Skywalk BREEZE Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

BREEZE
Modular Harness-LTF91/09 | EN 1651/1999
32 Description
Introduction 33

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BREEZE and is the answer not in the manual?

Questions and answers

Related Manuals for Skywalk BREEZE

Summary of Contents for Skywalk BREEZE

  • Page 1 BREEZE Modular Harness-LTF91/09 | EN 1651/1999 32 Description Introduction 33...

  • Page 2: Table Of Contents

    Maintenance, Care Welcome to skywalk! Repairs Congratulations on the purchase of your new BREEZE and thank you for your trust in us and in our products. In this manual you will find information that will help you quickly get to Disposal know your new harness to ensure your fun for a long time.

  • Page 3: Description

    In this way, the geometry allows an intuitive transmission of control pulses and weight shifting. Security was at the top of our to-do list for the BREEZE. With the BREEZE, we are integrating the PERMAIR technology developed for the Red Bull X-Alps for the first time in a recreational harness.

  • Page 4: Features

    3 FEATURES 1 - Recco The RECCO® Reflector offers emergency personnel an additional chance to locate a missing person (for example, in heavily forested areas). 2 - Provision for a hydration system Includes a pocket in the back area for attaching a drinking bladder, a drinking tube outlet from the back compartment and an elastic loop to attach the mouthpiece.
  • Page 5 12 - In-flight adjustments a) Back adjustment: To adjust pilot position and angle in flight. b) Lumbar support: For optimal ergonomic support in the lower lumbar region. c) Shoulder strap: To adjust to the upper body length. d) Chest strap: For adjusting the roll stability. 13 - Get Up locking system With Austri Alpin frame buckles for a solid, secure connection.

  • Page 6: Safety Notice

    With the chest strap adjustment, the flight dynamics of the harness can be adjusted. Neither skywalk nor the seller nor the importer of this product can be made liable in case of The tighter the chest strap, the more stable the harness becomes. However, yaw personal injury or damage caused to a third party.
  • Page 7 6 INSTALLING THE RESERVE CHUTE 4. Now you can connect the V-lines of the BREEZE with the lanyard of your reserve chute. To connect the reserve chute to the V-line, you must use a screw shackle The BREEZE can be combined with most compact reserve chutes. The reserve chute with at least 2400 daN strength.
  • Page 8 INSTALLING THE RESERVE CHUTE 1. Place the reserve chute in the BREEZE reserve compartment lines first and the V-lines untwisted next to it. Guide the V-lines up the side channel. (pic 1) 2. Guide the two zipper pullers counter to the actual functional direction to the opening...

  • Page 9: Harness Adjustments

    The deployment force must not be below 2 daN and must not exceed 7 daN. In case of of the paraglider touch each other. uncertainties you should consult a specialist or contact your competent skywalk dealer. 4. To adjust the length, open the knot on the brummel hooks.
  • Page 10 CAUTION THE PROTECTOR IS NO SEAT CUSHION! SITTING ON THE HARNESS MAY DAMAGE THE PROTECTOR OR SHORTEN ITS LIFE. IF YOU SUSPECT DAMAGE, TEST FOR LEAKS. WHEN IN DOUBT, CONTACT YOUR SKYWALK DEALER OR US DIRECTLY. Inflation 1. Place the harness flat on its side and make sure that no heavy objects, such as cockpit or reserve shut, are lying on the protector, making it difficult to inflate.
  • Page 11 After each hard landing and any fall from a height of more than 0.5 m, a leak test (page 58) must be performed on the protector. To remove the protector from the BREEZE, follow these steps: 1. Separate the cover as described on page 50.

  • Page 12: Flying Safe

    DO NOT LAUNCH IF YOU FIND ANY DEFECTS, EVEN SMALL ONES! IF YOU demand fast reactions. FIND ANY SIGNS OF DAMAGE OR ABNORMAL WEAR AND TEAR, CONTACT YOUR FLIGHT SCHOOL OR SKYWALK DIRECTLY. CAUTION BEHAVIOR IN THE EVENT OF A RESERVE CHUTE DEPLOYMENT NEVER FLY ON BAR IN TURBULENT AIR.

  • Page 13: Miscellaneous

    > To clean it, just use a brush or a damp cloth. Use mild soap to clean it only when We do not recommend using the BREEZE for flying over water or for safety training absolutely necessary. If you do, first remove other parts like the reserve parachute.

  • Page 14: Repairs

    3. Store the protector at a constant temperature for 12 hours in a shady room. The BREEZE is certified to LTF 91/09 as well as EN 1651/1999. The BREEZE is defined as 4. After the time has elapsed, check the air pressure in the protector.

  • Page 15: Maintenance Check

    Suspension points height(cm) your glider from the very beginning. The BREEZE will provide you with plenty of joy over Harness weight (g)

  • Page 16: Test Protocol

    Date: TEST PROTOCOL Denseness test: Customer, Name: Result: [+/–]: defects: suggestion: Adress: Tel. Nr: inflate the protector, check level after 12h Product type: Size: Serialnumber: certification number.: last service: Rescuesystem: Manufacturing date:: Result: [+/–]: defects: suggestions: Rescue handle: (check cotter pins & Loops) V-Line: Checklist: Result [+/–]:...
  • Page 17 SAMABZ100 user manual for BREEZE harness Skywalk GmbH & Co. KG Windeckstr. 4 | 83250 Marquartstein +49 (0) 8641/69 48 40 info@skywalk.info | www.skywalk.info...
