- Page 1 AirSpeed 1000 Installation Guide Part Number: DUG01289 System Release: 16.0 Revision: A Published: January 2019...
- Page 2 No responsibility is assumed by Airspan Networks Ltd. for the use of the documents nor for the rights of third parties which may be effected in any way by the use thereof. The provision of these documents (and the documents themselves) does not constitute professional advice of any kind.
-
Page 3: Table Of Contents
Maximum Output TX Power ..............8 Product Variants ....................8 Power Consumption ....................8 External Antennas ....................9 About This Document ................10 Purpose ........................ 10 Intended Audience ....................10 Document Conventions ..................10 DUG01289 Airspan Commercial and Internal Use... - Page 4 1.1 AirSpeed 1000 ....................13 2 Getting Started ..................14 2.1 Workflow of Installation ................. 14 2.2 AirSpeed 1000 Installation Checklist ............. 14 3 Verifying Prerequisites ................. 15 3.1 Verifying Site Requirements ................15 3.2 Verify Installation Requirements ..............15 3.2.1 Verify the Tools ....................
- Page 5 Figure 13: Ethernet Cable through Connector .................. 26 Figure 14: Power Cable Attached ....................27 Tables Table 1: AirSpeed 1000 ETSI Maximum Output TX Power ..............8 Table 2: AirSpeed 1000 FCC Maximum Output TX Power ..............8 Table 3: Supported Frequency Bands ....................8 Table 4: Power Consumption ......................
-
Page 6: Document Information
AirSpeed 1000 Installation Guide Document Information Abstract This document details procedures for installing the Airspan’s AirSpeed 1000 Pico-class LTE eNodeB variant. Revision History Revision Details Date Summary of Changes Rev 0.1 – 0.2 Initial document – draft(s) August 2017 ... -
Page 7: Warnings And Cautions
The AirSpeed 1000 should be installed and operated from a minimum safe distance of about 48Cm. Avertissement et Precautions d’Utilisation Exposition des personnes aux fréquences radioélectriques Les AirSpeed 1000 doivent être installée et utilisée de façon à garantir la distance minimale de sécurité de 2.5m. Radio Interference This AirSpeed 1000 generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. -
Page 8: Important Safety Instructions
AirSpeed 1000 Installation Guide nécessaire, disposant d’un agreement des autorités gouvernementales de régulation. Toute enfreinte a ces obligations peut annuler la garantie délivrée par Airspan pour ces produits et peut exposer l’utilisateur final ou le fournisseur de services a des dommages légaux et financiers. -
Page 9: Warning Of Hazardous Voltages
Substances Hazardous to Health Regulations 1989 and the Dangerous Substances Regulations 1990). At the end of any Airspan products life cycle, the customer should consult with Airspan to ensure that the product is disposed of in conformance with the relevant regulatory requirements. -
Page 10: Warning Symbols
UL Information - The electrical source must be properly grounded according with NEC and other local safety code requirements. - AirSpeed 1000 is designed to operate in environmental conditions complying with IP40 and relevant standards. DECLARATION OF CONFORMITY European Community, Switzerland, Norway, Iceland, and Liechtenstein Declaration of Conformity with Regard to the R&TTE Directive 1999/5/EC... - Page 11 AirSpeed 1000 Installation Guide Greek: ΜΕ ΤΗΝ ΠΑΡΟΥΣΑ Airspan ΔΗΛΩΝΕΙ ΟΤΙ Ο ΕΞΟΠΛΙΣΜΟΣ ΣΥΜΜΟΡΦΩΝΕΤΑΙ ΠΡΟΣ ΤΙΣ ΟΥΣΙΩΔΕΙΣ ΑΠΑΙΤΗΣΕΙΣ ΚΑΙ ΤΙΣ ΛΟΙΠΕΣ ΣΧΕΤΙΚΕΣ ΔΙΑΤΑΞΕΙΣ ΤΗΣ ΟΔΗΓΙΑΣ 1999/5/ΕΚ. Français: Cet appareil est conforme aux exigencies essentialles et aux autres dispositions pertinantes de la Directive 1999/5/EC.
