- Page 1 Disclaimer Disclaimer This user manual is provided as a free service by FixYourDLP.com. FixYourDLP is in no way responsible for the content of this manual, nor do we guarantee its accuracy. FixYourDLP does not make any claim of copyright and all copyrights remain the property of their respective owners. About FixYourDLP .com FixYourDLP.com (http://www.
-
Page 2: Mp8760 Multimedia Projector
Bruksanvisning för MP8760 Multimediaprojektor 3M MP8760 Multimediaprojector Gebruiksaanwijzing T H E T R U S T E D S O U R C E F O R P R O J E C T O R L A M P S A N D A C C E S S O R I E S... -
Page 3: Table Of Contents
OW TO RDER APPENDIX.................................... 25 3M IPC 2000 Multimedia Projector MP8760 T H E T R U S T E D S O U R C E F O R P R O J E C T O R L A M P S A N D A C C E S S O R I E S... -
Page 4: Safeguards
Before operating the machine, please read the entire manual thoroughly. The 3M Multimedia Projector MP8760 was designed, built, and tested for use indoors, using 3M lamps, 3M ceiling mount hardware and nominal local voltages. The use of other replacement lamps, outdoor operation, operation in environments containing heavy cigarette smoke or different voltages has not been tested and could damage the projector or peripheral equipment and/or create a potentially unsafe operating condition. - Page 5 Inside of projector gets very HOT! Allow internal parts to cool before replacing the lamp. LOCATION OF LABELS SAVE THESE INSTRUCTIONS The information contained in this manual will help you operate and maintain your 3M MP8760 Multimedia Projector. 3M IPC 2000 ...
-
Page 6: Warranty
LIMITED WARRANTY 3M warrants this product against any defects in material and workmanship, under normal use and storage, for a period of two years from date of purchase. Proof of purchase date will be required with any warranty claim. In the event this product is found to be defective within the warranty period, 3M’s only obligation and your exclusive remedy shall be... -
Page 7: Section 1: Unpack
Figure 1-1. Packing List 1-2. Keep Your Packing Materials Save the shipping box and packing materials in the event the MP8760 should require shipping to a 3M Service Center for repair. Use packing material to protect projector. 1-3. What’s Next? Take a few minutes to review Section 2 to familiarize yourself with the MP8760 machine characteristics and then turn to Section 3 to set up the projector. -
Page 8: Section 2: Production Description
EPS-19A 3M IPC 2000 Multimedia Projector MP8760 T H E T R U S T E D S O U R C E F O R P R O J E C T O R L A M P S A N D A C C E S S O R I E S... -
Page 9: Section 3: Set Up/Connections
Menu.) Disc/Pad: Move cursor up/down, left/right. Menu: Display/remove menus. Menu (-/+): Increase/decrease menu value. 10. Aux: Toggle On/Off a 3M compatible device. 11. Focus: Adjust image focus. 12. Standby: Switch between standby mode (lamp — off, fan off after cool down) and projection mode —... -
Page 10: Mouse Connection
Start up projector then start up input sources. Section 4–1. 3M IPC 2000 Multimedia Projector MP8760 T H E T R U S T E D S O U R C E F O R P R O J E C T O R L A M P S A N D A C C E S S O R I E S... - Page 11 PORT EPS-49A Figure 3-4. Cable Connections 3M IPC 2000 Multimedia Projector MP8760 T H E T R U S T E D S O U R C E F O R P R O J E C T O R L A M P S A N D A C C E S S O R I E S...
-
Page 12: Image Size (Projector-To-Screen Distance)
Figure 3.5. Maximum Image Shift 3M IPC 2000 Multimedia Projector MP8760 T H E T R U S T E D S O U R C E F O R P R O J E C T O R L A M P S A N D A C C E S S O R I E S... -
Page 13: Section 4: Operating Instructions
! ! ! ! Note In most cases, the projector will automatically adjust to the graphic mode of your computer by selecting a pre-programmed setting. 3M IPC 2000 Multimedia Projector MP8760 T H E T R U S T E D S O U R C E F O R P R O J E C T O R L A M P S A N D A C C E S S O R I E S... -
Page 14: Standby Mode
To completely exit the menu system and return to the projected image, press the Menu button. 3M IPC 2000 Multimedia Projector MP8760 T H E T R U S T E D S O U R C E F O R P R O J E C T O R L A M P S A N D A C C E S S O R I E S... -
Page 15: Menu Adjustments/Settings
640x480 / 800x600 / 832x624 / 1024x768 / 1152x864 / 1152x870 / 1152x900 / 1280x960 / 1280x1024) 3M IPC 2000 Multimedia Projector MP8760 T H E T R U S T E D S O U R C E F O R P R O J E C T O R L A M P S A N D A C C E S S O R I E S... - Page 16 (immediate / 1, 3, or 5 seconds / off) 3M IPC 2000 Multimedia Projector MP8760 T H E T R U S T E D S O U R C E F O R P R O J E C T O R L A M P S A N D A C C E S S O R I E S...
- Page 17 Test Display test submenu 3M IPC 2000 Multimedia Projector MP8760 T H E T R U S T E D S O U R C E F O R P R O J E C T O R L A M P S A N D A C C E S S O R I E S...
