Philips VES15.1HE LA Service Manual

Philips VES15.1HE LA Service Manual

Chassis
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Colour Television
Contents
48")
2000 series 24"
2000 series 28"
2000 series 32"
2000 series 40"
2000 series 48"
Published by ASA/SC 1504 Consumer Care
©
2015
TP Vision Netherlands B.V.
All rights reserved. Specifications are subject to change without notice. Trademarks are the
property of Koninklijke Philips Electronics N.V. or their respective owners.
TP Vision Netherlands B.V. reserves the right to change products at any time without being obliged to adjust
earlier supplies accordingly.
PHILIPS and the PHILIPS' Shield Emblem are used under license from Koninklijke Philips Electronics N.V.
Page
2
2
5
9
18
21
22
25
32
33
34
35
36
37
38
Drawing PWB
39
41-42
43
45-46
47
56-57
58
59
60
61
62
63
64
65
66
Printed in the Netherlands
Chassis
VES15.1HE
Subject to modification
EN 3122 785 19830
LA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VES15.1HE LA and is the answer not in the manual?

Questions and answers

Related Manuals for Philips VES15.1HE LA

Summary of Contents for Philips VES15.1HE LA

  • Page 1: Table Of Contents

    Koninklijke Philips Electronics N.V. or their respective owners. TP Vision Netherlands B.V. reserves the right to change products at any time without being obliged to adjust earlier supplies accordingly. PHILIPS and the PHILIPS’ Shield Emblem are used under license from Koninklijke Philips Electronics N.V.

  • Page 2: Revision List

    EN 2 VES15.1HE LA Revision List 1. Revision List Manual xxxx xxx xxxx.0 • First release. 2. Technical Specs, Diversity, and Connections Index of this chapter: Technical Specifications 2.1 Technical Specifications For on-line product support please use the links in. Here is 2.2 Directions for Use...
  • Page 3 Technical Specs, Diversity, and Connections VES15.1HE LA EN 3 Connections 19830_100_152001.eps 152001 Figure 2-1 Connection overview (..T/12 series and ..P/12 series) back to 2015-Jan-20 div. table...
  • Page 4 EN 4 VES15.1HE LA Technical Specs, Diversity, and Connections Note: The following connector colour abbreviations are used - Video Red 0.7 V / 75 W (acc. to DIN/IEC 757): Bk= Black, Bu= Blue, Gn= Green, - Video Green 0.7 V / 75 W Gy= Grey, Rd= Red, Wh= White, Ye= Yellow.

  • Page 5: Precautions, Notes, And Abbreviation List

    Spare Parts the following points: • Route the wire trees correctly and fix them with the For the latest spare part overview, consult your Philips Spare mounted cable clamps. Part web portal. • Check the insulation of the Mains/AC Power lead for external damage.
  • Page 6 EN 6 VES15.1HE LA Precautions, Notes, and Abbreviation List result in sets which have the same CTN (Commercial Type 6 = play 16 : 9 format, 12 = play 4 : 3 Number; e.g. 28PW9515/12) but which have a different B.O.M.
  • Page 7 Precautions, Notes, and Abbreviation List VES15.1HE LA EN 7 Digital Noise Reduction: noise The SDI signal is self-synchronizing, reduction feature of the set uses 8 bit or 10 bit data words, and has DRAM Dynamic RAM a maximum data rate of 270 Mbit/s,...
  • Page 8 SOPS Self Oscillating Power Supply Serial Peripheral Interface bus; a 4-wire synchronous serial data link standard S/PDIF Sony Philips Digital InterFace SRAM Static RAM Service Reference Protocol Small Signal Board Spread Spectrum Clocking, used to reduce the effects of EMI...

