
VEHICLE SECURITY Opening The Trunk Lid General Information ALARM SYSTEM — IF The following regulatory statement EQUIPPED applies to all radio frequency (RF) devices equipped in this vehicle: Modifications And This device complies with Part 15 of the Add-On Equipment FCC Rules and with Industry Canada FCA cannot guarantee the immobilizer license-exempt RSS standard(s).
Page 26 To avoid damage to the key fob, do not: If you lose a key fob, an authorized Disarming dealer will reset the electronic codes of The system is disarmed when the Drop the key fob. your remaining key fobs and ignition is placed in the ON position with Get the key fob wet.
Page 27 Vehicle Security Alarm The trunk lid will not open when the The system will disarm if one of the System — If Equipped vehicle security alarm system is following operations takes place within activated. 20 seconds after pushing the lock If the security alarm system detects an button: To rearm the system, perform If the battery becomes drained while...
Page 28: Doors
DOORS To Turn Off An Armed System An armed system can be turned off Lock/Unlock With using any one of the following methods: Emergency Key Pushing the unlock button on the key The doors, trunk lid, and fuel door lock fob.
Page 29 Central Lock/Unlock Double Locking System — If Equipped Warning! The doors, trunk lid, and fuel door lock automatically when the lock rocker The double locking system is designed switch is pushed with both doors to prevent someone who has broken For personal security and safety in the closed.
Page 30 5. The indicator light illuminates for Lock/Unlock With To unlock both doors and fuel filler door, about three seconds to indicate that the Advanced Keyless Entry push the button on the exterior door Function — If Equipped system has been activated. handle twice within three seconds.
Page 31 A beep sound is heard for confirmation Not operating the key fob for ten If you are out of the operational range when the doors, and fuel filler door are seconds. before the doors and trunk lid are closed locked/unlocked using the request or another key fob is left in the vehicle, the Pushing any button except the lock switch on the exterior door handle.
Page 32 Locking/Unlocking With Door-Lock Auto Lock/Unlock Auto Lock/Unlock Function Setting Switch Function — If Equipped Change Using Door-Lock Switch (With Door-Lock Switch) Both doors and the fuel filler door lock When the vehicle speed exceeds automatically when the lock side is The doors and fuel filler door can be set 12 MPH (20 km/h), the doors, and fuel pushed.
Page 33 Function Number Function (*) The auto door-lock function is disabled. The doors and the fuel filler door lock automatically when the vehicle speed is about 12 MPH (20 km/h) or more. The doors and the fuel filler door lock automatically when the vehicle speed is about 12 MPH (20 km/h) or more.
Page 34: Seats
SEATS Automatic Transmission Vehicles vehicle receives an impact strong enough to inflate the air bags, both the The doors cannot be locked or Manual Adjustment doors, the trunk lid, and fuel filler door unlocked while the setting function is are automatically unlocked after about Forward / Rearward being performed.
Page 35 Seat Recline Heated Seats Use the seat warmer when the engine is running. Leaving the seat To recline the seatback, lift up the On some models, the front driver and warmer on for long periods with the recline lever and lean back until the passenger seats may be equipped with engine not running could discharge the desired position has been reached,...
Page 36: Non-Adjustable Head Restraints
NON-ADJUSTABLE Driver And Passenger Head Restraints HEAD RESTRAINTS Warning! Your vehicle is equipped with The non-adjustable head restraints are non-adjustable head restraints on the form fitted into the upper structure of Persons who are unable to feel pain to driver's and passenger's seatbacks. the seatback, and are designed to the skin because of advanced age, chronic reduce the risk of injury by restricting...
Page 37: Steering Wheel
STEERING WHEEL MIRRORS Steering Wheel Outside Mirrors Adjustment Be sure that all inside and outside To change the angle of the steering mirrors are adjusted to the desired wheel: position prior to driving the vehicle. Mirror Types: 1. With the gear selector in the PARK position, pull the lock release lever, Flat Type (Driver Side): flat surface located under the steering column,...
Page 38 Inside Day / Night Mirror Rear View Mirror Adjustment Before driving, adjust the rear view mirror to center on the view through the rear window. 04060102-MAN-002 04060102-36E-666 Mirror Adjustment Lever Automatic Dimming Mirror Buttons 1 — Mirror Adjustment Lever 1 — Off A —...
Page 39 Push the off button ( O ) to cancel the Power Mirrors Folding Mirrors automatic dimming function. The The ignition must be in the ACC or ON Manually fold the outside mirror indicator light will turn off. position to adjust the outside power rearward until it is flush with the vehicle.
Page 40: Exterior Lights
EXTERIOR LIGHTS Heated Mirrors — If Equipped Headlights These mirrors are Rotate the headlight switch to heated to melt frost or activate/deactivate the headlights, other ice. This feature will be exterior lights and dashboard activated whenever illumination. you push the Rear When the lights are turned on, the Window Defrost button.
Page 41 Headlight Operation Without Auto-Light Control Switch Position Daytime Running Lights High Beams Ignition Position ACC Or OFF ACC Or OFF ACC Or OFF Headlights Daytime Running Lights Tail Lights / Position Lights / License Plate Lights / Instrument Panel Illumination (*) If the driver's door is opened, or 30 seconds have elapsed with the lights turned on, the lights turn off.
Page 42 Daytime Running Lights Automatic Lighting damaged when the wipers activate (DRL) automatically. If you are going to clean When the headlight switch is in the the windshield, be sure the wipers are The daytime running lights turn on AUTO position and the ignition is cycled turned off completely when the engine automatically when the vehicle starts ON, the light sensor will detect the...
Page 43 Follow Me Home With Auto-Light Control When the fog light switch is in the The Follow Me Home Light System position and the headlight switch is turns on the headlights (low beams) for in AUTO position, the front fog lights will a period of time after the ignition is stay on.
Page 44 Lane Change Assist Leaving Home Light Headlamp Leveling System System — If Equipped Move the lever halfway toward the direction of the lane change (until the The Leaving Home Light System turns On some models, the angle of the indicator flashes) and hold it there. It will the headlights on when the unlock headlights will be automatically adjusted return to the off position when released.
Page 45: Windshield Wipers / Washer
WINDSHIELD OFF: stop When the wiper lever is in the AUTO position and the ignition is cycled ON, WIPERS / WASHER AUTO: auto control operation the wipers may move automatically in Windshield Wipers And — or LO: low speed operation the following cases: Washer = or HI: high speed operation...
Page 46: Climate Control System
CLIMATE CONTROL If the windshield is coated with water With the wiper lever in the OFF, repellent, the rain sensor may not be intermittent, or AUTO position, the SYSTEM able to sense the amount of rainfall wipers will operate continuously until Operating Tips correctly and auto-wiper control may the lever is released.
Page 47 specifications are indicated on a label (A Vent Operation or B depending on the market) Adjusting The Vents attached to the inside of the engine To adjust the direction of air flow, move compartment. Check the label before the vent adjustment knob. refilling the refrigerant.
Page 48 Center Vents (Front Passenger) Center vents are located on the dashboard. Air vent open/close: use the Center Vent tab 1 to open/close the center vents (A = open / B = close). Air flow direction adjustment: use the Center Vent tab 1 to adjust the center vents to the desired position.
Page 49 Airflow Mode 06010202-121-002 Airflow Locations 1 — Fixed Upper Air Diffuser 2 — Adjustable Side Air Vents 3 — Adjustable Center Air Vent 4 — Floor Vents...
Page 50 Manual Climate Control System With MAX A/C function 06010300-122-002 Manual Climate Controls With MAX A/C 1 — Temperature Control Knob 4 — Rear Window Defrost Button 2 — Blower Control Knob 5 — Air Recirculation Button 3 — Mode Selector Knob 6 —...
Page 51 Controls flow from the floor vents is less than Note: that of the position. 1 – Temperature Control Knob Before opening the convertible top, 4 – Rear Window Defrost Button make sure the Rear Window Defrost This dial controls the interior Button is turned off.
Page 52 Note: Do not use the Outside Air If the windshield fogs up easily, set the Note: Position in cold or rainy weather is Mode Selector Knob to the position. If the air conditioner is used while dangerous as it will cause the windows If cooler air is desired at face level, set driving up large hills or in heavy traffic, to fog up.
Page 53 Ventilation Dehumidifying (With Air Conditioner) Proceed as follows: Warning! Operate the air conditioner in cool or 1. Set the Mode Selector Knob to the cold weather to help defog the position. Set the temperature control to the hot or windshield and side windows. warm position when defogging (Front 2.
Page 54 Automatic Climate Control System 06010900-122-999 Automatic Climate Controls — Type A 1 — Temperature Control Knob 4 — Rear Window Defrost Button 2 — Blower Control Knob 5 — Air Recirculation Button 3 — Mode Selector Knob 6 — A/C Button...
Page 55 06010900122 Automatic Climate Controls — Type B 1 — Temperature Control Knob 4 — Rear Window Defrost Button 2 — Blower Control Knob 5 — Air Recirculation Button 3 — Mode Selector Knob 6 — A/C Button...
Page 56 Controls Note: 1 – Temperature Control Knob With the air flow mode set to the Caution! position, and the Temperature This knob controls internal temperature Control Knob is set to a medium of the vehicle. Turn it clockwise for Failure to follow these cautions can cause temperature, the floor vents will blow hotter temperatures and damage to the heating elements:...
Page 57 5 – Air Recirculation Button Operation Of Automatic Windshield Defrosting Air Conditioning And Defogging Press the Air Recirculation Button to select between outside air and Proceed as follows: Set the mode selector knob to the recirculated air positions. position and turn the blower control 1.
Page 58: Power Windows
POWER WINDOWS Power Window Controls The ignition must be placed in the ON position for the power windows to operate. A power window may no longer open/close if you continue to push the switch after opening/closing the power window. If the power window does not 04070103-LN2-002 06010904333003 Power Window Switches...
