Technical Information; Setting Pts; Troubleshooting & Diagnostics - Command access LLP-UL-M KIT Insert Instructions

mm4s switches
off
1
STANDARD TORQUE
on
HIGH TORQUE
on
2
PTS PROGRAMMING on
off
PTS PROGRAMMING LOCKED
Step 1-
Press the device push pad to the desired setting. (this can be fully depressed or less than fully
depressed).
Step 2-
While depressing the push pad, apply power. (i.e. presenting the credential to the reader).
Step 3-
Continue to keep pad depressed, the device will beep 6 times, roughly 5 seconds. After the beeps
have stopped, release the pad and now the adjustment is complete. If not to your liking repeat the
three steps. That's all there is to it.
Beeps Explanation
2 Beeps Over Voltage
3 Beeps
Under Voltage
4 Beeps Failed Sensor
5 Beeps Forced Release
Push pad is depressed. Device
6 Beeps
is re-adjusting
Over-travel or mechanical obstruction
7 Beeps
U S c u s t o m e r s u p p o r t 1 - 8 8 8 - 6 2 2 - 2 3 7 7 | w w w . c o m m a n d a c c e s s . c o m | C A c u s t o m e r s u p p o r t 1 - 8 5 5 - 8 2 3 - 3 0 0 2

Technical Information

SPECIFICATIONS
• Input Voltage: 24VDC +/- 10%
• Wire gauge: Minimum 18 gauge
• Direct wire run - no relays or access control
units in-between power supply & module

Setting PTS

**Important Info**
Make sure to set PTS before finishing installation
Troubleshooting & Diagnostics
> 28V unit will shut down. Check voltage & adjust to 24 V.
< 22V unit will shut down. Check voltage & adjust to 24 V.
Verify all 3 sensor wires are installed correctly. Replace sensor if problem
persists by contacting CAT tech support.
Device will automatically re-engage within 5 seconds.
Check to make sure the push pad is not stuck or catching
on anything.
If mechanical obstruction, remove & push pad down until beeping stops
to reset. If no obstruction, the pad may have been pushed in too far
during PTS calibration. Recalibrate with the pad slightly out. If problem
persists, verify the magnet is within 1/4" of the sensor at the end of
travel.
Standard Torque Mode
Average Latch Retraction Current: 1 Amp
Average Holding Current: 215 mA
High Torque Mode
Average Latch Retraction Current: 2 Amp
Average Holding Current: 250 mA
Solution
PTS Video
Click or Scan
# 2 0 2 2 7 _ E
