SIRIO
FR-TMA
D811231 02-12-02 Vers. 09
CONTROL UNIT

Advertisement

loading
Need help?

Need help?

Do you have a question about the SIRIO FR-TMA and is the answer not in the manual?

Questions and answers

Summary of Contents for BFT SIRIO FR-TMA

  • Page 1 SIRIO FR-TMA D811231 02-12-02 Vers. 09 CONTROL UNIT...
  • Page 2 SIRIO FR-TMA SIRIO FR-TMA Thank you for buying this product, our company is sure that you will be more • Anything which is not expressly provided for in the present instructions, than satisfied with its performance. This product is supplied with an is not allowed.
  • Page 3 SIRIO FR-TMA SIRIO FR-TMA 26-28 Block button (n.c.). Additional buttons to be connected in series When connecting two rubber edges and one photocell, F1 and F2 in fig.5 with one another. “D” become 2 rubber edges, and C1 one photocell; invert the connections 26-29 Photocell contact input (n.c.).
  • Page 4 SIRIO FR-TMA SIRIO FR-TMA with continuously active beams). This is used to connect IR edges which have not been checked or have internal self-diagnosing system, and always provide a voltage-free output contact. OFF - The IR edge devices are included in the Ok safety check cycle which is carried out before each manoeuvre.
  • Page 5 SIRIO FR-TMA SIRIO FR-TMA Fig. 1 Cavallotto di messa a terra Gruppo fusibili Sezionatore U-link for earth connection Fuse set Knife switch Crampillon de mise à la terre Groupe fusibles Disjoncteur Erdanschlussklemmen Sicherungsgruppe Trennschalter Perno de U de toma de tierra...
  • Page 6 SIRIO FR-TMA SIRIO FR-TMA Fig. 3 Fig. 4 Legenda 24VAC P1: Pulsante arresto a bordo quadro SIRIOTMA MPU: Micro controllo porta passo uomo M1-M2: Micro controllo rottura molle P1: Stop button on panel MPU: Check micro for pedestrian access Dip 9...
