Clas Ohlson SK-038BT Operating Instructions Manual

Mini Bluetooth Keyboard
Art.no 18-8401 Model SK-038BT
38-6372 SK-038BT
Please read the entire instruction manual before using the product and
then save it for future reference. We reserve the right for any errors in
text or images and any necessary changes made to technical data.
In the event of technical problems or other queries, please contact our
Customer Services.

Safety

• Do not subject the keyboard to knocks and blows.
• Do not place the keyboard where there is a risk that it may fall into
water or other liquids.
• Do not plug in or unplug the USB cable with wet hands.
• Do not place the keyboard close to a strong heat source or expose
it to direct sunlight for prolonged periods.
• Never attempt to tamper with, repair or modify the keyboard in
any way. The built-in battery cannot be replaced.
• Use only the included USB cable for charging the keyboard.

Buttons and functions

1 2
1. Micro-USB charger port connection
2. [ OFF/ON ] Power switch
3. LED indicator. Shines red while the battery is charging and goes out
when the battery is fully charged.
4. LED indicator. Flashes blue when the keyboard is detectable for
other Bluetooth devices.
5. LED indicator. Shines blue when the [ Caps Lock ] button is pressed.
GREAT BRITAIN • customer service tel: 0845 300 9799 e-mail: customerservice@clasohlson.co.uk internet: www.clasohlson.com/uk
Operating instructions

Charging

1. Connect the USB cable to a computer or other USB charging
device. The red LED indicator (3) will come on to show that
charging is in progress. Note: The keyboard should be charged for
at least 4 hours before it is used for the first time and even when it
is used again after a long period of disuse.
2. When the LED indicator goes out, the keyboard is fully charged.
Establishing a Bluetooth connection with
a computer, tablet or mobile phone
1. Set the [ ON/OFF ] switch (2) on
the keyboard to the ON position.
2. The LED Bluetooth connection indicator (4)
flashes blue to indicate that the keyboard
is detectable for other devices (hold down
[ Fn ] and [ F1 ] simultaneously for one
second if the LED indicator does not flash
to indicate that the keyboard is detectable).
3. Activate Bluetooth on the device you intend to connect to
the keyboard. Refer to the instruction manual of your device for
further clarification if you are unsure.
4. The keyboard will now appear on your device as "Bluetooth v3.0
Keyboard", select it.
5. A password will now appear on
your device. Write the password on
the keyboard and press [ ENTER ].
3 4 5
The two devices will now connect
(pair) with each other.
Note:
• The keyboard can only be paired with one device at a time.
• If, for example, you have the keyboard paired with your iPad and
then decide to pair it with your mobile phone or computer instead,
you can't just reactivate the previous connection to your iPad.
You will have to delete the keyboard (Bluetooth v3.0 Keyboard) from
the list of Bluetooth devices connected to your iPad and then carry
out a new Bluetooth device search to re-establish the connection.

Care and maintenance

Wipe the keyboard clean with a dry cloth as and when required.
Troubleshooting guide
The keyboard
won't turn on.
The keyboard
doesn't work.
Certain special
character keys
do not work.
6. The devices are now
paired.

Disposal

This product should be disposed of in accordance with local
regulations. If you are unsure how to proceed, contact your
local council.

Specifications

Bluetooth 3.0
Size
The battery in the keyboard might be discharged,
charge the battery.
• Make sure that a Bluetooth connection
has been properly established. Refer to
the Establishing a Bluetooth connection...
section above.
• Make sure that no other wireless devices
are interfering with the wireless keyboard
connection.
• If the device that you are attempting to
connect the keyboard to is already connected
to another Bluetooth device, this may impair
or prevent the keyboard from pairing with
the device. Disconnect the other (disrupting)
wireless device.
• If any of the keys do not seem to work when
using the keyboard, it could mean that
the settings in your smartphone or tablet are
not correctly set. Check that the language
setting is correct, e.g. English UK.
Samsung
• The keyboard language settings can be found
under Settings/My Device/Language and input
language. Click on the cog symbol to the right
of Samsung Keyboard/Input language.
iPhone/iPad
• Keyboard language settings are listed under
Settings/General/Keyboard/Keyboard/.
The current language setting will be displayed.
Click on the desired language to change.
31 × 11.3 × 0.7 cm
