- Page 1 AirHarmony-4200 DC Installation Guide Internal Filters Part Number: UGD-D01196 System Release: 16.0 Revision: A Published: March 2019...
- Page 2 Airspan Networks Ltd. reserves the right, without prior notice or liability, to make changes in equipment design or specifications. Information supplied by Airspan Networks Ltd. is believed in good faith to be accurate and reliable, while every care has been taken in preparing these documents. However, Airspan Networks Ltd. does not make any representations and gives no warranties of whatever nature in respect of these documents, including without limitation, the accuracy or completeness of any information, facts and/or opinions contained therein.
-
Page 3: Table Of Contents
DECLARATION OF CONFORMITY ..................8 GPS Compliance......................10 Maximum Output TX Total Power ..............10 Power Consumption - Supply and Current ..............10 Antenna System ......................12 External Antenna ......................12 About This Document ..................13 UGD-D01196 Airspan Commercial and Internal Use... - Page 4 4.2 Pole/Wall Mount Assembly ..................27 Mounting on a Pole ......................27 Mounting on a Wooden Pole ..................... 28 Mounting on a Wall ......................30 4.3 Securing AirHarmony-4200 DC to the Mounting Plate ..........32 UGD-D01196 Airspan Commercial and Internal Use...
- Page 5 Copper Ethernet Cable Assembly ..................37 5.4 Fiber Ethernet (SFP) Cable Installation..............38 SFP Cable Connection ......................39 5.5 Connecting the DC Power Cable to AirHarmony-4200 DC ........41 Power Input – DC ....................... 41 Connecting the DC Power Cable to AirHarmony ..............42 AC/DC Power Converter –...
- Page 6 Figure 28: Optional AC/DC Converter ....................43 Tables Table 1: AirHarmony-4200 DC Internal Filter FCC Maximum Output TX Total Power ......10 Table 2: AirHarmony-4200 DC Internal Filter ETSI Maximum Output TX Total Power ....... 10 Table 3: Power Consumption ......................11 Table 4: AW3089 Omni Antenna ......................
-
Page 7: Document Information
Abstract This document details procedures for installing the Airspan’s AirHarmony-4200 DC, with internal filters, a mini-Macro class eNodeB variant and its place in the Airspan product suite. This document is intended for qualified personnel with a working knowledge of LTE. -
Page 8: Warnings And Cautions
Connect the equipment to an outlet on a circuit different from that to which the power source is connected Modifications Any changes and modifications to this device that are not expressly approved by Airspan Networks may void the user's authority to operate the equipment. General ... -
Page 9: Important Safety Instructions
Toute enfreinte a ces obligations peut annuler la garantie délivrée par Airspan pour ces produits et peut exposer l’utilisateur final ou le fournisseur de services a des dommages légaux et financiers. -
Page 10: Safety
It is the user’s responsibility to install this device in accordance with the local electrical codes. Installation of the AirHarmony-4200 DC Internal Filters must be contracted to a professional installer. The circuit breaker should be easily accessible in case you have to disconnect the device. -
Page 11: Warning Of Hazardous Voltages
Substances Hazardous to Health Regulations 1989 and the Dangerous Substances Regulations 1990). At the end of any Airspan products life cycle, the customer should consult with Airspan to ensure that the product is disposed of in conformance with the relevant regulatory requirements. -
Page 12: Adherence To European Directive 2014/53/Eu
Airspan equipment is compliant with CE and R&TTE regulations and can be operated in all EU (European Union) locations listed below:... -
Page 13: Lightning Protection
- AirHarmony-4200 DC is designed to operate in environmental conditions complying with IP66 and relevant standards. -
Page 14: Declaration Of Conformity
This equipment is in compliance with the essential requirements and other relevant provisions of Directive 2014/53/EU. Español: Por medio de este Airspan, declara que la unidad cumple con los requisitos esenciales y cualquier otra disposición aplicable o exigible de la Directiva 2014/53 / UE. Greek: ΜΕ... - Page 15 Därmed intygar Airspan att denna enhet överensstämmer med de väsentliga egenskapskraven och andra relevanta bestämmelser som anges i direktiv 2014/53 / EU. Íslenska: Airspan lýsir hér með yfir að þessi eining uppfylli grunnkröfur og aðrar kröfur tilskipunar 2014/53 / ESB. Norsk: Airspan erklærer herved at utstyrsenheten oppfyller grunnleggende krav og andre relevante krav i...
