Troubleshooting

Handheld/Basestation Wireless Communication:
Check that the Wireless Indicator LED is illuminated on the Handheld. If the Handheld is
communicating with the Basestation, the light will be on. Note: wireless communication overrides any
directly connected devices (i.e. Fingerwheel).
1. Check / replace Handheld batteries (page 9). Fast blinking LEDs indicate low batteries.
2. Power o the Handheld and Basestation. Power up the Basestation rst, then the Handheld.
3. Check all cable connections and make sure they are in their correct port and fully plugged in.
4. Make sure Handheld and Basestation antennae are tightly fastened.
5. Con rm Handheld and Basestation are on the same RF channel (page 17).
6. Check for RF/WiFi interference. If interference is present, select an alternate RF channel on
Handheld and Basestation (page 17).
7. Make sure you have properly performed a lens calibration (page 7, 11).
8. To eliminate the possibility of hardware issues, attempt a Direct Connect to test system function.
(Direct connect cable part #2-100-0012) If there is full system function in Direct Connect Mode,
contact support for further wireless diagnostics.
Handheld/Basestation Tethered Communication:
In tethered mode the Wireless LED on the Handheld will be o and the Direct LED on the Handheld
and the Basestation will be on. Note: wireless communication overrides any directly connected devices
(i.e. Fingerwheel).
1. Check / replace Handheld batteries (page 9). Fast blinking LEDs indicate low batteries.
2. Power o the Handheld and Basestation. Power up the Basestation rst, then the Handheld.
3. Check all cable connections and make sure they are in their correct port and fully plugged in.
4. Make sure you have properly performed a lens calibration (page 7, 11).
4
20
Troubleshooting
Motor:
Communication  Issues
1. Make sure you are using the right cable (part #2-100-0011) and that is fully plugged into the
motor port on the Basestation.
2. Make sure you have properly performed a lens calibration (page 7, 11)
Motor  Function
1. Motor won't calibrate
a. See Motor Communication section above.
b. See page 13 to ensure your motor is properly set up.
c. Adjust microGain until successful calibration (page 16)
2. Motor is loud, jittery and/or unresponsive
a. Check your power supply. (minimum 12VDC, 3A. maximum 18VDC, 3A)
c. Make sure the drive gear is properly seated (Flipping the Gear, page 12).
b. See page 13 to ensure your motor is properly set up.
Basestation:
1. See the appropriate communication section at the left for Basestation communication issues.
2. Motor attempts but fails to calibrate: red ashing lights on Basestation.
a. This occurs when the lens requires more torque than is available. Check to make sure your lens is
not jammed or the motor is not in a bind with the lens gear. Once checked, perform a lens
calibration (page 7, 11).
b. Adjust the microGain Matrix one increment at a time until a successful calibration has been
performed (page 16).
c. Attempt a calibration with the motor o the lens. Press AUTO, count to three, stop the drive gear
from turning, release. The motor will change direction. Count to three again, stop the drive gear
from turning, release.
Troubleshooting
21