Page 59 Auto-Opening Power Windows 3. Make sure that the power window Engine-Off Power Window lock switch located on the driver's door Operation To fully open the window automatically is not depressed. push the switch completely down. The power window can be operated for To stop the window partway pull or about 40 seconds after the ignition has 4.
Page 60: Convertible Top (Soft Top)
CONVERTIBLE TOP Power Window Lock Switch (SOFT TOP) This feature prevents the passengers Lowering The power window from operating. Keep Convertible Top this switch in the locked position while children are in the vehicle. Warning! 1. Locked Position (Button Pushed): only the driver's power window can be operated.
Page 61 5. Remove the striker from the anchor. 6. Standing outside of the vehicle, hold the convertible top along the front edge and pull it toward the rear of the vehicle. To lower the convertible top from inside the vehicle, use the convertible top handles.
Page 62 Raising The Convertible To raise the convertible top, proceed as follows: 1. Make sure the parking brake is applied and the engine is OFF. 2. Pull the unlock lever upward to disengage the lock. 04110103-L23-002 Convertible Handle Location 2 — Convertible Top Handles 4.
Page 63 The convertible top may be The soft top is made of high quality constricted if it is left retracted for a material and if it is not maintained long period. Therefore, if the top has correctly, the material could harden, become constricted, it may be difficult becomes stained, or have an uneven to hook the top latch striker to the...
Page 64: Hood
HOOD Caution! Opening The Hood To open the hood, proceed as follows: Before opening the convertible top, 1. With the vehicle in PARK, pull the make sure the rear window defroster release handle located to the left of the switch is turned off. Otherwise the heat steering wheel, below the instrument generated from the window defroster panel.
Page 65: Trunk Lid
TRUNK LID 4. Verify that the support rod is secured in the clip before closing the Opening hood. 5. Lower the hood slowly to a height of Warning! about 8 inches (20 cm) above its closed position and then let it drop. Before opening the trunk lid, remove any snow and ice accumulation on it.
Page 66 Using The Remote Release Button Using The Electric Trunk Lid With The Advanced Keyless Entry — If Equipped Opener Function With the remote release button, the A locked trunk lid can also be opened trunk lid can also be opened while the while the key fob is being carried.
Page 67 When Trunk Lid Cannot Note: Do not pull the screw when Be Opened pulling the cap. Otherwise, the screw may fall off and become lost. If the battery is discharged, the trunk lid Refer to “Trunk Emergency Release” cannot be unlocked and opened. located in “Getting To Know Your If the trunk lid cannot be unlocked even Vehicle”...
Page 68: Trunk Emergency Release
TRUNK EMERGENCY HOMELINK — IF Trunk Safety Warning RELEASE EQUIPPED Warning! As a security measure, a emergency General Information release lever is built into the rear tail The HomeLink system replaces up to panel of the trunk. In the event of an Do not allow children to have access to the three hand-held transmitters with a adult or child being locked inside the...
Page 69 Proceed as follows: 1. Verify that there is a remote control Warning! transmitter available for the device you would like to program. Vehicle exhaust contains carbon 2. Disconnect the power to the device. monoxide, a dangerous gas. Do not run Programming The your vehicle in the garage while System...
Page 70 Note: To program the remaining two For questions or comments, please Operating The System HomeLink buttons, begin with step contact HomeLink at Push the programmed HomeLink one. www.homelink.com or button to operate a programmed 1-800-355-3515. 7. If the indicator light blinks rapidly for device.
Page 71: Internal Equipment
INTERNAL Insert the emergency key in the lock and turn it clockwise to lock, counter EQUIPMENT clockwise to unlock. Storage Compartments Note: When using the rear console cup Center Console holders, remove any cups before opening the seat side compartment. If the seat The center console is located between side compartment is opened with a cup the driver’s and passenger’s seats.
Page 72 To use the back trim storage Interior Lights compartment, slide the seat all the way Overhead Light forward and fold the seat back forward, The interior light is located in the then open the compartment. headliner in between the sun visors. When finished, close the compartment The interior light can be set to three and return the seat to its original...
Page 73 Trunk Light Turns on for about five seconds advanced keyless function) after the when a door is opened from the outside ignition is cycled OFF. The trunk light comes on when the lid is with a key fob being carried and then open and turns off when closed.
Page 74 The ignition must be placed in ACC or Depending on the device connected Cupholders — If to the accessory socket, the vehicle's Equipped electrical system may be affected, To prevent accessory socket damage Cupholders are available and can be which could cause the warning light to or electrical failure, pay attention to the inserted in the center console on the illuminate.
Page 75 Installing Cupholders When installing a cupholder, insert it Caution! firmly into the installation hole and make sure that it is secured in place. Do not place plastic bottles without caps in the cup holders. Otherwise, the contents may spill while the vehicle is being driven.
Page 76: Electric Power Steering
ELECTRIC POWER ENVIRONMENT Windblocker STEERING PROTECTION The Windblocker reduces rear wind SYSTEMS coming into the cabin while driving with Power Steering the convertible top in the lowered Emission Control System Electric power steering is only operable position. This vehicle is equipped with an when the engine is running.
Page 77 Under U.S. federal law, any modification to the original-equipment emission control system before the first sale and registration of a vehicle is subject to penalties. In some states, such modification made on a used vehicle is also subject to penalties. While the engine is off, the sound of a valve opening and closing can be heard at the rear of the vehicle, however this...
Page 78 This page is intentionally left blank...
Page 79 GETTING TO KNOW YOUR INSTRUMENT PANEL CONTROL PANEL AND INSTRUMENTS ....78 MAINTENANCE MONITOR — IF EQUIPPED ....84 FUEL ECONOMY MONITOR —...
Page 80: Control Panel And Instruments
CONTROL PANEL AND INSTRUMENTS Instrument Cluster 05020100-667-333 Instrument Cluster 1 — Odometer/Trip Computer And Trip Computer Button/Dashboard Illumination 2 — Tachometer 3 — Speedometer 4 — Automatic Transmission Info Display 5 — Odometer/Trip Computer Info/Engine Coolant Temperature Gauge/Fuel Gauge/Outside Temperature/Cruise Control/Info Switch Display...
Page 81 Odometer/Trip Computer When “Trip A” is selected, pushing the illumination is dimmed. When the selector again within one second will position lights are turned on, the change to “Trip B” mode. When “Trip A” warning light in the instrument The display mode can be changed from is selected, TRIP A will be displayed.
Page 82 Canceling Illumination Dimmer Note: With the ignition ON, rotate the knob to Even though the distance-to-empty the right until a beep sounds while the display may indicate a sufficient instrument cluster is dimmed. If the amount of remaining driving distance instrument cluster's visibility is reduced before refueling is required, refuel as due to glare from surrounding...
Page 83 Average Fuel Economy Mode This mode displays the average fuel economy by calculating the total fuel consumption and the total traveled distance since purchasing the vehicle, reconnecting the battery after disconnection, or resetting the data. The average fuel economy is calculated and displayed every minute.
Page 84 Note: Always set the vehicle speed Tachometer Engine Coolant according to the laws and regulations of Temperature Gauge And The tachometer shows engine speed in Fuel Gauge the country/city in which the vehicle is thousands of revolutions per minute driven. In addition, always verify the (rpm).
Page 85 Celsius using the following procedure. The fuel gauge shows approximately how much fuel is remaining in the tank Vehicles With Fiat Connect 7.0 when the ignition is in the ON position. Settings can be changed through the We recommend keeping the tank over Connect 7.0 radio screen.
Page 86: Maintenance Monitor - If Equipped
The vehicle is stopped Oil Life Reset The vehicle is put in neutral Vehicles With Fiat Radio 3.0 “Oil Change” with flexible settings are The vehicle is driven in reverse available. Consult an authorized dealer The clutch is not fully engaged when for details.
Page 87 Reset Method Oil Life Reset Your vehicle is equipped with an engine Vehicles With FIAT Connect oil change indicator system. The “Oil 7.0 Radio Change Required” message will flash in Proceed as follows: the instrument cluster display for approximately ten seconds after a 1.
Page 88 Oil Life Monitor You can customize settings in the setup display as follows: Item Explanation Setting Notification can be turned on/off. Displays the time or distance until maintenance is due. Select this item to set Time (months) the maintenance period. “Scheduled Due!” is displayed in red, and the indicator light will illuminate in the instrument cluster when the Scheduled...
Page 89 Item Explanation Setting Notification can be switched on/off. Displays the distance until an oil change is due. Select this item to set the oil change distance. “Oil Change Due!” is displayed in Distance (mile or km) red, and the indicator light will illuminate in the instrument cluster when the remaining distance is less than 300 mi (500 km).
Page 90: Fuel Economy Monitor - If Equipped
FUEL ECONOMY 4. Displays the following setting 3. Calculates the average fuel screen: ending display on/off switching economy every minute after vehicle MONITOR — IF - On/off switching for function which travel begins, and displays it. EQUIPPED synchronizes reset fuel economy data Description to trip meter (Trip A).
Page 91: Warning Lights And Messages
WARNING LIGHTS Ending Screen Display Vehicles With Fiat Connect 7.0 AND MESSAGES The warning contents can be verified If the ending display on the fuel on the audio system. economy monitor is on when the Warning Lights And Proceed as follows:...
Page 92 Engine Oil Warning Light KEY Warning Light Electric Throttle Warning Light LED Headlight KEY Warning Light Cold Start Warning Light BSM (Blind Spot Monitoring) OFF Indicator Light Check Engine Warning Light TCS/DSC Indicator Light Coolant Temperature Warning Light DSC OFF Indicator Light Automatic Transmission Warning Light Security Indicator Light...
Page 93 Red Warning Lights Warning Light What It Means Parking Brake Warning - Warning Light Inspection/Low Brake Fluid Level Warning Parking Brake Warning / Warning Light Inspection The light illuminates when the parking brake is applied with the ignition switched to START or ON.
Page 94 Warning Light What It Means Alternator Failure If the warning light illuminates while driving, it indicates a malfunction of the alternator or of the charging system. Drive to the side of the road and park off the right-of-way. Stop the vehicle in a safe place immediately and contact an authorized dealer.