-
Page 16: Gps Compliance
Note: A GPS is recommended for synchronizing between LTE sectors. Note: An optional GPS Lightning/Surge protector is available from Airspan when installing the GPS antenna in a remote location for lightning prone deployments. Maximum Output TX Total Power Table 1: AirHarmony-4200 DC Internal Filter FCC Maximum Output TX Total Power... -
Page 17: Table 3: Power Consumption
Transient Voltage: +150V (ETR283) The use of other power sources may impair safety AC power feed is also available, using an AC/DC power converter offered by Airspan. Note: For more details on the offered AC/DC converter (sold separately), please contact your nearest Airspan sales representative. -
Page 18: Antenna System
AirHarmony-4200 DC (Internal Filters) Installation Guide Antenna System AirHarmony-4200 DC comes in a range of frequency variants that can be mounted with different antenna options and formats. A typical installation will have a cross-polar sector or dual slant antenna connected to the approprate RF port of the AirHarmony-4200 DC variant unit. Various antennas are designed specifically for AirHarmony-4200 DC deployments;... -
Page 19: About This Document
Mount Antenna (external antenna) Connect and manage cables Intended Audience This guide is intended for persons who are responsible for installing the AirHarmony-4200 DC Internal Filter unit. These persons should have a working knowledge of the equipment. AirHarmony can be tightly integrated with Airspan’s iBridge and iRelay transport solutions. -
Page 20: Document Organization
Lists the hardware, software, and client requirements for Verifying Prerequisites installation. AirHarmony-4200 DC Internal Filters Installation Describes how to install AirHarmony-4200 DC Internal Filters unit. GPS Installation Describes how to install the GPS antenna. Connect and Manage Cables Describes how to connect the cables. -
Page 21: Customer Care Help Desk
Customer Care Help Desk Airspan’s Customer Care Help Desk offers prompt and efficient customer support services. Note: To avail Airspan’s Customer Care Help Desk support, you must be a registered user and must have a valid support contract. To register, click here and fill the Registration form. -
Page 22: Introduction
AirHarmony-4200 DC (Internal Filters) Installation Guide 1 Introduction This section provides a descriptive overview of the Airspan’s AirHarmony-4200 DC Internal Filters a Macro-class eNodeB variant and its place in the Airspan product suite. This document is intended for readers with LTE working knowledge. -
Page 23: Deployment
AirHarmony-4200 DC (Internal Filters) Installation Guide 1.2 Deployment A highly flexible and scalable 4G Base Station, the AirHarmony-4200 DC Internal Filters is capable of supporting LTE profiles across multiple frequency bands. Note: AirHarmony-4200 DC Internal Filters must be properly grounded (16AWG minimum) according to NEC and other local safety code requirements. -
Page 24: Related Airharmony 4200 Dc Internal Filters Variants
AirHarmony-4200 DC (Internal Filters) Installation Guide 1.3 Related AirHarmony 4200 DC Internal Filters Variants This document is related to AirHarmony 4200 DC Internal Filters variants. The following table lists the relevant variants: Table 6: AirHarmony 4200 DC Variants Band Product DL Freq. -
Page 25: Getting Started
AirHarmony-4200 DC (Internal Filters) Installation Guide 2 Getting Started 2.1 Workflow of Installation The Workflow to install the AirHarmony-4200 DC Internal Filters is displayed in the following diagram: Figure 3: Workflow Caution: Antennas must be connected and attached before AirHarmony-4200 DC Internal Filters unit is powered on. -
Page 26: Airharmony-4200 Dc Internal Filters Installation Checklist
AirHarmony-4200 DC (Internal Filters) Installation Guide 2.2 AirHarmony-4200 DC Internal Filters Installation Checklist Plan the installation of the AirHarmony-4200 DC by using the Installation Checklist, which you can find as a removable job aid in Appendix A for this guide. -
Page 27: Verify The Parts And Kits
4 bands for pole mounting – mounting kit supports dia. Range 64 mm (2.5 in) > 362 mm (14.25 in) Optional AC / DC Power Converter – Available from Airspan AC/DC Power Converter for AC/DC Indoor AC-DC-IDU- 133-00-061... - Page 28 AirHarmony-4200 DC (Internal Filters) Installation Guide Installation Kit / Part No. Airspan Consisting of: Image Part Type-IC DC PWR-75-INST-2 Type-IC DC Power Cable Power Cable - 75m - special order Full AXS SM Fiber Cable Full AXS SM FIB-FA-5-LC-SM- 686-00-016...
