Emergency Luminaire for
Fluorescent Lamps
Series EXLUX 6009
Operating instructions
Additional languages www.stahl-ex.com
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EXLUX 6009 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Stahl EXLUX 6009 Series

  • Page 1 Operating instructions Additional languages www.stahl-ex.com Emergency Luminaire for Fluorescent Lamps Series EXLUX 6009...
  • Page 2: Table Of Contents

    Contents General Information ....................3 Manufacturer .......................3 Information regarding the operating instructions ..........3 Conformity with standards and regulations ............3 Explanation of the symbols .................3 Symbols in these operating instructions .............3 Warning notes .....................4 Symbols on the device ..................4 Safety notes ......................4 Operating instructions storage ................4 Safe use ......................5 Intended Use .......................5...
  • Page 3: General Information

    They are legally binding in all legal affairs. Conformity with standards and regulations See certificates and EC Declaration of Conformity: www.stahl-ex.com. The device has IECEx approval. See IECEx homepage: http://iecex.iec.ch/ Further national certificates can be downloaded via the following link: http://www.r-stahl.com/downloads/certificates.html.
  • Page 4: En 2.2 Warning Notes

    Safety notes Warning notes Warning notes must be observed under all circumstances, in order to minimize the risk due to construction and operation. The warning notes have the following structure: • Signalling word: DANGER, WARNING, CAUTION, NOTICE • Type and source of danger/damage •...
  • Page 5: Safe Use

    Function and device design Safe use • Read and observe the safety notes in these operating instructions! • Observe characteristic values and rated operating conditions on the rating and data plates! • Observe additional information plates on the device! • Use the device in accordance with its intended and approved purpose only! •...
  • Page 6: En 4.2 Device Design

    Technical data Device design 16385E00 1 - Lamp holder 6 - Luminaire enclosure 2 - Ballast 7 - Reflector plate 3 - Luminaire trough 8 - Battery 4 - Cable gland 9 - Battery enclosure 5 - Connection terminal Technical data Explosion Protection Global (IECEx) Gas and dust...
  • Page 7 Technical data Technical Data Electrical data Rated voltage Standard: • 220 ... 240 V ± 10%, 50 / 60 Hz (Lamps acc. IEC60081) Optional: • 110 ... 127 V ± 10%, 50 / 60 Hz (Lamps acc. IEC60081) • 120V ± 10%, 50 / 60 Hz (Lamps acc. ANSI IEC C78.81) Rated insulation 320 V voltage...
  • Page 8: En En

    Technical data Technical Data Mounting / Installation Cable glands Standard luminaire Plastic: 2 x M25 x 1.5 cable entries 8161 and 2 x M25 x 1.5 stopping plugs 8290 (enclosed) Metal: 2 x metal plates M20 x 1.5 connected by means of PE for metal cable entries Attention: cable entries must be ordered separately Special:...
  • Page 9: Engineering

    Engineering Technical Data Switchover voltage from mains to battery operation for U < 0.74 x U from battery to mains operation for U > 0.80 x U Battery set Version Gas-tight NiCd battery Operating voltage Capacity 7 Ah Replacing the battery When opening the battery enclosure, the connection between the battery set and the emergency light electronics is disconnected.
  • Page 10: Emergency Light Blocking

    Engineering 6.1.3 Normal lighting operation • The light fitting is operated by normal lighting L´ PE N 16399E00 Emergency light blocking A remote switch for emergency light blocking can be connected to terminals 9 and 10 of the emergency light electronics. LED green LED grün LED red...
  • Page 11: En 7 Transport And Storage

    Transport and storage Linear connection 6043/7.. 6043/7.. 6043/7.. 6043/7.. Remote switch 16401E00 NOTICE The following conductor specifications must be observed during connection. Point-to-point connection Linear connection maximum conductor length 500 m 100 m 50 m 500 m maximum number of light fittings minimum cable 1.5 mm...
  • Page 12: Mounting And Installation

    Mounting and installation Recommendation: • Store battery at an ambient temperature of + 5 °C to + 25 °C and a relative humidity of 65 ± 5 %. The storage period is reduced of up to one month if stored outside this temperature range..
  • Page 13: Mounting / Dismounting, Operating Position

    Wall mounting must be performed with the central lock directed downwards. Outdoors, the mounting position with light emission upwards is not allowed. For outdoor use, we recommend to install a 8162/1 breather from R. STAHL Schaltgeräte GmbH. The breather guarantees compliance with degree of protection IP64 in all mounting positions.
  • Page 14: En En