Page 95 Red Warning Lights Warning Light What It Means High Engine Coolant Temperature Warning Light The light flashes when the engine coolant temperature is extremely high, and illuminates when the engine coolant temperature increases further. Handling Procedure Flashing Light: drive slowly to reduce engine load until you can find a safe place to stop the vehicle and wait for the engine to cool down.
Page 96 Red Warning Lights Warning Light What It Means Key Warning Light — Illuminated If any malfunction occurs in the keyless entry system, it illuminates continuously. Note: If the key warning indicator light illuminates or the push button start indicator light (amber) flashes, the engine may not start.
Page 97 Amber Warning Lights Warning Light What It Means ABS Warning Light If the ABS warning light stays on while you're driving, when the ABS control unit has detected a system malfunction. If this occurs, your brakes will function normally as if the vehicle had no ABS.
Page 98 Warning! A malfunctioning catalytic converter, as referenced above, can reach higher temperatures than in normal operating conditions. This can cause a fire if you drive slowly or park over flammable substances such as dry plants, wood, cardboard, etc. This could result in death or serious injury to the driver, occupants or others.
Page 99 Amber Warning Lights Warning Light What It Means TPMS (Tire Pressure Monitoring System) Warning Light — If Equipped The warning light switches on and a message is displayed to indicate that the tire pressure is lower than the recommended value and/or that slow pressure loss is occurring. In these cases, optimal tire duration and fuel consumption may not be guaranteed.
Page 100 Caution! The TPMS has been optimized for the original equipment tires and wheels. TPMS pressures and warning have been established for the tire size equipped on your vehicle. Undesirable system operation or sensor damage may result when using replacement equipment that is not of the same size, type, and/or style.
Page 101 Contact an authorized dealer as soon as possible. Master Warning Light Vehicles Equipped With Fiat Connect 3.0 System The warning light turns on continuously if there is a malfunction in the battery management system or there is a malfunction in the brake switch. Contact an authorized dealer as soon as possible.
Page 102 Warning Light What It Means Electric Throttle Control Warning Light This light informs you of a problem with the Electronic Throttle Control (ETC) system. If a problem is detected while the engine is running, the light will either stay on or flash depending on the nature of the problem.
Page 103 Warning Lights What It Means Low Fuel Warning Light The light turns on when the remaining fuel is about 2.3 gallons (9.0 liters). The light illumination timing may vary because fuel inside the fuel tank moves around according to the driving conditions and the vehicle posture. Add fuel. Low Washer Fluid Level Warning Light —...
Page 104 Green Warning Lights Warning Light What It Means Left Direction Indicator The warning light turns on when the direction indicator control lever is moved downwards or, together with the right direction indicator, when the hazard warning light button is pushed. Right Direction Indicator The warning light turns on when the direction indicator control lever is moved upwards or, together with the left direction indicator, when the hazard warning light button is pushed.
Page 105 Blue Warning Light Warning Light What It Means High Beam Headlights The warning light switches on when the high beam headlights are turned on. Low Engine Coolant Temperature Indicator Light The light illuminates continuously when the engine coolant temperature is low and turns off after the engine is warm.
Page 106 Warning Light (Red Color) On Dashboard Trim Warning Light What It Means Seat Belt Warning Light The seat belt warning light turns on if the driver or passengers seat is occupied and the seat belt is not fastened with the ignition placed in the ON position. If the driver or passengers seat belt is unfastened (only when the passenger seat is occupied) and the vehicle is driven at a speed faster than about 12 MPH (20 km/h), the warning light flashes.
Page 107 Message Indicated On Warning Sound Is Display — If Equipped Activated Caution! With Fiat Connect Lights-On Reminder 7.0 System If lights are on and the ignition is placed Do not drive the vehicle with the air If a message is displayed in the center...
Page 108 Note: Vehicles Without Advanced Keyless To allow the front passenger seat weight Function sensor to function properly, do not place To allow the passenger occupant and sit on an additional seat cushion on If the key is taken out of the vehicle classification sensor to function the front passenger seat.
Page 109 If this happens, open the trunk lid by Vehicle Speed Alarm — If Equipped Blind Spot Monitoring (BSM) pushing the electric trunk lid opener System Warning Beep — If The vehicle speed alarm function is and remove the key fob. Equipped designed to alarm the driver via a single A key fob removed from the trunk may...
Page 110: Personalization Features
E: Refer to “Lock/Unlock With A: Refer to the “Settings” paragraph The following Personalization Features Request Switch (With The Advanced in Fiat Connect 7.0 Supplement for can be set or changed by the customer Keyless Function)” (Doors) in “Getting further information.
Page 111 Settings Change Method Item Feature Factory Setting Available Settings Vehicle Lock: When Driving/Unlock: In Park/Lock: Out of Lock: When Park Unlock: In Operation condition of Door Locks Driving/Unlock: IGN Park/Lock: Shifting auto lock/unlock function Out of Park/ Lock: When Driving Unlock: IGN Off/ Lock: When Driving/Off Keyless...
Page 112 Settings Change Method Item Feature Factory Setting Available Settings Daytime Operational/non- Running On/Off — — operational Lights (DRL) 120 seconds/ Auto Time until headlights turn 90 seconds/ headlight off 30 second — 60 seconds/ (***) 30 seconds/Off (****) High/Med. Auto-Light Timing by which lights Medium High/Medium/Med.
Page 113 Settings Change Method Item Feature Factory Setting Available Settings System Language indicated in Depends on market Language English — display (****) Temperature unit Temperature °C °F/°C — indicated in display Distance unit indicated in Distance mi or km mi/km — display Fuel Economy Monitor Ending...
Page 114: Onboard Diagnostic System - Obd Ii
ONBOARD DIAGNOSTIC Caution! Warning! SYSTEM — OBD II Your vehicle is equipped with a ONLY an authorized service technician Prolonged driving with the MIL on could sophisticated Onboard Diagnostic should connect equipment to the OBD II cause further damage to the emission system called OBD II.
Page 115: Emissions Inspection And Maintenance Programs
EMISSIONS Your vehicle has a simple ignition The MIL will not flash at all and will actuated test, which you can use prior remain fully illuminated until you place INSPECTION AND to going to the test station. To check if the ignition in the off position or start MAINTENANCE your vehicle's OBD II system is ready,...
Page 116 This page is intentionally left blank...
Page 117 SAFETY SAFETY SYSTEMS ...116 AUXILIARY DRIVING SYSTEMS . .118 OCCUPANT RESTRAINT SYSTEMS ....125 SEAT BELT SYSTEMS ..126 CHILD RESTRAINT PRECAUTIONS .
Page 118: Safety Systems
SAFETY SYSTEMS conditions because the tires will build The capabilities of an ABS equipped up a wedge of surface layer when the vehicle must never be exploited in a The vehicle has the following safety wheels skid. reckless or dangerous manner that could systems: jeopardize the user’s safety or the safety of The sound of the ABS operating...
Page 119 TCS / DSC Indicator Light DSC operation is possible at speeds DSC OFF Indicator Light greater than 12 mph (20 km/h). indicator light stays on for a few indicator light stays on for a few seconds when the ignition is placed in The indicator light turns on when the seconds when the ignition is placed in the ON mode.
Page 120: Auxiliary Driving Systems
AUXILIARY DRIVING Note: Vehicle modifications, or failure to SYSTEMS properly maintain your vehicle, may When DSC is on and you attempt change the handling characteristics of your to free the vehicle when it is stuck, or Blind Spot Monitoring vehicle, and may negatively affect the drive it out of freshly fallen snow, the (BSM) System performance of the DSC system.
Page 121 The detection area on this system The BSM switch is pushed and the The battery voltage has decreased. covers the driving lanes on both sides warning light in the instrument cluster is If the warning light in the instrument of the vehicle and from the rear part of turned off.
Page 122 Driving on steep inclines. In the following cases, it may be difficult Forward Driving (BSM System to view the illumination/flashing of the Operation) Crossing the summit of a hill or BSM warning lights equipped on the The BSM system detects vehicles mountain pass.
Page 123 BSM Warning Beep The BSM and RCTA systems are turned off when the battery is The BSM audible alert is activated disconnected such as when the simultaneously with the flashing of a battery terminals or fuses have been BSM warning light. removed and reinstalled.
Page 124 With Rear View Camera In the following cases, the BSM off Note: Under the following conditions, indicator light turns on and operation of the rear radar sensors cannot detect The Rear Cross Traffic Alert (RCTA) the system is deactivated. If the BSM objects or it may be difficult to detect warning indication in the rearview off indicator light in the instrument...
Page 125 General Information The following regulatory statement applies to all Radio Frequency (RF) devices equipped in this vehicle: This device complies with Part 15 of the FCC Rules and with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: 1.
Page 126 TPMS (Tire Pressure level of tire wear is excessively different Tire Pressure Monitoring System Monitoring System) between them. Initialization In the following cases, system Tire Pressure Monitoring System — A run-flat tire, snow tire, or tire chains initialization must be performed so that Lo/Hi Grade are used.
Page 127: Occupant Restraint Systems
OCCUPANT General Information RESTRAINT The following regulatory statement SYSTEMS applies to all radio frequency (RF) devices equipped in this vehicle: The most important safety equipment of the vehicle comprise the following This device complies with Part 15 of the protection systems: FCC Rules and with Industry Canada license-exempt RSS standard(s).
Page 128: Seat Belt Systems
SEAT BELT Except Mexico SYSTEMS All of the seat belt retractors are designed to keep the lap/shoulder belts Buckle up even though you are an out of the way when not in use. excellent driver, even on short trips. The driver's seat belt has no provisions Someone on the road may be a poor for child-restraint systems and has only driver and could cause a collision that...
Page 129 Important Safety Be sure everyone in your vehicle is in a A seat belt that is buckled into the Precautions seat and using a seat belt properly. wrong buckle will not protect you properly. Occupants, including the driver, should The lap portion could ride too high on your Please pay close attention to the always wear their seat belts whether or not body, possibly causing internal injuries.
