iVISOR DS85 Faceplate Replacement
In our continuing effort for product improvement, all DS85 consoles
have now been redesigned with a new faceplate and hardware. This new
faceplate is compatible with all DS85 systems. Please follow the
installation instructions below for faceplate replacement.
All hardware required for the replacement will be supplied in the kit.
P/N: 024-085-100-002 Obsolete;
replaced by P/N: 536336 (Direct Replacement)
Replacement Instructions
1. Confirm that you have received all items required for the replacement:
Qty (8) - Black Plastic Spacers
•
Qty (8) - Metal Threaded Standoffs
•
Qty (1) - DS85 Faceplate
•
2. On the DS85 console, remove the four Phillips screws and washers from the back of the housing. Retain
these screws and washers; they will be needed when you reassemble the console.
(Figure A)
Hirschmann Automation and Control
1540 Orchard Drive
Chambersburg, PA 17201
Document: 530117 - DS85 Faceplate Replacement
x 8
x 8
Required Tools:
Phillips Screwdriver(s)
5 mm Socket
5.5 mm Socket
x 1
Service : (717) 217-2250
Parts / Sales : (717) 217-2269
www.hirschmann-usa.com
