- Page 1 WWW.AAPRODUCTSINC.COM Instruction Manual HX501 ( BLK & WHT ) Capactiy Extendable Pick-up Truck Rack With Protective Screen Set...
- Page 2 Read, understand and follow all warnings and instructions before using this product. Failure to follow these directions may result in property damage, serious bodily injury, and/or death. AA Products Inc. is not responsible for any property damage, personal injury, or death occurred while using any AA-Racks products. Retain these instructions for future reference.
-
Page 3: Assembling The Rack
NSTRUCTION MANUAL AAPRODUCTSINC For Technical Support Call:1-888-806-3972 / 626-332-4245 NSTALLATION INSTRUCTION ASSEMBLING THE RACK: 1） Find the Left & Right Mounting Bases; insert them to the bottom of the Screen. Secure with M10*60 Bolt （Note: Do not tighten the bolts and nuts） 2）... - Page 4 NSTRUCTION MANUAL AAPRODUCTSINC For Technical Support Call:1-888-806-3972 / 626-332-4245 NSTALLATION DIAGRAM Assembling The Rack: TEP 1 Put the assembly onto the bed-rail, adjust the mounting bases to set the desired position for installation. Adjustable Bolt M10 * 60 & Lock Nut &...
- Page 5 NSTRUCTION MANUAL AAPRODUCTSINC For Technical Support Call:1-888-806-3972 / 626-332-4245 C-Clamp Mounting Installation: (The C-Clamps installation might be limited due to different bed-rail structures varied from different Make & Models, cutting of bed-liners might be required for C-clamp Mounting installation) TEP 1 TEP 2 SSEMBLY COMPLETION...
- Page 6 NSTRUCTION MANUAL AAPRODUCTSINC For Technical Support Call:1-888-806-3972 / 626-332-4245 Stake Pocket Mounting Installation: (Only work for pick-up trucks come with Stake Pockets on the bed-rail, this option might not be available for certain Make & Models even if it comes with stake pockets on the bed-rail) TEP 1 Mark as needed...
- Page 7 AA PRODUCTS INC™ WARRANTY AA Products Inc™ will warranty all truck and van products for the life of the product, and all accessories for a period of one years from the date of purchase. Subject to the limitations and exclusions described in this warranty, AA Products Inc™ will remedy defects in the structural integrity of the product related to materials or workmanship by repairing or replacing, at its discretion, a defective product without charge for parts or labor.
- Page 8 WARNING Contact us : Service@aaproductsinc.com which are known to the State of California to cause cancer or birth defects or Toll Free:1-888-806-3972 other reproductive harm. For more information, visit www.P65warnings.ca.gov 626-332-4245...