Page 130 6. All occupants should always wear Seat Belts And Pregnant Emergency Locking their lap and shoulder belts properly. Women Mode Pregnant Women And Persons With When the seat belt is fastened, it will 7. The driver and front passenger seats Serious Medical Conditions always be in the emergency locking should be moved back as far as...
Page 131 Automatic Locking Mode Position the lap belt as low as possible, Failure to replace the seat belt assembly not on the abdominal area 2, then Always use the automatic locking mode could increase the risk of injury in adjust the shoulder belt 3 so that it fits to keep the child-restraint system from collisions.
Page 132 Unfastening The Seat Belt If the driver or passenger's seat belt is unfastened (only when the passenger Depress the button on the seat belt seat is occupied) and the vehicle is buckle. If the belt does not fully retract, driven at a speed faster than about pull it out and check for kinks or twists.
Page 133: Child Restraint Precautions
CHILD RESTRAINT The seat belt retractors remove slack Load Limiter quickly as the air bags are expanding. PRECAUTIONS The load limiting system releases belt Any time the air bags and seat belt webbing in a controlled manner to Child Restraints pretensioners have fired they must be reduce belt force on the occupant's replaced.
Page 134 Whatever child-restraint system you With Passenger Occupant consider, please pick the appropriate Classification System Warning! one for the age and size of the child, To reduce the chance of injuries caused obey the law and follow the instructions by deployment of the passenger Air that come with the individual Bag, the Passenger Occupant Improper installation can lead to failure...
Page 135 Child Restraint System Note: Types For additional information, refer to Warning! In this Owner’s Manual, explanation of www.nhtsa.gov/parents-and-caregivers child restraint systems secured with seat or call: 1–888–327–4236 belts is provided for the following three Never place a rear-facing child restraint Canadian residents should refer to types of popular child-restraint systems: in front of an air bag.
Page 136 Booster Seat Child Seat Installation Place the child-restraint system on Position the seat without putting your weight on A booster seat is a child restraint the seat and secure the child-restraint accessory designed to improve the fit of The passenger lap/shoulder belt can system with the lap portion of the the seat belt system around the child's easily be converted into the automatic...
Page 137: Supplementary Restraint System Srs - Air Bag
SUPPLEMENTARY Place the ignition in ON mode and make sure the passenger air bag RESTRAINT SYSTEM Warning! deactivation indicator light illuminates SRS — AIR BAG after installing a child restraint system Description on the passenger seat. If the passenger Never place a rear-facing child restraint air bag deactivation indicator light does The front and side Supplementary in front of an air bag.
Page 138 Without seat belt usage, the Air Bags cannot provide adequate protection Warning! during an accident. Seat belt usage is necessary to: If the Indicator Light remains illuminated Keep the occupant from being for an adult passenger, have an authorized thrown into an inflating Air Bag. dealer service the air bag system immediately.
Page 139 Warning! Unapproved modifications or service procedures to the passenger seat assembly, its related components, seat cover or cushion may inadvertently change the air bag deployment in case of a frontal collision. This could result in death or serious injury to the front passenger if the vehicle is involved in a collision.
Page 140 Supplementary Restraint System Components With Passenger Occupant Classification System 03040300-121-002 With Passenger Occupant Classification System 1 — Driver/Passenger Inflators And Air 5 — Side Crash Sensors 9 — Passenger Occupant Bags Classification Sensor 2 — Crash Sensors And Diagnostic 6 — Air Bag/Seat Belt Pretensioner 10 —...
Page 141 Without Passenger Occupant Classification System 03040300-122-003 Without Passenger Occupant Classification System 1 — Driver/Passenger Inflators And Air 4 — Front Air Bag Sensors 7 — Side Inflators And Air Bags Bags 2 — Crash Sensors And Diagnostic 5 — Side Crash Sensors Module (Sas Unit) 3 —...
Page 142 How The SRS Air Bags refer to "SRS Air Bag Deployment Never place a rear-facing child restraint Work Criteria" in this chapter for further in front of an air bag. A deploying information. passenger front air bag can cause death This vehicle has front air bags and or serious injury to a child 12 years or (With Passenger Occupant...
Page 143 For further details about air bag door or window. For more details about deployment, refer to "SRS Air Bag air bag deployment, refer to "SRS Air Warning! Deployment Criteria" in this chapter. Bag Deployment Criteria" in this chapter for further information. Side Air Bags Side Air Bags need room to inflate.
Page 144 Always wear your seat belt and sit properly, with the seatback in an upright Warning! position, your back against the seatback, sitting upright, facing forward, in the center of the seat, with your feet comfortably on Ignoring the Air Bag Warning Light in your or near the floor.
Page 145 SRS Air Bag Deployment Criteria This chart indicates the applicable SRS equipment that will deploy depending on the type of collision (the illustrations are the representative cases of collisions). Deployed air bags and seat belt pretensioners cannot protect you in another collision. Have the air bags, seat belt pretensioners, and the seat belt retractor assemblies replaced by an authorized dealer immediately.
Page 146 (**) Passenger Occupant Classification System: the passenger front and side air bags and the seat belt pretensioner are designed to deploy when the passenger occupant classification sensor detects a passenger sitting on the passenger's seat. Note: In a frontal offset collision, the equipped air bags and pretensioners may all deploy depending on the direction, angle, and rate of impact.
Page 147 Limitations To SRS Air Limitations To Side Collision Detection Side collisions may not be detected as In severe collisions such as those severe enough to deploy the SRS air described in "SRS Air Bag Deployment bag equipment: Criteria" paragraph, the applicable SRS air bag equipment will deploy.
Page 148 This system shuts off the passenger front and side Air Bags and seat belt Warning! pretensioner system, so make sure the passenger Air Bag deactivation indicator light turns on. Ignoring the Air Bag Warning Light in your instrument panel could mean you The air bag/seat belt pretensioner won’t have the air bags to protect you in a system warning light flashes and the...
Page 149 Passenger Air Bag Deactivation Children 12 years or younger should Indicator Lights always ride buckled up in a vehicle with a These indicator lights turn on to remind rear seat. you that the passenger front and side Air Bags and seat belt pretensioner will Note: or will not deploy during a collision.
Page 150 If the passenger Air Bag If the passenger Air Bag Passenger Air Bag Deactivation deactivation indicator light does not deactivation indicator light turns on Indicator Light On/Off Condition turn on after installing a child restraint when an occupant is seated directly in Chart system on the passenger seat, first, the passenger seat, have the...
Page 151 Warning! Never place a rear-facing child restraint in front of an air bag. A deploying passenger front air bag can cause death or serious injury to a child 12 years or younger, including a child in a rear-facing child restraint. Never install a rear-facing child restraint in the front seat of a vehicle.
Page 152: Event Data Recorder (Edr)
EVENT DATA Maintaining Your Air Bag Note: System RECORDER (EDR) EDR data are recorded by your vehicle only if a non-trivial crash or near This vehicle is equipped with an event Warning! crash-like situation occurs; no data are data recorder (EDR). recorded by the EDR under normal The main purpose of an EDR is to driving conditions and no personal...
Page 153: Constant Monitoring
CONSTANT However, if necessary, FCA will: Information related to controls of other on-vehicle computers. MONITORING Use the data for research on FCA The recorded data may vary depending vehicle performance, including safety. The following components of the Air on the vehicle grade and optional Bag systems are monitored by a Disclose the data or the equipment.
Page 154 Enhanced Accident Cut off battery power to the: Enhanced Accident Response System Response System Reset – Engine Procedure In the event of an impact, if the – Electric Motor (if equipped) communication network remains intact, In order to reset the Enhanced Accident and the power remains intact, –...
Page 155 STARTING AND OPERATING STARTING THE ENGINE ..154 BRAKE SYSTEM ... .155 MANUAL TRANSMISSION ..157 AUTOMATIC TRANSMISSION — IF EQUIPPED ....158 SPEED CONTROL .
Page 156: Starting The Engine
STARTING THE Never press the accelerator pedal for 4. Place the start button in the ON starting the engine. mode, push and release it as soon as ENGINE the engine starts. If the engine does not Models Equipped With A Starting The Engine start within 10 seconds, push the start Manual Transmission...
Page 157: Brake System
BRAKE SYSTEM Extended Park Starting After Starting — Warming Up The Engine Note: Extended Park condition occurs This vehicle has power-assisted brakes when the vehicle has not been started Proceed as follows: that adjust automatically through or driven for at least 30 days. normal use.
Page 158 Driving a vehicle with the “Brake Do not leave the key fob in or near the Warning Light” on is dangerous. vehicle or in a location accessible to A significant decrease in braking children. A child could operate power performance or vehicle stability during windows, other controls, or move the braking may occur.
Page 159: Manual Transmission
MANUAL Brake Assist TRANSMISSION During emergency braking situations when it is necessary to depress the Manual Transmission brake pedal with greater force, the brake assist system provides braking assistance, thus enhancing braking Warning! performance. When the brake pedal is depressed hard or depressed more quickly, the brakes apply more firmly.
Page 160: Automatic Transmission - If
AUTOMATIC With Parking Sensor System When leaving the vehicle, always make TRANSMISSION — IF When the gear selector is shifted to the sure the ignition is in the OFF mode, EQUIPPED REVERSE (R) position with the ignition remove the key fob from the vehicle, and lock the vehicle.
Page 161 The gear selector must be in PARK (P) Note: Even if you intend to use the Gear Selector Positions or NEUTRAL (N) to operate the starter. automatic transmission functions as a PARK (P) traditional automatic, you should also The transmission gear selector has PARK (P) locks the transmission and be aware that you can inadvertently PARK (P), REVERSE (R), NEUTRAL (N),...
Page 162 NEUTRAL (N) Unintended movement of a vehicle In NEUTRAL (N), the wheels and could injure those in or near the vehicle. As Caution! with all vehicles, you should never exit a transmission are not locked. The vehicle vehicle while the engine is running. Before will roll freely even on the slightest exiting a vehicle, always come to a incline unless the parking brake or...
