- Page 1 Inspiron 20 3000 Setup and Specifications Regulatory Model: W15B Regulatory Type: W15B005...
- Page 2 Notes, cautions, and warnings NOTE: A NOTE indicates important information that helps you make better use of your product. CAUTION: A CAUTION indicates either potential damage to hardware or loss of data and tells you how to avoid the problem. WARNING: A WARNING indicates a potential for property damage, personal injury, or death.
-
Page 3: Table Of Contents
Contents 1 Set up your computer........................4 2 Views............................7 Front......................................7 Left......................................8 Right......................................8 Back......................................9 Tilt......................................10 3 Specifications..........................12 Dimensions and weight................................12 System information................................13 Memory....................................13 Communications...................................13 Audio...................................... 14 Storage....................................14 Media-card reader................................14 Display....................................14 Camera....................................15 Ports and connectors................................15 Video...................................... -
Page 4: Set Up Your Computer
Set up your computer CAUTION: Place the computer on a soft and clean surface to avoid scratching the display. 1. Set up the stand. Easel stand - Lift the stand riser. Pedestal stand a) Lift the stand riser. b) Attach the base. c) Tighten the captive screw to secure the base to the stand riser. - Page 5 2. Connect the keyboard and mouse. NOTE: For setup instructions, see the documentation shipped with the keyboard and mouse. 3. Connect the power adapter. WARNING: Route the power-adapter cable through the routing guide on the stand to avoid potential damage to the power adapter and to avoid the unexpected system power-off when the stand is moved to a different orientation.
- Page 6 Figure 1. Connecting to your network b) Sign in to your Microsoft account or create a local account. Figure 2. Signing in to your Microsoft account or create a local account For Ubuntu: Follow the instructions on the screen to finish setup. 6.
-
Page 7: Views
Views Front Figure 3. Front view 1. Microphone (for touchscreen model) Provides digital sound input for audio recording, voice calls, and so on. 2. Camera Enables you to video chat, capture photos, and record videos. 3. Camera-status light Turns on when the camera is in use. 4. -
Page 8: Left
Left Figure 4. Left view 1. Media-card reader Reads from and writes to media cards. 2. USB 3.0 ports (2) Connect peripherals such as external storage devices and printers. Provides data transfer speeds up to 5 Gbps. 3. Headset port Connect headphones or a headset (headphone and microphone combo). -
Page 9: Back
Press to increase or decrease the display brightness. 3. Input-source selection button Press to select the video-input source. 4. Power button Press to turn on the computer if it is turned off, in sleep state, or in hibernate state. Press to put the computer in sleep state if it is turned on. Press and hold for 4 seconds to force shut-down the computer. -
Page 10: Tilt
Tilt Easel stand Pedestal stand Views... - Page 11 Views...
-
Page 12: Specifications
Specifications Dimensions and weight Height 317.64 mm (12.51 in) Width 480.52 mm (18.92 in) Depth • Touch screen – 33.10 mm (1.30 in) • Non-touch screen – 34.20 mm (1.35 in) Weight without stand: Touch screen 4.21 kg (9.28 lb) Non-touch screen 3.43 kg (7.56 lb) NOTE:... -
Page 13: System Information
Pedestal stand (maximum dimensions) 383.02 mm (15.08 in) 205.00 mm (8.07 in) 387.11 mm (15.24 in) System information Table 2. System information Computer model Inspiron 20-3064 Processor • 7th Generation Intel Core i3 • 7th Generation Intel Core i5 System chipset Integrated in processor Memory Table 3. -
Page 14: Audio
Audio Table 5. Audio specifications Controller Realtek ALC3661 Waves MaxxAudio Pro Speakers Speaker Output • Average: 3 W • Peak: 3.50 W Microphone Digital-array microphones Volume controls Program menus Storage Table 6. Storage specifications Interface • SATA 3 Gbps for optical drive •... -
Page 15: Camera
Camera Table 9. Camera specifications Resolution • Still image: 0.92 megapixels • Video: 1280 x 720 at 30 FPS (maximum) Diagonal viewing angle 74 degrees Ports and connectors Table 10. Ports and connectors specifications External Network One RJ45 port • Two USB 2.0 ports •... -
Page 16: Stand
Stand Table 14. Stand Easel Pedestal Height 174.80 mm (6.88 in) 184.17 mm (7.25 in) Width 120 mm (4.72 in) 204.98 mm (8.07 in) Depth 22.48 mm (0.89 in) 13.90 mm (0.55 in) Weight 0.56 kg (1.23 lb) 1.50 kg (3.31 lb) Computer environment Airborne contaminant level: G1 as defined by ISA-S71.04-1985 Table 15. -
Page 17: Getting Help And Contacting Dell
Getting help and contacting Dell Self-help resources You can get information and help on Dell products and services using these self-help resources: Table 16. Self-help resources Information about Dell products and services www.dell.com Dell Help & Support app Get started app Accessing help in Windows 10 In Windows search, type Help and Support, and press Enter.
