Clas Ohlson KG8004-UK Quick Start Manual

Wireless mini keyboard
Art.no 18-8233 Model KG8004-UK
38-4355 KG8004
Please read the entire instruction manual before use and save it for future
reference. We reserve the right for any errors in text or images and for making any
necessary technical changes to this document. If you should have any questions
concerning technical problems please contact our Customer Services.

Product description

• Wireless mini keyboard with optical trackball and integrated mouse buttons.
• Range: up to 10 m.
• Compatible with Windows 7 (32/64-bit), Vista (32/64-bit) and XP.
• Comes with USB receiver and batteries.
1. Left mouse button
1 2
2. Right mouse button
3. Optical trackball
4. ON/OFF switch
5. USB receiver
(under the battery cover)
6. Battery compartment
7. Battery cover

System requirements

4
• USB port
• Windows XP/VISTA/Win 7
Contents
• Wireless mini keyboard
• USB receiver (stored in the battery compartment under the keyboard)
• 2 x AAA/LR03 batteries
• Instruction manual
Installation
1. Slide the battery cover (7) in the direction of the arrow and remove it.
2. Insert the batteries according to the markings in the battery compartment.
3. Remove the USB receiver (5) and replace the battery cover.
4. Set the on/off switch (4) to ON to activate the keyboard.
5. Connect the USB receiver (5) to an available USB port on your computer.
6. The computer will detect and install the drivers automatically. A message
window will appear once installation is complete.
GREAT BRITAIN • for consumer contact, please visit www.clasohlson.co.uk and click on customer service.
Operation
1. Changing between numerals and letters:
Depress [ FN ] and then press [ Insert Num LK ] to activate the numerical
function keys [ 0 ] – [ 9 ], marked with blue.
Keep [ FN ] depressed the entire time you want to use the numerical function.
Release [ FN ] to return to normal letter functioning.
2. Using the blue marked function keys for adjusting audio, e-mail, etc.
E.g. To increase volume: Depress [ FN ] an then press [ F11 ].
Turn off the keyboard with the ON/OFF switch (4) to save the battery, if it is not to
be used for a while.
Care and maintenance
Use a vacuum with a brush attachment for cleaning. Dust and debris can be
blown clean with low pressure compressed air. Never use strong solvents or
cleaning agents.

Troubleshooting

3
1. Restart the keyboard by moving the ON/OFF switch (4) from ON to OFF and
back to ON.
2. Make sure the batteries are good and that they are correctly inserted.
3. Make sure the USB receiver is connected to a functioning USB port.
Disposal
When it is time to dispose of this product, do so in accordance with local regula-
tions. If you are unsure how to proceed, contact your local authority.
5 6 7

Specifications

Frequency range
Range
Power supply
USB Interface
Size (W x H x D)
Note:
• Other wireless equipment using the same frequency can reduce
the transmission range.
• The range of all wireless equipment depends on the type of obstacles
located between the transmitter and the receiver (e.g. a concrete wall will
interfere with the signal more than a plasterboard wall).
If you experience problems, try the following:
• Turn off any existing wireless equipment to see if that could be causing
the problem.
• Move the wireless equipment and/or shorten the distance and reduce
the number of obstacles (walls, furniture, etc) between the transmitter
and receiver.
2.4000–2.4835 GHz
Up to 10 m
2 x AAA/LR03 batteries (1.5 V),
alkaline batteries recommended.
1.1
265 x 127 x 17 mm

Declaration of Conformity

Hereby, Clas Ohlson AB, declares that this product,
Wireless keyboard
18-8233 & 38-4355
with model number
KG8004-UK & KG8004
is in compliance with the essential requirements and other
relevant provisions of Directive 1999/5/EC.
Article 3.1a (Safety): EN 60950-1
Article 3.1b (EMC): EN 301489-1
EN 301489-3
Article 3.2 (Radio): EN 300440-1
EN 300440-2
Insjön, Sweden, August 2011
Klas Balkow
President
Clas Ohlson, 793 85 Insjön, Sweden