Page 163 Shift-Lock System Shift Lock Override Warning! The shift-lock system prevents shifting If the gear selector will not move from out of PARK (P) unless the brake pedal PARK (P) using the proper shift is depressed. procedure, continue to press the brake Do not downshift for additional engine pedal and proceed as follows: To shift from PARK (P):...
Page 164 For Some Models To change to MANUAL (M) shift mode, shift the gear selector from DRIVE (D) to Proceed as follows: MANUAL (M). To return to automatic 1. Push the lock release button on the shift mode, shift the gear selector from gear selector while also pushing down MANUAL (M) to DRIVE (D).
Page 165 Do not drive the vehicle with the Driving Tips Climbing steep grades from a stop tachometer needle in the red zone To climb a steep grade from a stopped Overtaking while in manual shift mode. position: For extra power when passing another During deceleration, the vehicle or climbing steep grades, press 1.
Page 166: Speed Control
SPEED CONTROL Activation / Deactivation Speed Control Note: When the ignition is cycled OFF, This is an electronically controlled the system status before it was turned driving assistance feature that allows off is stored. For example, if the ignition the desired vehicle speed to be is cycled OFF while the Speed Control maintained, without having to press the is operating, the system will be...
Page 167 Deactivating Speed Control Note: The Speed Control setting The Speed Control will cancel if the cannot be performed under the vehicle speed decreases below Push the OFF/CAN button. The following conditions: 16 mph (25 km/h) when climbing a warning light (amber) in the steep incline.
Page 168 To increase speed using If the instrument cluster display for To temporarily cancel the system, use accelerator pedal: vehicle speed is indicated in km/h: the one of these methods: speed will decrease in 1 km/h Press the accelerator pedal to Slightly press the brake pedal.
Page 169: Radar Sensors - If Equipped
RADAR SENSORS — Vehicles are shipped with the direction of the radar sensors adjusted for each IF EQUIPPED Caution! vehicle to a loaded vehicle condition so Rear Radar Sensors that the radar sensors detect approaching vehicles correctly. If the The following systems use the rear If the rear bumper receives a severe direction of the radar sensors has impact, the system may no longer operate...
Page 170: Rear Park Assist - If Equipped
REAR PARK ASSIST The system is equipped with an assist The sensor area is frozen (operation device to notify the driver of the will return to normal when the ice is — IF EQUIPPED approximate distance from the vehicle thawed). Rear Park Assist to the surrounding obstruction using a The sensor is covered by a hand or...
Page 171 Obstructions under the bumper Note: The following types of Sensor Detection Range may not be detected. Obstructions obstructions may not be detected: The sensors detect obstructions within that are lower than the bumper or thin Thin objects such as wire or rope. the following range: which may have been initially detected but are no longer detected as the...
Page 172 Parking Sensor Audible Alert The audible alert will sound while the system is operating according to the following chart: Rear Sensor Distance Between Vehicle And Distance Detection Area Audible Alert (*) Obstruction Farthest distance Approx. 59 - 23 inches (150 cm - 60 cm) Slow intermittent sound Far distance Approx.
Page 173 When A Warning Alert Is Activated The system notifies the driver of an obstacle by activating the audible alert. Beep How To Check The system may have a malfunction. Contact an authorized dealer as soon as The audible alert is not heard. possible.
Page 174: Parkview Rear Backup Camera
PARKVIEW REAR When parking in REVERSE, take care over obstacles that may be above BACKUP CAMERA Warning! or under the camera’s display range. Operation When the display is cold, the The camera is located on the trunk lid, Always use extreme caution and verify images could be more blurred than the real conditions of the area behind the above the license plate.
Page 175 Display Note: The images on the display can Caution! show a situation that differs from the actual view. Do not apply excessive force to the camera. You could alter the position and angle of the camera. Do not disassemble, modify or remove it as this could compromise the seal.
Page 176 Note: If it is difficult to see the display Looking At The Display under the following conditions, it does The vehicle width guide lines are Warning! not mean that there is a malfunction: displayed on the screen as a reference In dark areas.
Page 177 5. Once the guide lines are parallel, 6. When the gear selector is moved straighten the steering wheel and from the REVERSE position and put in reverse slowly into the parking space. any other position, the screen returns to Continue to check the vehicle’s the previous display mode.
Page 178 Road Conditions And When The Road Behind The Displayed Image Vehicle Slopes Steeply: There are some differences between When the vehicle is on a steep uphill what is shown on the display, and the (downhill) slope, the object on the actual road conditions.
Page 179 Adjusting The Image Quality Warning! The image quality can be adjusted with the gear selector in the REVERSE Adjusting the rear-view camera image position. quality must always be done when the Four adjustments can be made: vehicle is stationary. Do not adjust the brightness, contrast, tint and color.
Page 180: Refueling The Vehicle
REFUELING THE knocking sound, see your authorized Reformulated Gasoline dealer immediately. Use of gasoline with VEHICLE Many areas of the country require the an octane number lower than 87 can use of cleaner burning gasoline referred Refueling The Vehicle cause engine failure and may void or to as “Reformulated Gasoline”.
Page 181 Problems that result from using number without MMT. Gasoline blended active solvents or similar ingredients. gasoline containing more than 15% with MMT reduces spark plug life and These can harm fuel system gasket and ethanol (E-15) or gasoline containing reduces emissions system performance diaphragm materials.
Page 182 Carbon Monoxide Refueling Procedure Note: Warnings Fuel Filler Door Make sure to lock both the doors when leaving the vehicle. Note: Always use only a designated Warning! FCA fuel filler cap or an approved Lock the doors after closing the fuel equivalent, available at your authorized filler door.
Page 183 Emergency Fuel Filler 2. Partially peel back the cover inside Door Release the trunk, then pull the emergency Warning! release lever. If the battery is discharged, the fuel filler door cannot be opened. In this case, Never have any smoking materials lit in the fuel filler door can be opened by or near the vehicle when the gas cap is taking care of the discharged battery...
Page 184: Vehicle Loading
VEHICLE LOADING Gross Axle Weight Rating Inflation Pressure (GAWR) Certification Label This is the cold tire inflation pressure for your vehicle for all loading conditions up The GAWR is the maximum permissible As required by National Highway Traffic to full GAWR. load on the front and rear axles.
Page 185: Towing Trailers
TOWING TRAILERS DRIVING TIPS front and rear axle. Weighing the vehicle may show that the GAWR of either the Trailer Towing Engine Break-In front or rear axles has been exceeded Recommendation but the total load is within the specified Your car is not designed for towing. GVWR.
Page 186 Follow the maintenance schedule For more traction in starting on and contact your authorized dealer. slippery surfaces such as ice or packed Warning! snow, use sand, rock salt, chains, Use the air conditioner only when carpeting, or other nonslip material necessary.
Page 187 Winter Driving ONLY use the passenger’s side floor mat on the passenger’s side floor area. Warning! Carry emergency gear, including tire chains, window scraper, flares, a small ALWAYS make sure objects cannot fall shovel, jumper leads, and a small bag or slide into the driver’s side floor area Fast spinning tires can be dangerous.
Page 188 Do not open or close the soft top when Install the chains on the rear tires only. the temperature is 41 °F (5 °C) or less. Do not use chains on the front tires. Caution! The material of the soft top could be Note: damaged by freezing.
Page 189 Driving In Flooded Area Overloading Note: Do not drive the vehicle on Note: Be careful not to overload your Caution! flooded roads as it could cause short vehicle. The gross axle weight rating circuit of electrical/electronic parts, or (GAWR) and the gross vehicle weight water enters the engine and causes it rating (GVWR) of the vehicle are on the Always check the depth of the standing...
Page 190 This vehicle is equipped with low profile tires allowing class-leading performance and handling. As a result, the sidewall of the tires are very thin and the tires and wheels can be damaged if driven through potholes or on rough/uneven roads at excessive speeds. Use care and reduce speed when traveling on rough/uneven roads or through potholes.
Page 191 IN CASE OF EMERGENCY HAZARD WARNING LIGHTS ..190 REPLACING A BULB ..190 REPLACING FUSES ..200 JACKING AND TIRE CHANGING . .209 TIRE SERVICE KIT .
Page 192: Hazard Warning Lights
HAZARD WARNING REPLACING A BULB off to warn oncoming traffic of an emergency. Push the switch a second LIGHTS General Instructions time to turn off the Hazard Warning Control Lights. The hazard warning indicator lights in the instrument cluster will flash Warning! The Hazard Warning Lights should simultaneously.
Page 193 After replacing a headlight bulb, When the weather is cold or damp always check its alignment. or after heavy rain or washing, the surface of headlights or rear lights may To replace the bulb, contact your steam up and/or form drops of authorized dealer.
Page 194 Replacement Bulbs Light Bulbs Type Power Front Position – Front Side-Maker Lights (If Equipped With Full-LED Headlights) Front Positions/Side-Maker Lights (If Equipped With Halogen Headlights) WY5W High Beam (If Equipped With Full-LED Headlights) – High Beam/Daytime Running Lights (DRL) (If Equipped With Halogen Headlights) 60 W Daytime Running Lights (DRL) (If Equipped With Full-LED Headlights) –...
Page 195 Light Bulbs Rear Lights 3. Remove the fasteners in the seven locations and partially peel back the The bulbs are arranged as follows : Front Lights mud guard. The bulbs are arranged as follows : 04110102-L40-010 Rear Lights 08020499000002 Mud Guard 04110102-L38-008 Head Lights 4 —...
Page 196 Headlights (High Beam) With Daytime Running Lights (If Equipped With LED Lamps) Proceed as follows: 1. If you are changing the right bulb, start the engine, turn the steering wheel all the way to the right, and turn off engine. If you are changing the left bulb, turn the steering wheel to the left.
Page 197 Fog Lights Side Direction Indicator Lights Proceed as follows: Proceed as follows: 1. If you are changing the right bulb, 1. Make sure the ignition is placed in start the engine, turn the steering wheel the OFF mode, and the headlight all the way to the right, and turn off switch is off.
