USER MANUAL
NOTICE D'UTILISATION - ANGLAIS
PIED A COULISSE INTELLIGENT CONNECTÉ Série E-INK
For charging connect USB cable
MICROTECH
MODIFICATIONS
ZERO button - Set Zero
ZERO button 5sec - Off
MENU button - Menu
MENU button 2sec - Resolution, mm/inch
DATA button - Save or Send Data value
DATA button 2sec - Memory
MENU+DATA button 2sec - Data transfer
setting (Wireless, Wireless HID, USB)
ZERO+DATA button 5sec - Reset
MENU STRUCTURE
MENU NAVIGATION:
DATA button - Next
MENU button - Select
ZERO button - Exit
1995
est.
BUTTONS
Advertisement
Table of Contents
Related Manuals for Microtech EUROTOOLS E-INK Series
Summary of Contents for Microtech EUROTOOLS E-INK Series
- Page 1 USER MANUAL MICROTECH 1995 est. NOTICE D'UTILISATION - ANGLAIS PIED A COULISSE INTELLIGENT CONNECTÉ Série E-INK MODIFICATIONS BUTTONS For charging connect USB cable ZERO button - Set Zero ZERO button 5sec - Off MENU button - Menu MENU button 2sec - Resolution, mm/inch...
- Page 2 MICROTECH SPECIFICATION 1995 est. Reso- Accu- Item No Range lution racy* μ mm inch mm 141093015F ±10 8 /4 • • • • • • • 141093015B 0-150 0-6” 40/16 • • • • • • • ±15 141093015C • • • • • • • •...
- Page 3 2D-S - Slave device on WIRELESS connection on HUB mode USB: Select setting of data transfer and Config data transfer Dot/Comma and Tab/Arrow Down/CR+LF DOWNLOAD APP DOWNLOAD MDS APP FOR MICROTECH DEVICES WIRELESS CONNECTION FROM www.microtech.tools, GooglePlay & App Store...
- Page 4 MICROTECH FUNCTIONS 1995 est. LIMITS mode GO/NOGO INDICATION LIMITS ON MAIN SCREEN MAX - NoGo more Upper limit MIN - NoGo less Lower limit NoGo RANGE - between Limits PEAK mode MAX/MIN DISABLE- non active mode - indicating MAX measured value...
