Axle Positions
Below is shown the possible axle positions. Axle position adjustment allows for change in
height and front-to-back balance of the Pyroweeder. Swap left and right axles for some
of the illustrated positions. (Ships in position
Flame Blade. In positions and the Pyroweeder will tend to be more front heavy
L3 H3
which some may prefer.
L1 L2 L3
H1 H2 H3
Lower ground clearance
L2
L1
Higher ground clearance
H2
H1
16
Well-designed, quality tools and equipment
.) Try positions or when using the
L2 L1 H1
Narrower Wheel Track
Reduce wheel track to 30 1⁄2" (outside to outside) by
mounting the axle on the bottom of the main bar.
L3
H3
| farmersfriendllc.com
O P T I O N A L F L A M E B L A D E C O N F I G U R A T I O N
Attaching the Flame Blade Accessory
7⁄16
Tools Needed: " socket or wrench and a Phillips screwdriver
1.
Remove the 1⁄ 4 "-20 nuts and 1⁄ 4 " oversize
A
washers from the 1⁄ 4 "-20 carriage bolts
B
protruding through the bottom panel
C
of the flame blade.
2.
Open up space at back of the two pan-
els—clam shell style—as shown, pivoting
on the front screws .
E
3.
Insert the Pyroweeder burners through
F
the cutouts in the top and bottom
G
panels as shown. Keep about 1" of the
burner outside of the flame blade.
H
C
E
D
A
↑ Pictured: Flame Blade 30
CAUTION
It is important that you ignite the propane flowing
into the flame blade as soon as possible after you
open the control valve. Propane can accumulate in
and around the blade and will produce a startling
pop if you are slow to ignite it. A torch or lighter
work best.
(931) 583-0397 | support@farmersfriendllc.com
4.
Close the two panels around the burners
so that the carriage bolts are again
C
protruding through the bottom panel
D
5.
Re-attach the nuts and washers
A
to the carriage bolts and tighten just
C
enough so that the flame blade is securely
attached to the burners.
6.
Tighten the front screws .
E
H About 1" out
G
F
B
Positioner Installation Location
.
D
B
