Clas Ohlson SMK-48350AG-UK Manual

Wireless Keyboard and Mouse
Art.no 18-8413 Model SMK-48350AG-UK
38-6600 SMK-48350AG
Please read the entire instruction manual before using the product and
then save it for future reference. We reserve the right for any errors in text
or images and any necessary changes made to technical data. In the event
of technical problems or other queries, please contact our Customer
Services.

Safety

• Do not subject the keyboard or mouse to knocks and blows.
• Do not place the keyboard or mouse where there is a risk that it
may fall into water or other liquids.
• Do not place the keyboard or mouse close to a strong heat source
or expose it to direct sunlight for prolonged periods.
• Never attempt to dismantle, repair or modify the keyboard or
mouse in any way.

Operating instructions

Batteries

Mouse
1. Remove the battery cover on the base of the mouse and insert
1 × AA/LR6 battery. Note the polarity markings in the battery
compartment to ensure correct battery insertion.
2. Refit the battery cover.
Keyboard
1. Open the battery cover
by sliding it outwards.
2. Insert a battery (AA/LR6).
Note the polarity markings
in the battery compartment
to ensure correct battery
insertion.
3. Refit the battery cover
by sliding it inward.
GREAT BRITAIN • customer service tel: 0845 300 9799 e-mail: customerservice@clasohlson.co.uk internet: www.clasohlson.com/uk

Connection

1. Remove the USB receiver from its
storage compartment on the base of
the mouse.
2. Plug the USB receiver into a vacant port
on your computer.
3. The mouse and the keyboard will
automatically be connected to your
computer.

Standby mode

If the mouse is not used for 8 minutes it enters standby mode to save
battery power. Pressing any of the buttons or moving the scroll wheel
will reactivate the mouse.

Factory reset

Mouse
1. Disconnect the USB receiver from the computer.
2. Press down the right mouse button and the scroll
wheel simultaneously.
3. Plug the USB receiver back into the computer.
Keyboard
1. Disconnect the USB receiver from the computer.
2. Press [ ESC ] and [ K ] on the keyboard simultaneously.
3. Plug the USB receiver back into the computer.

Care and maintenance

Clean the keyboard and using a lightly moistened cloth. Use only mild cleaning
agents, never solvents or corrosive chemicals. Remove the battery from
the keyboard and mouse if they are not to be used for a long time.

Disposal

This product should be disposed of in accordance with local regulations.
If you are unsure how to proceed, contact your local council.

Specifications

Batteries
Mouse 1 × AA/LR6
Keyboard 1 × AA/LR6

Declaration of Conformity

Hereby, Clas Ohlson AB, declares that following product(s):
Wireless Keyboard and mouse
38-6600/18-8413
SMK-48350AG
is in compliance with the essential requirements and other relevant provisions
of Directive 1999/5/EC and 2006/95/EC.
Article 3.1a (Safety): EN 60950-1
Article 3.1b (EMC): EN 301489-1
EN 301489-3
Article 3.2 (Radio): EN 300440-1
EN 300440-2
Insjön, Sweden, July 2014
Klas Balkow
President
Clas Ohlson, 793 85 Insjön, Sweden