  • Page 9: Mechanical Instructions

    Mechanical Instructions VES15.1HE LA EN 9 4. Mechanical Instructions Index of this chapter: Notes: 4.1 Cable Dressing • Figures below can deviate slightly from the actual situation, 4.2 Service Positions due to the different set executions. 4.3 Assembly/Panel Removal 4.4 Set Re-assembly Cable Dressing 19830_102_152001.eps...
  • Page 10 EN 10 VES15.1HE LA Mechanical Instructions 19830_103_152001.eps 152001 Figure 4-2 Cable dressing (24" 2000 series) 19830_104_152001.eps 152001 Figure 4-3 Cable dressing (28" 2000 series) back to 2015-Jan-20 div. table...
  • Page 11 Mechanical Instructions VES15.1HE LA EN 11 19830_105_152001.eps 152001 Figure 4-4 Cable dressing (32" 2000 series) 19830_107_152001.eps 152001 Figure 4-5 Cable dressing (40" 2000 series) back to 2015-Jan-20 div. table...
  • Page 12 EN 12 VES15.1HE LA Mechanical Instructions 19830_108_152001.eps 152001 Figure 4-6 Cable dressing (48" 2000 series) Service Positions Unscrew all the remaining screws [2]. (32") For easy servicing of a TV set, the set should be put face down Unscrew all the remaining screws [2], [3] and [4]. (48") on a soft flat surface, foam buffers or other specific workshop 3.
  • Page 13 Mechanical Instructions VES15.1HE LA EN 13 4 × 12 3 × 11 19830_109_152001.eps 152001 Figure 4-7 Rear cover removal (19") M3 × 5 3,5 × 13 19830_110_152001.eps 152001 Figure 4-8 Rear cover removal (24") back to 2015-Jan-20 div. table...
  • Page 14 EN 14 VES15.1HE LA Mechanical Instructions M4 x 10 3,5 x 13 3 x 11 19830_111_152001.eps 152001 Figure 4-9 Rear cover removal (28") M4 x 10 3,5 x 13 19830_112_152001.eps 152001 Figure 4-10 Rear cover removal (32") back to 2015-Jan-20...
  • Page 15 Mechanical Instructions VES15.1HE LA EN 15 M4 x 12 3,5 x 13 3 x 11 19830_114_152001.eps 152001 Figure 4-11 Rear cover removal (40") M4 x 12 M6 x 10 3,5 x 13 3 x 11 19830_115_152001.eps 152001 Figure 4-12 Rear cover removal (48")
  • Page 16 EN 16 VES15.1HE LA Mechanical Instructions 4.3.3 Speakers 4.3.9 IR/LED Board (19") 1. Unplug the connector from SSB. 1. Remove the back cover as described earlier. 2. Release the cables from their clamps. (if any) 2. Unplug the connector that connects the board with the 3.
  • Page 17 Mechanical Instructions VES15.1HE LA EN 17 Notes: • While re-assembling, make sure that all cables are placed and connected in their original position. See Figure 4-1, Figure 4-2, Figure 4-3, Figure 4-4, Figure 4-5 Figure 4-6. • Pay special attention not to damage the EMC foams on the SSB shields.

  • Page 18: Service Modes And Fault Finding

    EN 18 VES15.1HE LA Service Modes and Fault Finding 5. Service Modes and Fault Finding Index of this chapter: number is written in the NVM. 5.1 Test Points - If the NVM is fresh, the software identification, version, 5.2 Service Modes and cluster will be written to NVM.

  • Page 19: Software Upgrading

    RED button at FTI screen in Hotel TV mode. stand alone set. A description on how to upgrade the main Software file name should be “VES151HE_upgrade.bin”. software can be found in the DFU or on the Philips website. 5.3.6 How to Copy NVM Data to/from USB 5.3.2...
  • Page 20 EN 20 VES15.1HE LA Service Modes and Fault Finding some of them are available on USB, the available ones are 5.4.8 Staying in Stand-by Mode copied. If no USB is connected, nothing happens. Note: For Clone function USB stick (Copy to USB - Copy from This problem indicates a short on V voltages.

  • Page 21: Alignments

    Alignments VES15.1HE LA EN 21 6. Alignments Index of this chapter: White Point Alignments 6.1 General Alignment Conditions Steps for white point alignment are listed below 6.2 Hardware Alignments 6.3 Software Alignments • Run the PC 6.4 White Point Alignments •...

  • Page 22: Circuit Descriptions

    Layouts).Where necessary, you will find a separate drawing for clarification. Introduction VES15.1HE LA main board is driven by MStar SOC. This IC is a single chip IDTV solution that supports channel decoding, MPEG decoding, and media-centre functionality enabled by a high performance AV CODEC and CPU.
  • Page 23 Circuit Descriptions VES15.1HE LA EN 23 7.1.2 SSB Cell Layout DC-DC CI Socket NAND Flash LVDS Sockets Serial Flash Main IC HDMI Side Sockets Tuner Audio Amp 19830_204_152001.eps 152001 Figure 7-1 SSB layout cells (top view) back to 2015-Jan-20 div. table...

