- Page 1 Operating instructions Additional languages www.stahl-ex.com Linear Luminaire with LED Series EXLUX 6402/2...
-
Page 2: Table Of Contents
Contents General Information ....................3 Manufacturer .......................3 Information regarding the operating instructions ..........3 Conformity with standards and regulations ............3 Explanation of the symbols .................4 Symbols in these operating instructions .............4 Warning notes .....................4 Symbols on the device ..................5 Safety notes ......................5 Operating instructions storage ................5 Safe use ......................5 Intended Use .......................5... -
Page 3: General Information
General Information General Information Manufacturer R. Stahl Schaltgeräte GmbH R. STAHL (P) LTD., Plot No. - 5 Am Bahnhof 30 Malrosapuram Road, Sengundram Indl. Area 74638 Waldenburg Singaperumal Koil, Kancheepuram Dist., Germany Tamil Nadu – 603 204, INDIA Phone: +49 7942 943-0... -
Page 4: Explanation Of The Symbols
Explanation of the symbols Explanation of the symbols Symbols in these operating instructions Symbol Meaning Tips and recommendations on the use of the device General danger Danger due to explosive atmosphere Danger due to energised parts Warning notes Warning notes must be observed under all circumstances, in order to minimize the risk due to construction and operation. -
Page 5: En 2.3 Symbols On The Device
Safety notes Symbols on the device Symbol Meaning CE marking according to the currently applicable directive. 05594E00 According to marking, device approved for hazardous areas. 02198E00 Safety notes Operating instructions storage • Read the operating instructions carefully and store them at the mounting location of the device. -
Page 6: Function And Device Design
Function and device design Function and device design DANGER Explosion hazard due to improper use! Non-compliance results in severe or fatal injuries. • Use the device only according to the operating conditions described in these operating instructions. Function • for lighting areas, work spaces and objects •... - Page 7 Function and device design 16349E00 1 - Connection terminal - mounting plate 6 - Luminaire enclosure (internal wiring) 2 - Ballast 7 - Mounting plate 3 - Translucent cover 8 - LED PCB 4 - Cable gland 9 - Diffuser (optional / accessories) 5 - Connection terminal - luminaire (customer wiring) 243137 / 640260300020...
-
Page 8: En 5 Technical Data
Technical data Technical data Explosion Protection Global (IECEx) Gas and dust IECEx IBE 14.0080X EX nA d op is IIC T4 Gc EX tb IIIC T100 °C Db EX tc IIIC T100 °C Dc Europe (ATEX) Dust IBExU14ATEX1292 E II 2 D Ex tb IIIC T100 °C Db Gas and dust IBExU14ATEXB020 X E II 3 G Ex nA d op is IIC T4 Gc... - Page 9 Technical data Technical Data Luminous characteristics Luminous flux Power consumption [W] Colour rendering [Ra] ) 80 ) 80 ) 70 ) 70 Colour temperature [K] 5000 5000 5700 5700 without diffuser Luminous flux [lm] 2919 5375 3150 5800 Luminaire efficiency [lm/W] Light output ratio [%] with diffuser Luminous flux [lm]...
- Page 10 Technical data Technical Data Mechanical data Material Enclosure Material Polyester resin, glass fibre-reinforced Colour colour grey, similar to RAL 7035 Seal Silicone foam gasket in the lamp cover Translucent cover Polycarbonate Luminaire locking Central locking which can be opened/closed using a socket key M8 / wrench size 13, hinged lamp cover Mounting / Installation Cable glands...
-
Page 11: Transport And Storage
Transport and storage Technical Data Assembly Standard luminaire Standard: 2 x M8 insert nuts in the enclosure Special: Mounting grooves in the enclosure for the use of fastening and ceiling rails for variable luminaire mounting (variable mounting distances for luminaires L = 700 mm: 320 ... 480 mm; L = 1310 mm: 670 ... -
Page 12: Mounting And Installation
Mounting and installation Mounting and installation DANGER Explosion hazard due to incorrect installation of the device! Non-compliance results in severe or fatal injuries. • Carry out installation strictly according to the instructions and national safety and accident prevention regulations to maintain the explosion protection. -
Page 13: En 7.2 Mounting / Dismounting, Operating Position
Mounting and installation Mounting / dismounting, operating position DANGER Explosion hazard due to electrostatic discharge Non-complicance results in severe or fatal injuries. Do not use the luminaire in strong charge generating environments! The following processes/activities should be avoided: • accidental friction •... - Page 14 Mounting and installation Version L2 mm [inches] 28 W 400 [15.75] 52 W 800 [31.50] max. screw-in depth 10 mm [0.39] 15446E00 Suspension at moveable assembly parts 15447E00 15442E00 Mounting bracket Top rail Version L4 mm [inches] L mm [inches] 28 W 320 [12.60] 80 [3.15]...
- Page 15 In case of point suspension using pipe clamps, R. STAHL Schaltgeräte GmbH does not guarantee the strength and tightness of the luminaire! For pipe clamp mounting, use the solution of R. STAHL Schaltgeräte GmbH with integrated mounting rail providing reliable and stable four-point fixing! Wall bracket mounting...
-
Page 16: En 7.3 Installation
The result is leakage of the luminaire and difficulties in replacing the translucent cover. For pipe clamp mounting, use the solution of R. STAHL Schaltgeräte GmbH with integrated mounting rail providing reliable and stable four-point fixing! In case of point suspension using pipe clamps, R. STAHL Schaltgeräte... - Page 17 Mounting and installation Note: • Version without switch: Disconnect the luminaire from the power supply and secure it against being switched on again. • Version with switch: The luminaire is positively disconnected from the power supply by actuating the central lock. •...
- Page 18 The standard luminaire is delivered with 3 lead-in holes, 2 cable glands and 2 stopping plug. Please observe the tightening torque for luminaires with installed cable glands and stopping plugs from R. STAHL Schaltgeräte GmbH. Tightening torque Connection thread Pressure screw Cable gland 8161 M20 x 1.5...
-
Page 19: Commissioning
Commissioning M25 x 1.5 1.5 Nm Luminaires with approved cable glands and stopping plugs; not supplied by R. STAHL Schaltgeräte GmbH WARNING Cable glands and stopping plugs which are not approved. Explosion protection is impaired! • Only use separately certified cable glands and stopping plugs. -
Page 20: Maintenance And Repair
Maintenance and repair Maintenance and repair WARNING Risk of electric shock or malfunctioning of the device due to unauthorized work! Non-compliance can result in severe injuries and material damage. • Work performed on the device must only be carried out by appropriately authorized and qualified electricians. -
Page 21: Repair
Malfunction or damage to the device due to the use of non-original components. Non-compliance can result in material damage. • Use only original accessories and spare parts from R. STAHL Schaltgeräte GmbH. For accessories and spare parts, see data sheet on our homepage www.stahl-ex.com.
