Aiphone IS-SS-HID Instructions

The IS-SS-HID is an IS-series door station and an HID ProxPoint Plus Card Reader, built onto the
same stainless steel faceplate. The card reader provides electronic access to a building through a
separate Access Control System, which is not supplied by Aiphone.
The IS-SS-HID can connect to the IS-CCU, IS-SCU, or IS-RCU control units.
IS-SS-HID

PACKAGE CONTENTS:

IS-SS-HID
Vandal-resistant Door Station
Flush backbox &
tamper-resistant screws
IS-SS-HID
Vandal Resistant Door Station
with Built in Proximity Card Reader
-INSTRUCTIONS-
1
2
3
4
Security Driver
Available from A1 Security Cameras
www.a1securitycameras.com email: sales@a1securitycameras.com
NAMES & FUNCTIONS:
1. Microphone
2. Speaker
3. Call button
4. Prox Reader

FEATURES:

• All-in-one solution: Communication product &
Card Reader
• If a card is missing or malfunctioning,
audio communication can provide user
verification
• Standard Wiegand output to access panel
• Convenience of installing combined components

INSTALLATION:

• For flush mounting, cut a hole in the wall and use the
supplied back box.
Box dimensions are: 11-3/4" H x 5-13/16" W x 1-3/4" D
• For surface mounting, use the SBX-ISDVFP surface
mount box.
This box can mount to a standard 1 gang box or to any
flat surface.
Pg. 1