  • Page 24: Power Management

    PSU is not broken. Always replace a defective fuse with one with the correct specifications! This part is available in the regular market. DIMMING Consult the Philips Service web portal for the order codes of the boards. BACKLIGHT_ON/OFF STBY_ON/OFF The output voltages to the chassis are: PIN11 •...

  • Page 25: Ic Data Sheets

    IC Data Sheets VES15.1HE LA EN 25 8. IC Data Sheets This chapter shows the internal block diagrams and pin electrical diagrams (with the exception of “memory” and “logic” configurations of ICs that are drawn as “black boxes” in the ICs).
  • Page 26 EN 26 VES15.1HE LA IC Data Sheets Diagram 10-3-4 B04, Tuner, USB, WiFi, TPS2553-1 (IC U2) Block diagram Reverse Voltage Comparator Current Sense Charge Pump Current Driver Limit FAULT (Note A) UVLO Thermal Sense ILIM Pinning information TPS2552/TPS2553 (TOP VIEW)
  • Page 27 IC Data Sheets VES15.1HE LA EN 27 Diagram 10-3-5 B05, Power, APL5910 (IC U5) Block diagram VCNTL Power- Thermal On-Reset VCNTL Shutdown (POR) 5µA Control Logic Enable Soft-Start 0.8V VOUT 0.8V Error Amplifier Dela Current-Limit Short Current-Limit Pinning information VOUT VCNTL 19830_301_152001.eps...
  • Page 28 EN 28 VES15.1HE LA IC Data Sheets Diagram 10-3-5 B05, Power, TPS54528 (IC U9) Block diagram Logic VREG5 VBST Control Logic 1 shot XCON VREG5 VREG5 Ceramic Capacitor SGND Softstart PGND PGND SGND PGND Protection UVLO VREG5 Logic UVLO Pinning information...
  • Page 29 IC Data Sheets VES15.1HE LA EN 29 Diagram 10-3-5 B05, Power, TPS65251 (IC U19) Block diagram TPS65251 AGND ROSC INTERNAL SYNC VOLTAGE RAILS 12V DC Supply BST1 Vout BUCK1 VIN1 BUCK1 from enable logic COMP1 Rlim1 BST2 Vout BUCK2 VIN2...
  • Page 30 EN 30 VES15.1HE LA IC Data Sheets Diagram 10-3-7 B07, Audio, Headphone, TAS5719 (IC U35) Block diagram OUT_A 2 HB FET Out Serial OUT_B Order SDIN Audio Noise Port (DAP) Shaper OUT_C 2 HB FET Out OUT_D Protection Logic MCLK...
  • Page 31 IC Data Sheets VES15.1HE LA EN 31 Diagram 10-3-7 B07, Audio, Headphone, DRV632 (IC U16) Block diagram DRV632 +INL +INR Line Line Driver Driver –INL –INR OUTL OUTR Click and Pop Short-Circuit Suppression Protection Mute Bias Circuitry Pinning information DRV632...

  • Page 32: Block Diagrams

    Block Diagrams VES15.1HE LA EN 32 9. Block Diagrams Wiring diagram 2000 series 19" WIRING DIAGRAM 19" (2000 series) Board Level Repair Component Level Repair Only for authorized workshops to panel (M2) MAIN POWER SUPPLY (M3) TV ANTENNA SPDF OUT...