Page 198 6. Lift up the lens assembly, and then 2. Turn the socket counterclockwise, remove the cluster and install the new remove socket assembly then remove side direction indicator lens assembly in the bulb. the reverse order of the removal procedure. 08020499000011 Side Direction Indicator 1 —...
Page 199 Rear Direction Indicator Lights Proceed as follows: 1. Remove the retainers and the trunk lid end trim. 07031501214002 07031501-215-001 Trunk Trim Taillight Housing Fasteners 2 — Connector 4 — Screw 5 — Nuts 2. Disconnect the connector from the unit by pressing the tab on the 4.
Page 200 5. Turn the socket and bulb assembly Reverse Light Rear Side Marker counterclockwise to remove from Proceed as follows: Proceed as follows: taillight housing, and remove bulb. 1. Push the lens assembly rearward to 1. Make sure the ignition is placed in the OFF mode, and the headlight compress the internal catch, then pull switch is off.
Page 201 License Plate Lights 3. Turn the socket and bulb assembly counterclockwise and remove, remove Proceed as follows: bulb. 1. Make sure the ignition is placed in the OFF mode, and the headlight switch is off. 2. Slide the unit as shown in the figure to remove it.
Page 202: Replacing Fuses
REPLACING FUSES Replacing Interior Light Bulbs General Information Overhead Light Proceed as follows: Warning! 1. Using a suitable tool to prevent damage to the lens, remove the overhead light by carefully prying on the When replacing a blown fuse, always edge of the lens.
Page 203 Fuse location 3. Press retaining clip and remove protection cover. Fuses are grouped together in two fuse boxes located in the interior on the left 4. Pull the fuse straight out with the side of the vehicle and under the hood. fuse puller provided on the fuse block located in the engine compartment.
Page 204 Underhood Fuses 2. Remove the front tab while slightly lifting the front of the cover. If the headlights or other electrical components do not work and the fuses 3. Remove the cover while lifting it and in the cabin are normal, inspect the fuse sliding it to the rear.
Page 205 Fuse Block (Engine Compartment) 07031602-121-001...
Page 206 DESCRIPTION FUSE RATING PROTECTED COMPONENT ENG IG3 Engine Control Systems ENG IG2 Engine Control Systems HORN2 7.5 A Horn C/U IG1 15 A For Protection Of Various Circuits ENG IG1 7.5 A Engine Control System — — — INTERIOR 15 A Overhead Light —...
Page 207 DESCRIPTION FUSE RATING PROTECTED COMPONENT TAIL 20 A Taillights/Number Plate Lights/Position Lights — — — ROOM 25 A Overhead Light 15 A Fog Lights H/CLEAN 20 A Headlight Washer (If Equipped) STOP 10 A Stop Lights/Rear Fog Light (If Equipped) HORN 15 A Horn...
Page 208 DESCRIPTION FUSE RATING PROTECTED COMPONENT DEFOG 30 A Rear Window Defogger 30 A For Protection Of Various Circuits — — — HEATER 40 A Air Conditioner — — — — — —...
Page 209 Fuse Block Interior 07031602-03F-002...
Page 210 DESCRIPTION FUSE RATING PROTECTED COMPONENT RHT R 30 A — RHT L 30 A — — — — — — — F.OUTLET 15 A Accessory Sockets — — — AT IND 7.5 A AT Shift Indicator — If Equipped MIRROR 7.5 A Power Control Mirror R_DECK R...
Page 211: Jacking And Tire Changing
JACKING AND TIRE Tools Location CHANGING Your vehicle may be equipped with a spare tire, jack, lug wrench and tow eyes. For details, contact an authorized Warning! dealer. Tools are stored in the trunk. Do not attempt to change a tire on the side of the vehicle close to moving traffic.
Page 212 To Secure The Jack Conditions Of Non-Use 2. Turn on the Hazard Warning Lights and engage the parking brake. Proceed as follows: Temperatures below -40°F (−40°C). 3. For vehicles with automatic 1. Insert the wing bolt into the jack with On sandy or muddy ground.
Page 213 Removing A Tire 4. Continue raising the jack head gradually by rotating the screw with your hand until the jack head is inserted into the lift point. Warning! Caution! Carefully follow these tire changing warnings to help prevent personal injury or damage to your vehicle: Do not attempt to raise the vehicle by Always park on a firm, level surface as...
Page 214 To Remove An Anti-theft Lug Nut Proceed as follows: Warning! 1. Obtain the special key for the anti-theft lug nut. Raising the vehicle higher than necessary can make the vehicle less stable. It could 2. Place the special key on top of the slip off the jack and hurt someone near it.
Page 215 Mounting The Tire 3. Turn the lug wrench 5. Remove the tire blocks and store counterclockwise and lower the vehicle. the tools and jack. Proceed as follows: Use the lug wrench to tighten the nuts 6. Check the inflation pressure. Refer 1.
Page 216: Tire Service Kit
TIRE SERVICE KIT Tire Service Kit Mexico Market: Components And Tire Service Storage Operation The Tire Service Kit is located inside the The Tire Service Kit includes the trunk. following items: U.S.A. And Canada Markets: 08020202-121-003 Tire Service Kit Location The Tire Service Kit included with your vehicle is for a temporary repair of a slightly damaged flat tire resulting from...
Page 217 Tire Service Usage Sealing A Tire With Tire Take care not to allow the contents of Precautions Service Kit Tire Service Kit to come in contact with hair, eyes, or clothing. Tire Service Kit The tire sealant cannot be reused. If the sealant is harmful if inhaled, swallowed, or sealant has been used, or is expired, absorbed through the skin.
Page 218 3. Place the gear selector in REVERSE 7. Pull out the air compressor hose for a manual transmission, and PARK and the air compressor plug from the for automatic transmission. air compressor. 4. Apply the parking brake with the brake pedal pressed and cycle the engine OFF.
Page 219 11. Insert the air compressor plug into the accessory socket, located deep in the back of the footwell on the passenger side, and cycle the ignition to ACC. Note: When inserting the air compressor plug into or removing it from the accessory socket, make sure that the air compressor switch is off.
Page 220 16. Remove the air compressor hose from the injection valve of the bottle. Warning! Warning! Then, install the injection hose to the injection valve of the bottle to prevent leakage of any remaining sealant. Never use the air compressor above 3 Bar Do not adhere the speed restriction sticker (43.5 psi).
Page 221 Note: With TPMS System: if the tire Sealing A Tire With Tire Take care not to allow the contents of is not properly inflated, the warning Service Kit Tire Service Kit to come in contact with light will illuminate. hair, eyes, or clothing. Tire Service Kit sealant is harmful if inhaled, swallowed, or After driving the vehicle for about absorbed through the skin.
Page 222 3. Place the gear selector in REVERSE for a manual transmission, or PARK for automatic transmission. 4. Apply the parking brake with the brake pedal pressed and cycle the engine OFF. 5. Unload passengers and cargo, then remove the Tire Service Kit. 6.
Page 223 Note: Store the valve core in a place where it will not get dirty. Warning! 10. Insert the injection hose into the valve. Do not adhere the speed restriction sticker to the padded area on the steering wheel. Adhering the speed restriction sticker to the padded area on the steering wheel is dangerous because the air bag may not operate (deploy) normally resulting in...
Page 224 Note: Caution! Carefully drive the vehicle at a speed of 50 mph (80 km/h) or less. If the vehicle is driven at a speed of If the tire inflation pressure does not 50 mph (80 km/h) or more, the vehicle increase, repair of the tire is not possible.
Page 225: Jump Starting
JUMP STARTING If an emergency flat tire repair has been performed using the Tire Service Preparations For Jump Kit, FCA recommends that the tire be Starting replaced with a new one as soon as possible. If the tire is to be repaired or If the battery is discharged, a jump reused, contact an authorized dealer.
Page 226 To jump start the vehicle, follow this 5. Connect the opposite end of the procedure: positive jumper cable to the positive Caution! terminal on the booster battery. 1. Remove the positive terminal cover. 6. Connect the negative end of the Do not use a portable battery booster pack negative jumper cable to the negative or any other booster source with a system...
Page 227: If Your Engine Overheats
IF YOUR ENGINE Starting A Flooded Engine OVERHEATS Warning! If the engine fails to start, it may be If Your Engine Overheats flooded (excessive fuel in the engine). In any of the following situations, you You or others can be badly burned by hot Follow this procedure: engine coolant (antifreeze) or steam from can reduce the potential for overheating...
Page 228: Towing The Vehicle
TOWING THE If Steam Is Coming From The Engine Compartment: VEHICLE Caution! Do not go near the front of the vehicle. Attaching The Tow Eyes Stop the engine. Wait until the steam — If Equipped dissipates, then open the hood and The tow eye must be used exclusively start the engine.
Page 229 Proceed as follows: 1. Remove the towing eyelet and the lug wrench from the luggage compartment. 2. Wrap a flathead screwdriver or similar tool with a soft cloth to prevent damage to a painted bumper, and open the cap located on the front or rear bumper.
Page 230: Enhanced Accident Response System (Ears)
ENHANCED Note: Follow the precautions below to avoid damage to the towing eyelet and ACCIDENT Caution! towing hook, vehicle body, or RESPONSE SYSTEM transmission system when towing: (EARS) DO NOT use sling-type equipment when Do not tow a vehicle heavier than This vehicle is equipped with an towing.
Page 231: Event Data Recorder (Edr)
EVENT DATA RECORDER (EDR) This vehicle is equipped with an Event Data Recorder (EDR). The main purpose of an EDR is to record data that will assist in understanding how a vehicle’s systems performed under certain crash or near crash-like situations, such as an air bag deployment or hitting a road obstacle.
Page 232 This page is intentionally left blank...
Page 233 SERVICING AND MAINTENANCE INTRODUCTION ... .232 ENGINE COMPARTMENT ..239 BATTERY RECHARGING ..243 MAINTENANCE PROCEDURES . .243 RAISING THE VEHICLE ..246 WHEELS AND TIRES .