-
Page 29: Panels
AirHarmony-4200 DC (Internal Filters) Installation Guide Panels The following figures display the AirHarmony-4200 DC Internal Filters bottom and top panels. The following displays the AirHarmony-4200 DC’s bottom panel. Figure 4: AirHarmony-4200 DC Internal Filters Unit, Bottom panel UGD-D01196 Airspan Commercial and Internal Use... -
Page 30: Physical Dimensions
AirHarmony-4200 DC (Internal Filters) Installation Guide The following displays the AirHarmony-4200 DC’s Internal Filters unit top panel. Figure 5: AirHarmony-4200 DC Internal Filters Unit, Top panel Physical Dimensions AirHarmony-4200 DC Internal Filters unit is in an all outdoor enclosure. Table 9: AirHarmony-4200 DC Physical Dimensions... -
Page 31: Environmental
AirHarmony-4200 DC (Internal Filters) Installation Guide Environmental AirHarmony-4200 DC Internal filters unit meets the following environmental requirements: GR-63 Storage and Transportation ETSI EN 300-019-1-4 Operational (non-weather protected equipment) ETSI EN 300-019-1-1 Storage (weather protected, non-temperature controlled locations) ... -
Page 32: Installing Airharmony-4200 Dc
Remove the protective dust cap from the GPS antenna jack prior to mounting on the AirHarmony-4200 DC. Align the GPS jack with the plug on the top panel on the AirHarmony-4200 DC. Attach the GPS antenna to the TNC connector on the unit. -
Page 33: Pole/Wall Mount Assembly
Verify that the mounting pins are facing upwards as shown below. Figure 7: Pole/Wall mounting plate (w/o bolt) Select the location on the pole to mount the AirHarmony-4200 DC. You can attach the AirHarmony-4200 DC to any pole from 1-7/8 to 16 inches (47.6 to 406.4 mm) in diameter. -
Page 34: Mounting On A Wooden Pole
AirHarmony-4200 DC (Internal Filters) Installation Guide Figure 8: Mounting plate mounted Mounting on a Wooden Pole Airspan provides an additional mounting alternative specifically for a wooden pole. The following images show the pole mount assembly on a wooden pole. Caution: Take care to install the Pole/Wall mounting plate in the correct orientation. -
Page 35: Figure 10: Mounting Plate On Pole
Select the location on the pole to mount the AirHarmony-4200 DC. You can attach the AirHarmony-4200 DC to any pole from 1-7/8 to 16 inches (47.6 to 406.4 mm) in diameter. Determine where to position the mounting plate on the pole and mark where to drill for insertion of the 3/8-16 through-bolt. -
Page 36: Mounting On A Wall
Attach the mounting plate to the wall using Lag bolts (x8 recommended). Note: Lag bolts (x8) and necessary hardware are not supplied by Airspan and are the responsibility of the installer. Recommended minimum 5/16 x 4” dia. (8mm x 100mm) with appropriate plugs according to field conditions. -
Page 37: Figure 12: Mounting Plate On Wall
AirHarmony-4200 DC (Internal Filters) Installation Guide Figure 12: Mounting Plate on Wall UGD-D01196 Airspan Commercial and Internal Use... -
Page 38: Securing Airharmony-4200 Dc To The Mounting Plate
AirHarmony-4200 DC on pole or wall. To mount AirHarmony-4200 DC to the mounting plate, perform the following: Lift up the AirHarmony-4200 DC unit and hook the slotted holes onto the mounting pins (studs) on the top of the mounting plate. -
Page 39: Figure 15: Airharmony Mounted On Concrete Pole
Once aligned insert the supplied M8x20 Hex head bolt with a split washer and a flat washer into each clinch-nut. Check and tighten all six (6) M8x20 Hex head bolts. The following displays the AirHarmony-4200 DC being mounted on a non-wooden pole. Figure 15: AirHarmony mounted on concrete Pole UGD-D01196... -
Page 40: Figure 16: Airharmony Mounted Wooden Pole
AirHarmony-4200 DC (Internal Filters) Installation Guide The following displays the AirHarmony-4200 DC mounted on a wooden pole. Figure 16: AirHarmony mounted Wooden Pole UGD-D01196 Airspan Commercial and Internal Use... -
Page 41: Figure 17: Airharmony Mounted On A Wall
AirHarmony-4200 DC (Internal Filters) Installation Guide The following displays the AirHarmony-4200 DC mounted on a wall. Figure 17: AirHarmony mounted on a Wall UGD-D01196 Airspan Commercial and Internal Use... -