- Page 18 Lamp 3M IPC 2000 Multimedia Projector MP8760 T H E T R U S T E D S O U R C E F O R P R O J E C T O R L A M P S A N D A C C E S S O R I E S...
-
Page 19: Section 5: Remote Control
*Enter: Mouse emulation ON, left mouse displayed image. button. Mouse emulation OFF, Enter button for confirmation of a selection. ZOOM FOCUS Aux: Toggle On/Off a 3M compatible device. Drag: Lock left mouse button. *Menu: Display system menus. Text: Not used. VIDEO... -
Page 20: Meaning Of The Icons
Mouse button a second time. 3M IPC 2000 Multimedia Projector MP8760 T H E T R U S T E D S O U R C E F O R P R O J E C T O R L A M P S A N D A C C E S S O R I E S... - Page 21 Either there is no input source connected to the projector or the source is giving no output signal. For RGB/PC input sources you must manually select another Sync Mode recognition in the Advanced Setup menu. 3M IPC 2000 ...
-
Page 22: Battery Replacement
Figure 5-1. Replacing Batteries ™ © 3M IPC 2000 Multimedia Projector MP8760 T H E T R U S T E D S O U R C E F O R P R O J E C T O R L A M P S A N D A C C E S S O R I E S... -
Page 23: Section 6: Maintenance
PC / RGB 1 EPS-53A Figure 6-1. Removing Air Filter Door 3M IPC 2000 Multimedia Projector MP8760 T H E T R U S T E D S O U R C E F O R P R O J E C T O R L A M P S A N D A C C E S S O R I E S... -
Page 24: Replacing Projection Lamp
Figure 6-2. Changing the lamp cartridge 3M IPC 2000 Multimedia Projector MP8760 T H E T R U S T E D S O U R C E F O R P R O J E C T O R L A M P S A N D A C C E S S O R I E S... -
Page 25: Lamp Life Indicator
For best performance, keep your projector free of excess dust and surface dirt. Use a soft cloth to remove dust from the projector housing. Use 3M High Performance Cleaning Cloth to remove surface dirt and smudges from the projection lens. -
Page 26: Section 7: Troubleshooting
Standby Mode. 3M IPC 2000 Multimedia Projector MP8760 T H E T R U S T E D S O U R C E F O R P R O J E C T O R L A M P S A N D A C C E S S O R I E S... - Page 27 • • The Standby button There is no lamp in Put a 3M MP8760 lamp in the unit. • blinks red and the the unit. Install the lamp again. • lamp with not turn The lamp is improperly placed in the unit.
-
Page 28: Service Information
7-2. Service Information For product information, product assistance, service information, or to order accessories or spare parts, please call: In U.S. or Canada: 1-800-328-1371 In other locations, contact your local 3M Sales office. 3M IPC 2000 Multimedia Projector MP8760... -
Page 29: Section 8: Product Specifications
FCC Part 15, Class A, CE, UL Warranty Two years limited warranty on parts and labor 3M IPC 2000 Multimedia Projector MP8760 T H E T R U S T E D S O U R C E F O R P R O J E C T O R L A M P S A N D A C C E S S O R I E S... -
Page 30: Accessory & Spare Parts List
MP8760 remote mouse and a PC mouse (only works with Microsoft serial mouse). 8-3. How to Order Please order these parts through your dealer, or contact 3M Customer Service at the following number: • In U.S. or Canada: 1–800–328–1371 •... -
Page 31: Appendix
2.00 (78.7) 1.50 (29.1) 0.57 (22.4) 3M IPC 2000 Multimedia Projector MP8760 T H E T R U S T E D S O U R C E F O R P R O J E C T O R L A M P S A N D A C C E S S O R I E S... - Page 32 A standard power cord set (U.S., UK, or European) will be included with each MP8760. If you need a special power cord set, contact your local 3M authorized dealer. The power cords must be in accordance with the regional and corresponding national safety regulations and be properly approved.
- Page 33 If you've had selected another menu language as english, which is the default language, you'll have to select your menu language again. 3M IPC 2000 Multimedia Projector MP8760 T H E T R U S T E D S O U R C E F O R P R O J E C T O R L A M P S A N D A C C E S S O R I E S...
- Page 34 1280 x 1024 3M IPC 2000 Multimedia Projector MP8760 T H E T R U S T E D S O U R C E F O R P R O J E C T O R L A M P S A N D A C C E S S O R I E S...
- Page 35 3M IPC 2000 Multimedia Projector MP8760 T H E T R U S T E D S O U R C E F O R P R O J E C T O R L A M P S A N D A C C E S S O R I E S...
- Page 36 INCLUDING BUT NOT LIMITED TO, ANY IMPLIED WARRANTY OF MERCHANTIBILITY OR FITNESS FOR A PARTICULAR PURPOSE. If this product is defective within the warranty period stated above, your exclusive remedy shall be, at 3M's option, to replace or repair the 3M product or refund the purchase price of the 3M product.
- Page 37 Disclaimer Disclaimer This user manual is provided as a free service by FixYourDLP.com. FixYourDLP is in no way responsible for the content of this manual, nor do we guarantee its accuracy. FixYourDLP does not make any claim of copyright and all copyrights remain the property of their respective owners. About FixYourDLP .com FixYourDLP.com (http://www.