Page 234: Introduction
INTRODUCTION documents, should any New Vehicle equipment may perform maintenance. Limited Warranty coverage But we recommend that it always be Be extremely careful and prevent injury disagreement occur. Failure to do so done by an authorized dealer using to yourself and others or damage to can result in your New Vehicle Limited genuine FCA parts.
Page 235 As explained in the “Introduction” Operation of windshield Visually inspect conditions of the: paragraph, several procedures can be washer/wiper system and engine, transmission, lines and hoses done only by a qualified service positioning/wear of windshield wiper (exhaust/fuel system/brakes) and technician with special tools. blades rubber elements (hoses/belts/etc.) For details, read the separate Warranty...
Page 236 Scheduled Servicing Plan Mileage or time passed (whichever comes first) Or Years: Or Kilometers: Check tire condition/wear and adjust pressure, if necessary, check Tire • • • • • • • • • • • • • • • Service Kit expiration date (if equipped).
Page 237 Mileage or time passed (whichever comes first) Or Years: Or Kilometers: Check engine control system operation (via • • • • • • • • • • • • • • • diagnostic tool). Visually inspect condition of: exterior bodywork, underbody protection, pipes and hoses (exhaust - •...
Page 238 Mileage or time passed (whichever comes first) Or Years: Or Kilometers: Check windshield/rear window wiper blade • • • • • • • • position/wear. Check operation of windshield washer system • • • • • • • • and adjust jets if necessary.
Page 239 Mileage or time passed (whichever comes first) Or Years: Or Kilometers: Visual inspect the condition and tensioning of • • • the accessory drive belt. Replace the accessory • drive belt. **** Inspect and replace PCV • valve if necessary. Change engine oil and In accordance with Oil Change Indicator System OR Severe Duty Mileage, whichever occurs first.
Page 240 Mileage or time passed (whichever comes first) Or Years: Or Kilometers: Replace engine air filter. # • • • • • Flush and replace the engine coolant at 10 years or 150,000 miles • • (240,000 km) whichever comes first. Replace the timing belt •...
Page 241: Engine Compartment
ENGINE COMPARTMENT Checking Levels 07030300-121-003 1 — Window Washer Reservoir 4 — Engine Coolant Reservoir 2 — Engine Oil Dipstick 5 — Brake/Clutch Fluid Reservoir 3 — Engine Oil Cap 6 — Battery...
Page 242 Engine Oil Engine Coolant Warning! Warning! You or others can be badly burned by Be very careful when working in the hot engine coolant (antifreeze) or steam engine compartment when the engine is from your radiator. If you see or hear hot: you may get burned.
Page 243 If it is at or near L (Low), add coolant by mixing a minimum solution of 50% Warning! Mopar Long Life Coolant Concentrate for FIAT Spider. Use higher concentrations (not to exceed 70%) if Do not open hot engine cooling system. temperatures below −34°F (−37°C) are Never add engine coolant (antifreeze) anticipated.
Page 244 Automatic Transmission Overfilling the brake fluid reservoir can Control Unit result in spilling brake fluid on hot engine Warning! parts, causing the brake fluid to catch fire. The transmission oil level should only be Brake fluid can also damage painted and checked at an authorized dealer.
Page 245: Battery Recharging
BATTERY MAINTENANCE RECHARGING PROCEDURES Caution! Battery Charging The following pages contain Procedure instructions on the required It is essential when replacing the cables maintenance from the technical on the battery that the positive cable is personnel who designed the vehicle. attached to the positive post and the Warning! In addition to these specific...
Page 246 Lubricate the external lock cylinders Note: Blade Replacement twice a year. Apply a small amount of Proceed as follows: Hot waxes applied by automatic car high-quality lubricant directly into the washers have been known to affect 1. Raise the wiper arm. lock cylinder.
Page 247 3. Tilt the blade assembly and remove Note: it from the arm. Do not bend or discard the stiffeners, they will be reused. If the metal stiffeners are switched, the blade's wiping efficiency could be reduced. Do not use the driver's side metal stiffeners on the passenger's side, or vice versa.
Page 248: Raising The Vehicle
RAISING THE WHEELS AND TIRES Note: VEHICLE P (Passenger) — Metric tire sizing is Tire Safety Information based on U.S. design standards. If the vehicle needs to be raised, see an Tire safety information will cover P-Metric tires have the letter “P” authorized dealer which is equipped aspects of the following information: molded into the sidewall preceding the...
Page 249 Tire Sizing Chart EXAMPLE: Example Size Designation: P215/65R15XL 95H, 215/65R15 96H, LT235/85R16C, T145/80D18 103M, 31x10.5 R15 LT P = Passenger car tire size based on U.S. design standards, or "..blank.." = Passenger car tire based on European design standards, or LT = Light truck tire based on U.S.
Page 250 EXAMPLE: Load Identification: Absence of the following load identification symbols on the sidewall of the tire indicates a Standard Load (SL) tire: XL = Extra load (or reinforced) tire, or LL = Light load tire or C, D, E, F, G = Load range associated with the maximum load a tire can carry at a specified pressure Maximum Load –...
Page 251 EXAMPLE: 01 = Number representing the year in which the tire was manufactured (two digits) 01 means the year 2001 Prior to July 2000, tire manufacturers were only required to have one number to represent the year in which the tire was manufactured. Example: 031 could represent the 3rd week of 1981 or 1991 Tire Terminology And Definitions Term...
Page 252 Tire Loading And Tire Pressure Tire And Loading Information Loading Placard Note: The proper cold tire inflation The vehicle maximum load on the tire pressure is listed on the driver’s side must not exceed the load carrying B-Pillar or the rear edge of the driver's capacity of the tire on your vehicle.
Page 253 Steps For Determining Correct 150 lb passengers in your vehicle, Metric Example For Load Limit Load Limit— the amount of available cargo and For example, if “XXX” amount equals 635 kg and there will be five 68 kg luggage load capacity is 650 lbs. (1) Locate the statement “The passengers in your vehicle, the amount (1400-750 (5x150) = 650 lbs.)
Page 254 GUID-054900419-high.tif Warning! Overloading of your tires is dangerous. Overloading can cause tire failure, affect vehicle handling, and increase your stopping distance. Use tires of the recommended load capacity for your vehicle. Never overload them.
Page 255 Tires — General Tire Inflation Pressures Unequal tire pressures from one side of Information the vehicle to the other can cause the The proper cold tire inflation pressure is vehicle to drift to the right or left. Tire Pressure listed on the driver's side B-Pillar or rear Always drive with each tire inflated to the edge of the driver's side door.
Page 256 Check tire pressures more often if Consult an authorized tire dealer for tire subject to a wide range of outdoor repairs and additional information. Warning! temperatures, as tire pressures vary Damaged Run Flat tires, or Run Flat with temperature changes. tires that have experienced a loss of Tire pressures change by approximately High speed driving with your vehicle under...
Page 257 Tire Spinning Tire pressure - Improper cold tire inflation pressures can cause uneven When stuck in mud, sand, snow, or ice wear patterns to develop across the tire conditions, do not spin your vehicle's tread. These abnormal wear patterns wheels above 30 mph (48 km/h) or for will reduce tread life, resulting in the longer than 30 seconds continuously need for earlier tire replacement.
Page 258 Replacement Tires Tire Types Warning! All Season Tires — If Equipped The tires on your new vehicle provide a balance of many characteristics. They All Season tires provide traction for all should be inspected regularly for wear Do not use a tire, wheel size, load rating, seasons (Spring, Summer, Fall, and and correct cold tire inflation pressures.
Page 259 capability on wet or dry surfaces may Compact Spare Tire — If be poorer than that of non-studded Equipped Warning! tires. Some states prohibit studded The compact spare is for temporary tires; therefore, local laws should be emergency use only. You can identify if checked before using these tire types.
Page 260 Do not install a wheel cover or attempt Limited Use Spare — If to mount a conventional tire on the Equipped Warning! collapsible spare wheel, since the wheel The limited use spare tire is for is designed specifically for the temporary emergency use only.
Page 261 Wheel And Wheel Trim When cleaning extremely dirty wheels Dark Vapor Chrome, Black Satin Care including excessive brake dust, care Chrome, or Low Gloss Clear Coat must be taken in the selection of tire Wheels All wheels and wheel trim, especially and wheel cleaning chemicals and aluminum and chrome plated wheels, equipment to prevent damage to the...
Page 262 Tire rotation means moving the wheels to a different position, with respect to Warning! Caution! the vehicle. During rotation, inspect tires for correct balance. Using tires of different size and type (M+S, Using snow chains with tires with Snow) between front and rear axles can non-original dimensions may damage the cause unpredictable handling.
Page 263: Department Of Transportation Uniform Tire Quality Grades
DEPARTMENT OF Because your vehicle is not habits, service practices, and equipped with a spare tire, you cannot TRANSPORTATION differences in road characteristics do a tire rotation safely with the jack UNIFORM TIRE and climate. that may come with your vehicle if so QUALITY GRADES equipped.
Page 264: Storing The Vehicle
STORING THE Temperature Grades VEHICLE The Temperature grades are A (the Warning! highest), B, and C, representing the If the vehicle is left inactive for longer than a month, the following precautions tire's resistance to the generation of The temperature grade for this tire should be observed: heat and its ability to dissipate heat, is established for a tire that is...
Page 265: Bodywork
BODYWORK Cover the vehicle with a fabric or Preserving The perforated plastic sheet, paying Paintwork Protection From particular care not to damage the Touch up abrasions and scratches Atmospheric Agents painted surface by dragging any dust immediately to prevent the formation of that may have accumulated on it.
Page 266 not wash the vehicle after it has been Damage caused by bird Water marks left in the sun or with the hood hot: this dropping/insects/tree sap Problem: may alter the shine of the paintwork. Problem: Rain, fog, dew, and even tap water can Exterior plastic parts must be cleaned Bird droppings contain acids.