Page 42: Airharmony-4200 Dc Connections
5.1 Grounding The AirHarmony-4200 DC requires a secure ground connection. The ground cable should be connected with the grounding screw fitted with a flat washer and lock washer to the bottom of the chassis clearly marked with the universal ground symbol as shown below. The grounding screw (M6 x 16) is pre-installed during assembly. -
Page 43: Weather-Proofing The Antenna Connections
The Ethernet cable is connected using a standard RJ45 connector protected by a harsh environment protective casing. The Copper Ethernet cable is connected to the AirHarmony-4200 DC using a Gland connector assembled on the bottom panel of the unit, as shown below. -
Page 44: Fiber Ethernet (Sfp) Cable Installation
Do not tighten the tail nut. Figure 20: Ethernet Cable through connector Seat the RJ45 connector plug securely into the body cavity of the AirHarmony-4200 DC Tighten the Gland body into to the threaded hole on the bottom of the AirHarmony- 4200 DC. -
Page 45: Sfp Cable Connection
AirHarmony-4200 DC (Internal Filters) Installation Guide Note: Airspan recommends using the Finisar - FTLF1318P3BTL 1000BASE-LX which has been tested and approved by Airspan. Available from Airspan if required. SFP Cable Connection Figure 21: LC duplex cable assembly Remove the protective dust cap from the connector housing assembled on the unit. -
Page 46: Figure 23: Slide On Inner Housing
AirHarmony-4200 DC (Internal Filters) Installation Guide Figure 23: Slide on inner housing Note: Check that there no space between the inner housing and mounting flange. Check and remove any debris that might interfere with the connection. Slide the outer shell over the inner housing and turn the outer bayonet shell 1/4 turn clockwise, until it clicks into place. -
Page 47: Connecting The Dc Power Cable To Airharmony-4200 Dc
Check Power Supply for proper polarization. Note: Airspan supplies two (2) types of cable, either black wire and white wire cable or black wire and blue wire cable. The cables’ specs are identical only the colors are different. Figure 25: DC Power Connection... -
Page 48: Connecting The Dc Power Cable To Airharmony
AirHarmony-4200 DC (Internal Filters) Installation Guide Figure 26: Power Connector – Bottom Panel Connecting the DC Power Cable to AirHarmony Plan the position of the DC power cable run from the AirHarmony unit to the power supply unit. The DC power cable is offered in various lengths, to fit different deployments. -
Page 49: Ac/Dc Power Converter - Optional
Airspan. The third-party external AC/DC Power Converter is an optional unit that connects to the AirHarmony-4200 DC in the event there is no -48VDC availability at the site. Note: Airspan recommends using the AC/DC Power Converter for the AirHarmony-4200 DC. -
Page 50: A Job Sheet
AirHarmony-4200 DC (Internal Filters) Installation Guide A Job Sheet This job sheet enables the users to keep track of their installation. It covers all the prerequisites required for accomplishing the AirHarmony-4200 DC installation. Table 12: Job Sheet Site Requirements Pole or wall for installation identified... -
Page 51: B Abbreviations
AirHarmony-4200 DC (Internal Filters) Installation Guide B Abbreviations Term Expansion 3GPP 3rd Generation Partnership Project, responsible for LTE Almost Blank Subframes Adjacent Channel Selectivity is a measurement of a receiver's ability to process a desired signal while rejecting a strong signal in an adjacent frequency channel. ACS is defined as the ratio of the receiver filter attenuation on the assigned channel frequency to the receiver filter attenuation on the adjacent channel frequency. - Page 52 AirHarmony-4200 DC (Internal Filters) Installation Guide Term Expansion Medium Access Controller – responsible for several functions such Error Correction, Packet (De)Multiplexing, etc… MBSFN Multicast-Broadcast Single Frequency Network is an LTE feature designed to deliver services such as Mobile TV using the LTE infrastructure, and is expected to...
