Command access LLP-UL-M KIT Insert Instructions page 7

19.
Re-install filler plate being cautious of wires.
21.
Hook up to power. Depress push pad & set PTS adjustment.
Step 1-
Select your preferred torque mode (ships in standard torque) Press the device push pad to the
desired setting. (Recommend to fully depress and release 5%, giving the device room for
changing door conditions.)
Step 2- While depressing the push pad, apply power. (i.e. presenting the credential to the reader).
Step 3- Continue to keep pad depressed, the device will beep 6 times. After the beeps have stopped,
release the pad and now the adjustment is complete. If not to your liking repeat the three
steps.
mm4s switches
off
1
on
on
2
off
U S C U S T O M E R S U P P O R T 1 - 8 8 8 - 6 2 2 - 2 3 7 7 | W W W . C O M M A N D A C C E S S . C O M | C A C U S T O M E R S U P P O R T 1 - 8 5 5 - 8 2 3 - 3 0 0 2
CONTINUED
Setting PTS
STANDARD TORQUE
HIGH TORQUE
PTS PROGRAMMING on
PTS PROGRAMMING LOCKED
20.
Re-install the head cover.
7