  • Page 33: Wiring Diagram 2000 Series 28

    Block Diagrams VES15.1HE LA EN 33 Wiring diagram 2000 series 24" WIRING DIAGRAM 24" (2000 series) Board Level Repair Component Level Repair Only for authorized workshops (M2) MAIN POWER MAIN POWER MAIN POWER SUPPLY (M3) TV ANTENNA SPDF OUT (RGB/CVBS)

  • Page 34: Wiring Diagram 2000 Series 40

    Block Diagrams VES15.1HE LA EN 34 Wiring diagram 2000 series 28" WIRING DIAGRAM 28" (for 2000 series) Board Level Repair Component Level Repair Only for authorized workshops (M2) MAIN POWER SUPPLY (M3) HDMI TV ANTENNA SIDE AV SPDIF OUT CN27...
  • Page 35 Block Diagrams VES15.1HE LA EN 35 Wiring diagram 2000 series 32" WIRING DIAGRAM 32" (for 2000 series) Board Level Repair Component Level Repair Only for authorized workshops (M2) MAIN POWER SUPPLY (M3) HDMI TV ANTENNA SIDE AV SPDIF OUT CN27...
  • Page 36 Block Diagrams VES15.1HE LA EN 36 Wiring diagram 2000 series 40" WIRING DIAGRAM 40" (for 2000 series) Board Level Repair Component Level Repair Only for authorized workshops (M2) HDMI TV ANTENNA MAIN POWER SIDE AV SPDIF OUT SUPPLY (M3) CN27...
  • Page 37 Block Diagrams VES15.1HE LA EN 37 Wiring diagram 2000 series 48" WIRING DIAGRAM 48" (for 2000 series) Board Level Repair Component Level Repair Only for authorized workshops (M2) MAIN POWER SUPPLY (M3) HDMI TV ANTENNA SIDE AV SPDIF OUT CN27...

  • Page 38: Block Diagram 2000 Series Mb95M Platform

    Block Diagrams VES15.1HE LA EN 38 Block diagram 2000 series MB95M platform D ^ D D 9B9&& 9B9&& [: RU [: 9B9&& s d [: s d 9B9&& ''5 5$0 ''5 5$0 9B9&& s ^ ^ 0[ELW RU 0[ELW RU 9B9&&...

  • Page 39: Circuit Diagrams And Pwb Layouts

    Circuit Diagrams and PWB Layouts VES15.1HE LA EN 39 10. Circuit Diagrams and PWB Layouts 10.1 A 17ips61-3p1 19", 24" and 28" Slim Integrated Power Supply 10-1-1 19", 24" and 28" Slim Integrated Power Supply RL207 RL207 SB5100 275V RL207...
  • Page 40 Circuit Diagrams and PWB Layouts VES15.1HE LA EN 40 10-1-2 19", 24" and 28" Slim Integrated Power Supply BA159 Vled+ 12V_24V_CON SB5100 OVP_LED 1N4148 FQD7N10L COMP VCC1 100n BKL_ON/OFF 12V_24V_CON Vled+ Vled BC858B 330R DBRT GATE 100R PWM_DIM 100n BC848B...
  • Page 41 Circuit Diagrams and PWB Layouts VES15.1HE LA EN 41 10-1-3 Layout top Power Supply layout top 17ips61-3p1 19830_502_152001.eps 152001 back to 2015-Jan-20 div. table...
  • Page 42 Circuit Diagrams and PWB Layouts VES15.1HE LA EN 42 10-1-4 Layout bottom Power Supply layout bottom 17ips61-3p1 19830_503_152001.eps 152001 back to 2015-Jan-20 div. table...

  • Page 43: A 17Ips71P-R4 32", 40" And 48" Power Supply

    Circuit Diagrams and PWB Layouts VES15.1HE LA EN 43 10.2 A 17ips71p-r4 32", 40" and 48” Power Supply 10-2-1 32", 40" and 48" Slim Integrated Power Supply R305 12V RCD SNUBBER OPTION R306 XCAPS BA159 PINGOOD OPTIONS R308 C315 100n...
  • Page 44 Circuit Diagrams and PWB Layouts VES15.1HE LA EN 44 10-2-2 32", 40" and 48" Slim Integrated Power Supply OUTPUT DIODE RC SNUBBER CIRCUIT C300 Tapped Coil Option CON_AC C50 V_LED+ C301 BOOST INPUT VOLTAGE +24VCC POWER BOARD to LED BARS CONNECTION...
  • Page 45 Circuit Diagrams and PWB Layouts VES15.1HE LA EN 45 10-2-3 Layout top Power Supply layout top 17ips71p-r4 19830_506_152001.eps 152001 back to 2015-Jan-20 div. table...
  • Page 46 Circuit Diagrams and PWB Layouts VES15.1HE LA EN 46 10-2-4 Layout bottom Power Supply layout bottom 17ips71p-r4 19830_507_152001.eps 152001 back to 2015-Jan-20 div. table...