    Mounting and installation Suspension at movable mounting parts 16325E00 16326E00 Mounting bracket Top rail Version L4 [mm] L [mm] 17/18 W 320 32/36 W 670 Lateral mounting pockets for variable points of suspension. When mounting the luminaire using top rails, ensure that the mounting surface is flat.
  • Page 15 L [mm] 17/18 W 320 32/36 W 670 For pipe clamp mounting, use the solution of R. STAHL Schaltgeräte GmbH with integrated mounting rail providing reliable and stable four-point fixing! In case of point suspension using pipe clamps, R. STAHL Schaltgeräte GmbH does not guarantee the strength and...
  • Page 16: Installation

    / 26,38 ... 36,61 " 32 16334E00 R. STAHL Schaltgeräte GmbH - rail profile for continuous row mounting of linear fluorescent luminaires EXLUX It facilitates row mounting and installation of the luminaires. The rail profile can also be used as cable duct.
  • Page 17 Mounting and installation • Remove the closing cap of the central lock. • Turn the central lock using a socket wrench M8, wrench size 13, by 90° to the left as far as it will go. • Swivel down the translucent cover. •...
  • Page 18 Mounting and installation Opening • Loosen the screws (1) (cross head H2). • Open the battery cover (2). Closing • Close the battery cover (2). • Tighten the screws (1) (cross head H2) firmly (2 Nm). 8.3.2 Electrical connections Electrical connection Observe the maximum clamping possibility of the connecting terminals (see chapter "Technical data").
  • Page 19 Mounting and installation Connection terminals Standard:Spring clamp Optional: terminals up to 4 mm Screw-type terminals up to 4 mm finely and extra finely stranded, and 6 mm solid Stripping length: Stripping length: 10 ... 11 mm 10 ... 11 mm L‘...
  • Page 20 The standard luminaire is delivered with 3 lead-in holes, 2 cable glands and 2 stopping plug. Please observe the tightening torque for luminaires with installed cable glands and stopping plugs from R. STAHL Schaltgeräte GmbH. Tightening torque Connection thread Pressure screw Cable gland 8161 M20 x 1.5...
  • Page 21: Commissioning

    Commissioning Please note: • the required dust resistance! • the required type of protection! • the required temperature resistance! • the IP degree of protection according to the rating plate! • the operating instructions of the cable glands and stopping plugs! •...
  • Page 22: Operation

    Operation Operation 10.1 Operation 10.1.1 Operating Modes Power supply operation Stand-by operation The lamps are switched off regardless of normal lighting. Continuous operation The lamps are switched on regardless of normal lighting. Normal lighting operation The lamps are operated by normal lighting. Emergency light operation: In the event of a power failure, the light fitting switches to emergency light operation.
  • Page 23 Operation LED green LED grün LED red LED rot mit Brücke ohne Brücke 1,5 h with jumper without jumper Fernschalter Remote switch Fernschalter BAT- Remote switch BAT+ 16400E00 Remote switch is closed Remote switch is opened Power supply Switching on the lamps depend- Switching on the lamps operation ing on operation mode...
  • Page 24: Indications

    Operation 10.2 Indications When connecting to the power supply Initialisation within 30 seconds Second Description 0 - 10 Function test green LED 10 - 20 Function test red LED 20 - 30 continuous operation test green LED blinks - continuous operation state test active red LED blinks - continuous operation...
  • Page 25: Troubleshooting

    • The error is reset. Further error indications will be reset directly after troubleshooting. If the error cannot be eliminated using the mentioned procedures: • Contact R. STAHL Schaltgeräte GmbH. For fast processing, have the following information ready: • Type and serial number •...
  • Page 26: Maintenance And Repair

    Maintenance and repair Maintenance and repair WARNING Risk of electric shock or malfunctioning of the device due to unauthorized work! Non-compliance can result in severe injuries and material damage. • Work performed on the device must only be carried out by appropriately authorized and qualified electricians.
  • Page 27 Maintenance and repair 11.1.1 Replacement of lamps Only use fluorescent lamps with pins made of brass. • Insert both lamp bases of the lamp into the holder slots as far as possible. • Put the lamp into operating position by turning it to the right or to the left.
  • Page 28 Maintenance and repair 11.1.3 Battery replacement WARNING Danger due to sparking! Explosion protection is impaired! • Carry the battery cover with built-in battery secured on the wrist. • Put the strap of the battery case around the wrist. 16387E00 • Loosen the screws (1) (cross head H2) of the battery cover. •...
  • Page 29: Cleaning

    11.3 Returning the device Use the "Service form" to return the device when repair/service is required. On the internet site "www.stahl-ex.com" under "Downloads > Customer service": • Download the service form and fill it out. • Send the device along with the service form in the original packaging to R.
  • Page 30: Disposal

    Accessories and Spare parts NOTE Malfunction or damage to the device due to the use of non-original components. Non-compliance can result in material damage. • Use only original accessories and spare parts from R. STAHL Schaltgeräte GmbH. Figure Description Art. no.