-
Page 12: Maximum Output Tx Power
23.98 44.48 20.5 1000 Note: The AirSpeed 1000 requires operation using an Airspan FCC-specific version of Netspan acting as a CBRS Domain Proxy. Caution: Do not set maximum output TX total power to higher than local regulations. Product Variants AirSpeed supports the following frequency bands with the specific performance values:... -
Page 13: External Antennas
AirSpeed 1000 Installation Guide External Antennas AirSpeed 1000 connects to the external antennas via four (4) N-Type female connectors located at the top panel. The antenna should be mounted to its appropriate mounting facility. The supported antennas should be dual slant, cross polar antennas. -
Page 14: About This Document
Install the AirSpeed 1000 Connect and manage cables Intended Audience This guide is intended for persons who are responsible for installing the AirSpeed 1000 equipment. Document Conventions This document uses the following typographic conventions. Table 5: Typographic Conventions... -
Page 15: Related Reading
AirSpeed 1000 Installation Guide Related Reading The following documents contain related information: AirSpeed 1000 Product Datasheet Airspan LTE Commissioning Manual DUG01289 Airspan Commercial and Internal Use... -
Page 16: Customer Care Help Desk
Customer Care Help Desk Airspan’s Customer Care Help Desk offers prompt and efficient customer support services. To avail Airspan’s Customer Care Help Desk support, you must be a registered user and must Note: have a valid support contract. To register, click here and fill the Registration form. -
Page 17: Introduction
AirSpeed 1000 is a Pico-class LTE eNodeB product, providing high-speed data, mobility, Voice over LTE, and broadcast/multicast services. AirSpeed 1000 is a super compact, easy to install Pico-class eNodeB. Allowing an operator to deploy LTE broadband services on any Street Furniture, rooftop or building front AirSpeed 1000 is a dual sector / carrier 2x2 MIMO product. -
Page 18: Getting Started
The Workflow to install the AirSpeed 1000 is displayed in the following diagram: Figure 3: Workflow 2.2 AirSpeed 1000 Installation Checklist Plan the installation of the AirSpeed 1000 by using the Installation Checklist, which you can find as a removable job aid in Appendix B for this guide. -
Page 19: Verifying Prerequisites
Tightening cable glands - To fit 15 mm Note: Airspan does not provide screws and wall anchors for mounting the unit to the wall. The screw size depends on the structure of the building to which the unit is to be attached. When selecting screw sizes, consideration must be given to the weight of the unit and load that may be induced in windy conditions. -
Page 20: Verify The Parts And Kits
Transient Voltage: +150V (ETR283) Note: AC power feed is also available, using an AC/DC power converter offered by Airspan. For more details on the offered AC/DC converter (sold separately), please contact your nearest Airspan sales representative. DUG01289 Airspan Commercial and Internal Use... -
Page 21: Connections
AirSpeed 1000 Installation Guide 3.2.4 Connections The following diagrams display the connections on the top and bottom panels of the AirSpeed 1000. Note: The unit requires a secure ground connection and a grounding screw fitted with a flat washer and lock washer is provided on the back and clearly marked with the universal ground symbol. -
Page 22: Physical Dimensions
1 Kg. / 2.2 Lbs. (Bracket Base) 3.2.6 Environmental Note: AirSpeed 1000 is not meant to be used in a Marine environment. AirSpeed 1000 meets the following environmental requirements: IEC 60529 IEC 60068 ETSI EN 300-019-2-4 Operational (non-weather protected equipment) ... -
Page 23: Table 9. Airspeed 1000 Environment Compliance
AirSpeed 1000 Installation Guide Table 9. AirSpeed 1000 Environment Compliance Type Details Operating temperature -40°C to 55°C / -40°F to 131°F Operating humidity 5% - 100% non-condensing Storage temperature -40°C to 70° C / -40°F to 158°F Storage humidity 5% - 100% non-condensing... -
