Additionally, the system allows the connection of up to two outdoor
units and up to three indoor units in total. It exists the possibility to
mount different topologies according to the phyisical distribution of
the building requirements.
PFA 2415
100-240 Vac
2
2
PE 1 / PE 2
2
MON 70 / MON 43
2
MON 70 / MON 43
2
PE 1 / PE 2
2
Electronic lock
2
PE 1 / PE 2
2
MON 70 / MON 43
2
2
Electronic
lock
MON 70 / MON 43
MON 70 / MON 43
2
Electronic
lock
