- Page 1 PRECISION TABLET CALIPER MICROTECH Patent #100613 Serial № ISO 17025:2005 (cert. № 4K051) Quality management system ISO 9001:2015 (cert. № U228396) www.microtech.ua...
- Page 2 1 MAIN SPECIFICATIONS Range, Resolution, Max error, Item № Force, N 14109805X 0-500 0.001 ±0.020 14109810X 0-1000 0.001 ±0.030 14109815X 0-1500 0.001 ±0.030 14109820X 0-2000 0.001 ±0.040 о о Operating conditions from +10 С to +35 С. *Optionally Tablet caliper can be equipped with outside Pyrometer for Temperature compensation.
- Page 3 Android devices or Windows PC (on these devices must be installed MICROTECH SPC software). 2.7 Also you can connect other Wireless MICROTECH devices to this caliper for receiving and collecting data. (It’s necessary to switch on Bluetooth module throw Android settings).
- Page 4 Results 21,2 30,0 41,3 51,4 71,5 101,6 External 126,8 measurement 131,4 175,6 225,7 243,5 281,2 400,0 500,0 Parallelism of measuring surfaces Flatness of measuring surfaces μ Roughness of measuring surfaces Ra<0.32 Head of the MICROTECH calibration lab. _____ /Tatyana Guz/...