Page 267 In low temperatures, a vehicle's Note: FCA is not responsible for When washing and waxing the finish hardens. This increases the scratches caused by automatic car vehicle, be careful not to apply chance of paint chipping. washes or improper washing. excessive force to any single area of Scratches are more noticeable on the vehicle hood.
Page 268 Always wash and dry the vehicle before Bright-Metal waxing it. In addition to the vehicle Maintenance Caution! body, wax the metal trim to maintain its Use tar remover to remove road tar and lustre: insects. Never do this with a knife or Do not use steel wool, abrasive cleaners, Use wax which contains no similar tool.
Page 269 Underbody Maintenance Rinse it thoroughly with clean water to remove all the soap. Road chemicals and salt used for ice Caution! and snow removal and solvents used Wipe it as dry as you can before the for dust control may collect on the water dries on it.
Page 270 Note: Proceed as follows: 3. Remove leaves and other matter accumulated in the drain filter. Some leather treatment products 1. Check the position of the drain filter can ruin the convertible top's gloss. with your hand from behind the bow. 4.
Page 271: Interiors
INTERIORS Vinyl Remove dust and loose dirt from vinyl Caution! Seats And Fabric Parts with a whisk broom or vacuum cleaner. Clean vinyl with a leather-and-vinyl cleaner. High water temperature and high water Warning! pressure car washers are available Fabric depending on the type of high pressure Remove dust and loose dirt from fabric car washer device.
Page 272 Clean the webbing with a mild soap Instrument panel precautions solution recommended for upholstery or Prevent caustic solutions such as Caution! carpets. Follow instructions. Do not perfume and cosmetic oils from bleach or dye the belts, this may contacting the instrument panel. They weaken them.
Page 273 Window Interiors Remove dust and sand first using a vacuum cleaner or other means, then If the windows become covered with an Caution! wipe dirt off using a soft cloth with a oily, greasy, or waxy film, clean them leather cleaner or a soft cloth soaked in with glass cleaner.
Page 274 This page is intentionally left blank...
Page 275 TECHNICAL SPECIFICATIONS IDENTIFICATION DATA ..274 RECOMMENDED TIRE INFLATION PRESSURE ....275 ENGINE ....277 TRANSMISSION .
Page 276: Identification Data
IDENTIFICATION DATA Identification Numbers Model Plate The model plate is located on the left side of door pillar. 10010104-122-001AB 10010106-121-001 Vehicle Identification Number Vehicle Emission Control Information Label Motor Vehicle Safety Standard Label Tire Pressure Label (U.S.A. and Canada) The tire pressure label is located on the The motor vehicle safety standard label left side of door pillar.
Page 277: Recommended Tire Inflation Pressure
RECOMMENDED Always check the tire inflation Checking Tire Pressure pressures on a regular basis according TIRE INFLATION Proceed as follows: to the recommended tire inflation PRESSURE pressure on the tire label and in 1. When you check the air pressure, On the tire label you will find the conjunction with the information in this make sure the tires are cold - meaning...
Page 278 Glossary Of Terms B-pillar The structural member at the side of Tire Placard the vehicle behind the front door. A label indicating the OE (Original Equipment) tire sizes, recommended Original Equipment (OE) inflation pressure, and the maximum Describes components originally weight the vehicle can carry.
Page 279: Engine
ENGINE Engine 1.4 Turbo Multi Air Cycle Four Number and position of cylinders 4 in line Piston bore and stroke (mm) 72.0 x 80.4 Total displacement (cm³) 1368 Compression ratio 9.8:1 Maximum power (kW) Maximum power (HP) Corresponding engine speed (rpm) 5500 Maximum torque (Nm) Maximum torque (lb.-ft.)
Page 280: Transmission
TRANSMISSION Engine Traction Type Description (*) / 6-speed 6-speed manual 1.4 Turbo Multi Air Manual/Automatic Automatic Transmission (**) (*) If equipped with manual transmission (**) If equipped with automatic transmission...
Page 281: Brakes
BRAKES Engine Front brakes Rear brakes Parking brake Ventilated (floating type 11 in Solid (floating type 11 in 1.4 Turbo Multi Air Mechanical (lever type) (279.4 mm) diameter) (279.4 mm) in diameter) Note: Water, ice, and salt spread on the roads may deposit on the brake disks reducing braking efficiency the first time the brakes are applied.
Page 282: Suspensions
SUSPENSIONS Engine Front Rear 1.4 Turbo Multi Air Double wishbone with stabilizer bars Multilink with stabilizer bars...
Page 283: Steering
STEERING Engine Turning circle curb to curb, ft (m) Type Double pinion electric power assist system 1.4 Turbo Multi Air 30.8 (9.4) (DP - EPAS) - rack and pinion...
Page 284: Dimensions
DIMENSIONS Dimensions Dimensions are expressed in inches and refer to the vehicle equipped with its standard-supplied tires. Height is measured with vehicle unloaded. Trunk Volume: 4.9 cu. ft. (140 Liters) 10000555-122-333 Vehicle Dimension Chart 159.6 (4054 mm) 90.9 (2309 mm) 48.5 (1232 mm) 58.9 (1496 mm) 68.5 (1740 mm)
Page 285 Weights Curb Weight: 2477 lbs (1124 kg) (if equipped with manual transmission) / 2516 lbs (1141 kg) (if equipped with automatic transmission).
Page 286: Fluid Capacities
FLUID CAPACITIES Item Capacities Fuel tank 11.9 (gallons) / 45 (liters) Engine oil (without oil filter replacement) 3.3 (quarts) / 3.2 (liters) Engine oil (with oil filter replacement) 4.0 (quarts) / 3.8 (liters) Coolant (with manual transmission) 7.6 (quarts) / 7.2 (liters) Coolant (with automatic transmission) 7.5 (quarts) / 7.1 (liters) Manual transmission oil...
Page 287: Fluids And Lubricants
Manual transmission oil Oil for FIAT Spider Mopar Automatic Transmission Long Life Automatic transmission fluid Fluid for FIAT Spider Mopar Long Life Hypoid Gear Oil for FIAT Rear differential oil Spider Mopar Long Life Limited Slip Additive for Limited slip differential oil FIAT Spider We recommend you use Mopar DOT 3.
Page 288 Caution! Mixing of engine coolant (antifreeze) other than specified Organic Additive Technology (OAT) engine coolant (antifreeze), may result in engine damage and may decrease corrosion protection. Organic Additive Technology (OAT) engine coolant is different and should not be mixed with Hybrid Organic Additive Technology (HOAT) engine coolant (antifreeze) or any “globally compatible” coolant (antifreeze). If a non-OAT engine coolant (antifreeze) is introduced into the cooling system in an emergency, the cooling system will need to be drained, flushed, and refilled with fresh OAT coolant (conforming to MS.90032), by an authorized dealer as soon as possible.
Page 289: Performance
PERFORMANCE Performance Top speed after the initial period of usage of the vehicle. Version MPH (km/h) 1.4 Turbo Multi Air 160HP...
Page 290 This page is intentionally left blank...
Page 291 CUSTOMER ASSISTANCE SUGGESTIONS FOR OBTAINING SERVICE FOR YOUR VEHICLE . . .290 IF YOU NEED ASSISTANCE ..290 WARRANTY INFORMATION ..292 REPORTING SAFETY DEFECTS . .292 PUBLICATION ORDER FORMS . . .293...
Page 292: Suggestions For Obtaining Service For Your Vehicle
Vehicle delivery date and mileage vehicle the best, and are most additional charges with the service concerned that you get prompt and FIAT Customer Center manager. Keep a maintenance log of high quality service. The manufacturer's your vehicle's service history, as this P.O.
Page 293 Puerto Rico And U.S. Service Contract We appreciate that you have made a Virgin Islands major investment when you purchased You may have purchased a service the vehicle. An authorized dealer has Customer Service Chrysler International contract for a vehicle to help protect also made a major investment in Services LLC you from the high cost of unexpected...
Page 294: Warranty Information
WARRANTY REPORTING SAFETY To contact NHTSA, you may call the INFORMATION DEFECTS Vehicle Safety Hotline toll free at 1-888-327-4236 (TTY: See the Warranty Information Booklet, In The 50 United States 1-800-424-9153); or go to for the terms and provisions of FCA US And Washington, D.C.
Page 295: Publication Order Forms
PUBLICATION Owner's Manuals ORDER FORMS These Owner's Manuals have been prepared with the assistance of service To order the following manuals, you and engineering specialists to acquaint may use either the website or the you with specific FCA US LLC vehicles. phone numbers listed below.
Page 296 This page is intentionally left blank...
Page 297 INDEX Back-Up Camera ... .172 Precautions ....61 Battery ....242 Raising .
Page 298 Emergency, In Case Of Flashers Gasoline, Reformulated ..178 Hazard Warning ...190 Jump Starting ..223,224 Gear Ranges ....159 Flooded Engine Starting .
Page 299 Engine Oil Reset ..84,85 Leaving Home Light System ..42 Manual Climate Controls..48 Life Of Tires ....255 Instrument Panel.
Page 300 Personalization Features ..108 Reminder, Seat Belt ...130 Adjustment ....32 Remote Keyless Entry Heated .
Page 301 Suspensions ....280 Quality Grading ... .261 Passive Entry Programming ..21 Radial ....254 Symbols .
Page 303 Mobile radio equipment with output power greater than INSTALLATION OF RADIO TRANSMITTING EQUIPMENT normal may require special precautions. Special design considerations are incorporated into this All installations should be checked for possible interfer- vehicle’s electronic system to provide immunity to radio ence between the communications equipment and the frequency signals.

Fiat 124 Spider 2019 Owner's Manual

Getting to Know Your Vehicle

Getting to Know Your Instrument Panel

Safety

Starting and Operating

In Case of Emergency

Servicing and Maintenance

Quick Links

Chapters

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Fiat 124 Spider 2019

Summary of Contents for Fiat 124 Spider 2019

Table of Contents