  • Page 47: B 17Mb95M-R3A Ssb

    Circuit Diagrams and PWB Layouts VES15.1HE LA EN 47 10.3 B 17mb95m-r3a SSB 10-3-1 B01, HDMI/GPIO protection HDMI/GPIO protection HDMI0_5V HDMI0_RX0N RXA0N HDMI0_HPDIN HDMI0_RX0P HDMI0_RX2P RXA0P RXC0N HDMI0_RX1N RXA1N RXC0P HDMI2_RX2P HDMI0_RX2N HDMI0_RX1P RXA1P RXC1N R141 HDMI0_RX2N HDMI0_RX1P RXA2N RXC1P...
  • Page 48 Circuit Diagrams and PWB Layouts VES15.1HE LA EN 48 10-3-2 B02, MStar, DDR3 MStar, DDR3 1V5_VCC 1V5_VCC C257 C258 C259 C260 C261 C262 C264 C265 C266 C268 DDR0_VREFCA DDR1_VREFDQ 100n 100n 100n 100n 100n 100n 100n 100n 100n 100n R410...
  • Page 49 Circuit Diagrams and PWB Layouts VES15.1HE LA EN 49 10-3-3 B03, CI, Ethernet, Nand CI, Ethernet, Nand NAND_ALE NF_ALE PCM_D[0]/NF_AD[0] PCMNANDD0 AD22 NC29 NAND_WPZ NF_WPZ PCM_D[1]/NF_AD[1] PCMNANDD1 Place these resistors AB21 NAND_CEZ NF_CEZ PCM_D[2]/NF_AD[2] PCMNANDD2 close to MSTAR AC21 AE17...
  • Page 50 Circuit Diagrams and PWB Layouts VES15.1HE LA EN 50 10-3-4 B04, Tuner, USB, WiFi Tuner, USB, WiFi 3V3_VCC_TUNER 24MHz USB & WIFI 30051799 I2C ADDR: C0 C158 C161 TP96 30010731 27MHz Q131 C344 BC858B 1V8_VCC_TUNER TP91 6 IO4 C348 C471...
  • Page 51 Circuit Diagrams and PWB Layouts VES15.1HE LA EN 51 10-3-5 B05, Power Power 3V3_STBY W/B2CABLE LDO1 DC/DC1 12V_STBY R822 30069495 560R LM1117 TP72 TP119 5V_STBY 3V3_STBY DC/DC3 C1213 C1214 C119 VOUT C475 C472 R394 R644 TP120 TP121 100n 100k 120k...
  • Page 52 Circuit Diagrams and PWB Layouts VES15.1HE LA EN 52 10-3-6 B06, LVDS LVDS OPTIONS TABLE PANEL SUPPLY SWITCH FHD 50Hz 3D FFC R298 OP_PIN4 3V3_VCC C140 100u R297 3D_SYNC_OUT R239 12V_VCC PANEL_VCC PANEL_VCC OP_PIN5 5V_VCC R299 PANEL_VCC 3V3_VCC R236 R175...
  • Page 53 Circuit Diagrams and PWB Layouts VES15.1HE LA EN 53 10-3-7 B07, Audio, Headphone Audio, Headphone TP93 DSP_MAIN_L_OUT MAIN_L HP_L CLOSE TO MSTAR IC MSD8WB9BX TP94 C453 C1200 LINEIN_L0 R653 AA12 LINEIN_R0 DSP_SC_L_OUT SC_L_OUT HP_R AA11 LINEIN_L2 C548 AB11 C586 LINEIN_R2...
  • Page 54 Circuit Diagrams and PWB Layouts VES15.1HE LA EN 54 10-3-8 B08, MST supply, keyboard MST supply, keyboard 3V3_VCC VDD33 100n 100n 3V3_VCC AVDD_LPLL 100n 100n VDDC C1203 AVDD_MOD VDDC 2V5_VCC 100n 1V5_VCC AVDD_DDR0 3V3_STBY AVDD_DVI 3V3_STBY AVDD_DMPLL C400 C446 C443...
  • Page 55 Circuit Diagrams and PWB Layouts VES15.1HE LA EN 55 10-3-9 B09, Audio/video I/O, DVD Audio/video I/O, DVD INDIA OPTION SC_CVBS_IN R419 5V_VCC SCART 1 12V_VCC 220R C854 TP43 SCART_AUD_L_IN VGA INPUT C383 100n SCART_AUD_R_IN VGA_DDC_5V BC858B 24C02 option C211 TP63...
  • Page 56 Circuit Diagrams and PWB Layouts VES15.1HE LA EN 56 10-3-10 Layout top SSB layout top 17mb95m-r3a 19830_518_152001.eps 152001 back to 2015-Jan-20 div. table...
  • Page 57 Circuit Diagrams and PWB Layouts VES15.1HE LA EN 57 10-3-11 Layout bottom SSB layout bottom 17mb95m-r3a 19830_519_152001.eps 152001 back to 2015-Jan-20 div. table...

