Command access LLP-UL-M KIT Insert Instructions page 6

13.
Re-install the push pad end cap with (2) screws.
2
1
15.
While sliding housing back on make sure motor bracket
fits between exsiting groves.
17.
Attach to power and test to confirm
motor is functioning.
U S C U S T O M E R S U P P O R T 1 - 8 8 8 - 6 2 2 - 2 3 7 7 | W W W . C O M M A N D A C C E S S . C O M | C A C U S T O M E R S U P P O R T 1 - 8 5 5 - 8 2 3 - 3 0 0 2
CONTINUED
14.
Slide housing back onto baserail being cautious
not to pitch any wires
16.
Confirm motor has seated properly but see if the
bottom bracket is sitting flush on the baserail.
18.
Re-install (2) screws securing base rail to housing.
1 2
6
