- Page 1 MODEL 3101C-TJ101 DELAY EGRESS SYSTEM 705 Emmett Street Bristol, CT 06010 WIRING INSTRUCTIONS 1-877-DynaLock www.dynalock.com...
-
Page 2: Basic Setup
MODEL 3101C-TJ101 DELAY EGRESS SYSTEM 705 Emmett Street Bristol, CT 06010 WIRING INSTRUCTIONS 1-877-DynaLock www.dynalock.com BASIC SET-UP Remove the Electronics Cover to expose the circuit board assembly. - System Selector Switches The selector switches (S3) which control major system functions are factory set to the OFF position for basic lock operation. -
Page 3: Basic Wiring
“FA” - page 6). DO NOT APPLY POWER TO TERMINALS 3 & 4 OR CIRCUIT BOARD DAMAGE WILL OCCUR. When the fire panel trips, the 3101C-TJ101 will release, the audible will sound a constant tone and the bi-color LED (LED1) will change to green. - Page 4 With the door closed and latched apply input power to terminals 1 & 2. Slide selector switch (DS1) #1 to the ON position to activate the Set-Up mode. EGRESS SENSOR Rotate the on-board keyswitch counter-clockwise. The 3101C-TJ101 should ADJUSTMENT WHEEL now be unlocked (LED1-OFF).
-
Page 5: Audible Signal
MODEL 3101C-TJ101 DELAY EGRESS SYSTEM 705 Emmett Street Bristol, CT 06010 WIRING INSTRUCTIONS 1-877-DynaLock www.dynalock.com SEPERATE 7050 KEYSWITCH OPERATION POSITION DESCRIPTION CENTER NORMAL / LOCKED CLOCKWISE (SPRING LOADED) RESET AFTER DELAY EGRESS ALARM COUNTER-CLOCKWISE BYPASS / UNLOCKED WITHOUT ALARM INDICATOR & AUDIBLE DESCRIPTIONS... -
Page 6: Optional Set-Up
MODEL 3101C-TJ101 DELAY EGRESS SYSTEM 705 Emmett Street Bristol, CT 06010 WIRING INSTRUCTIONS 1-877-DynaLock www.dynalock.com OPTIONAL SET-UP - System Selector Switches Set the System Selector Switches (S3) to address your specific system requirements. The normal factory setting is all switches off. - Page 7 LED 1 located on the 7050 faceplate. The 3101C-TJ101 circuit board is supplied with flying lead connections for LED 1 and the 7050 key switch. These leads must be connected to match the same color flying leads coming from the 7050-LED. (See above illustration).
-
Page 8: Option Wiring
MODEL 3101C-TJ101 DELAY EGRESS SYSTEM 705 Emmett Street Bristol, CT 06010 WIRING INSTRUCTIONS 1-877-DynaLock www.dynalock.com OPTION WIRING 3101B CIRCUIT BOARD 3101C-TJ101 CIRCUIT BOARD OPTIONAL STANDARD OUTPUT TERMINALS INPUT/OUTPUT TERMINALS (TYPICAL - ALL MODELS) (AS ORDERED) 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24... -
Page 9: Typical Wiring
MODEL 3101C-TJ101 DELAY EGRESS SYSTEM 705 Emmett Street Bristol, CT 06010 WIRING INSTRUCTIONS 1-877-DynaLock www.dynalock.com OPTION WIRING MONITORING OUTPUT DESCRIPTIONS TYPICAL WIRING DELAY EGRESS OUTPUT NC C NO 13 14 15 Delay egress alarm monitoring. SPDT dry relay contacts rated 1Amp @ 24 Volts... - Page 10 3101C-TJ101 CIRCUIT BOARD NOTES: Harnesses J6 and J8 are only present if the 3101C-TJ101 is equipped with the DYN - Dynastat Force Sensor and/or DSM - Door Status Switch Options. Observe polarity when re-connecting the J5 and J8 harness connectors. Orient these connectors with respect to harness wire colors as follows: Harness connectors J3 and J6 are not polarity sensitive.
-
Page 11: Installer Notes
MODEL 3101C-TJ101 DELAY EGRESS SYSTEM 705 Emmett Street Bristol, CT 06010 WIRING INSTRUCTIONS 1-877-DynaLock www.dynalock.com INSTALLER NOTES Page 11 3101C-TJ101 MANUAL 06/14... - Page 12 PLEASE DELIVER THIS MANUAL AND THE KEYS TO THE END USER UPON COMPLETION OF THE 3101C-TJ101 INSTALLATION FOR PRODUCT SUPPORT AND PARTS ORDERING INFORMATION CONTACT: DynaLock Corp. 705 Emmett Street Bristol, CT 06010 Bus: (877) 396-2562 Toll-Free USA (860) 582-4761...