  • Page 58: J 17Ld141-2 Ir/Led (2000 Series 19")

    Circuit Diagrams and PWB Layouts VES15.1HE LA EN 58 10.4 J 17LD141-2 IR/LED (2000 series 19") 10-4-1 IR/LED LED/IR 100R 2012-03-05 LED/IR 17LD141-2 19420_515_130314.eps 130314 back to 2015-Jan-20 div. table...

  • Page 59: J 17Ld155-R4 Ir/Led (2000 Series 24")

    Circuit Diagrams and PWB Layouts VES15.1HE LA EN 59 10.5 J 17LD155-R4 IR/LED (2000 series 24") 10-5-1 IR/LED LED/IR 100R GND1 100n 100n GND2 100n LED/IR 17LD155-R4 19830_520_152001.eps 152001 back to 2015-Jan-20 div. table...

  • Page 60: J 17Ld160-R6 Ir/Led (2000 Series 28", 32", 40", 48")

    Circuit Diagrams and PWB Layouts VES15.1HE LA EN 60 10.6 J 17LD160-R6 IR/LED (2000 series 28", 32", 40", 48") 10-6-1 IR/LED LED/IR 100R GND1 100n 100n GND2 100n LED/IR 17LD160-R6 19830_521_152001.eps 152001 back to 2015-Jan-20 div. table...

  • Page 61: Styling Sheets

    Styling Sheets VES15.1HE LA EN 61 11. Styling Sheets 11.1 2000 series 19" 19" Pos No. Description Remarks LCD panel SSB (Small Signal Board) PSU (Power Supply Unit) Loudspeaker IR Board Front Cabinet Back Cabinet Remote Control Not displayed Detachable AC Cord...
  • Page 62 Styling Sheets VES15.1HE LA EN 62 11.2 2000 series 24" 24" Pos No. Description Remarks LCD panel SSB (Small Signal Board) PSU (Power Supply Unit) Loudspeaker IR Board Front Cabinet Back Cabinet Remote Control Not displayed Detachable AC Cord Not displayed...
  • Page 63 Styling Sheets VES15.1HE LA EN 63 11.3 2000 series 28" 28" Pos No. Description Remarks LCD panel SSB (Small Signal Board) PSU (Power Supply Unit) Loudspeaker IR Board Front Cabinet Back Cabinet Remote Control Not displayed Detachable AC Cord Not displayed...
  • Page 64 Styling Sheets VES15.1HE LA EN 64 11.4 2000 series 32" 32" Pos No. Description Remarks LCD panel SSB (Small Signal Board) PSU (Power Supply Unit) Loudspeaker IR Board Front Cabinet Back Cabinet Remote Control Not displayed Detachable AC Cord Not displayed...

  • Page 65: Series

    Styling Sheets VES15.1HE LA EN 65 11.5 2000 series 40" 40" Pos No. Description Remarks LCD panel SSB (Small Signal Board) PSU (Power Supply Unit) Loudspeaker IR Board Front Cabinet Back Cabinet Remote Control Not displayed Detachable AC Cord Not displayed...
  • Page 66 Styling Sheets VES15.1HE LA EN 66 11.6 2000 series 48" 48" Pos No. Description Remarks LCD panel SSB (Small Signal Board) PSU (Power Supply Unit) Loudspeaker IR Board Front Cabinet Back Cabinet Remote Control Not displayed Detachable AC Cord Not displayed...