Page 24: Airspeed 1000 Installation
Wall mounting The AirSpeed 1000 Mounting Kit - includes a pole/wall mounting bracket for fastening the unit to a pole or on a wall. Prior to installation of the AirSpeed unit the mounting bracket must first be affixed in place on either the pole or a wall. -
Page 25: Pole Mounting (Larger Poles)
AirSpeed 1000 Installation Guide The following describes the pole mounting procedure: Select the location on the pole to mount the AirSpeed 1000 mounting bracket. Note: You can attach the unit to any pole from 1 inch to 8 inch (33.7 to 210 mm) in diameter. -
Page 26: Figure 7: Pole Mounting Assembly
AirSpeed 1000 Installation Guide Figure 7: Pole Mounting Assembly Figure 8: Mounted on Pole DUG01289 Airspan Commercial and Internal Use... -
Page 27: Wall Mount Assembly
4.3 Wall Mount Assembly The following describes the wall mounting procedure: 1. Select the location on the wall to mount the AirSpeed 1000 mounting bracket. 2. Assemble the 2 SEMS screws (M8 x 20) into the lower threaded holes on the mounting (base) bracket, do not tighten. -
Page 28: Led Display
AirSpeed 1000 Installation Guide 4.4 LED Display A single tri-color LED (Green/Red/Orange) appears at the bottom of the unit, providing unit status indication. DUG01289 Airspan Commercial and Internal Use... -
Page 29: Connect And Manage Cables
5.1 Grounding The AirSpeed 1000 requires a secure ground connection and a grounding screw fitted with a flat washer and lock washer is provided on the back and clearly marked with the universal ground symbol The cable should be grounded and bonded according to international or local standards. -
Page 30: Ethernet Cable Installation
Connecting the DC Power Cable Plan the position of the DC power cable run from the AirSpeed 1000 unit to the power supply. The DC power cable is offered in various lengths, to fit different deployments. Uncoil the cable and secure the connector to the connector on the bottom panel of the AirSpeed 1000 unit. -
Page 31: Figure 14: Power Cable Attached
AirSpeed 1000 Installation Guide Position the pins correctly, the connector is secured to the unit with a locking ring that is screwed into place. Use firm hand pressure only, the connector has a built in sealing ring. Caution: The internal plastic parts of the mating connector are keyed. Take care to align these by visual inspection or by gently rotating the connector body until the key way sections align and the pins go in before tightening the locking ring. -
Page 32: A Job Sheet
AirSpeed 1000 Installation Guide A Job Sheet This job sheet enables the users to keep track of their installation. It covers all the prerequisites required for accomplishing the AirSpeed 1000 installation. Site Requirements Position on Pole / Wall Access restrictions (local regulations) (when applicable) -
Page 33: B Checklist
B Checklist During installation, review and perform all the steps on this checklist (in the given order). This checklist is meant for the person who performs the AirSpeed 1000 installation. Tip: To make sure you complete all the tasks, detach or print this checklist and use it as a job aid. -
Page 34: C Abbreviations
AirSpeed 1000 Installation Guide C Abbreviations Table 10: ABBREVIATIONS & DEFINITIONS Term Expansion 3GPP 3rd Generation Partnership Project, responsible for LTE AWGN Additive White Gaussian Noise is a channel model in which the only impairment to communication is a linear addition of white noise with a constant spectral density and a Gaussian distribution of amplitude. - Page 35 AirSpeed 1000 Installation Guide Term Expansion MTBF Mean Time Between Failures Network Listening Orthogonal Frequency-Division Multiple Access (OFDMA) is a multiple access OFDMA version of OFDM digital modulation scheme, used for eNodeB transmissions to Protocol Data Unit Precision Time Protocol is used to synchronize clocks throughout a network. In this...
