RedBack Lasers DGL1010VS Instruction Manual

Electronic digital dual grade
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DGL1010VS and is the answer not in the manual?

Questions and answers

Related Manuals for RedBack Lasers DGL1010VS

Summary of Contents for RedBack Lasers DGL1010VS

  • Page 2 CONTENTS User Safety Introduction and DGL1010VS Accessories DGL1010VS Diagram Operating Instructions Batteries Power and Tilt Mode Grade Setting Vertical Rotation Mode Laser Receiver LR715/LR720 Calibration Self Check & Technical Specifications Warranty User Safety • Laser output sign lies near the output aperture.
  • Page 3 LCD display duplicating the display on the laser level itself. This make setting grades and the DGL1010VS other features a snap. The DGL1010VS can also be used on its side for vertical alignment and site square layout and has scan modes essential for indoor visible use.
  • Page 4 DGL1010VS DIAGRAMS DGL1010VS Laser Unit 1. Alignment Scope 2. Scope Mount 3. Rotating Head 4. Heavy Rubberised Casing 5. Keypad 6. LCD Display Keypad Power On/Off (laser level) Rotation & Speed Setting Grade Axis Tilt On/Off Vibration, Wind Setting Setting Grade % Remote Channel Select Re-Level &...

  • Page 5: Smart Remote Control

    Smart Remote Control Ruberised Casing LCD Display Tilt On/Off Setting Grade Axis Vibration, Wind Setting Remote Channel Select Setting Grade % Re-Level & Backlight Manual Mode Rotation & Speed Power On/Off (remote) Scan Modes & Adjustment Receiver - LR715 Receiver - LR720 Bubble Vial Rubber Casing (top and side)

  • Page 6: Battery Instructions

    DGL1010VS OPERATING INSTRUCTIONS Battery Instructions The DGL1010VS has two battery options either 3 x standard “D” size Alkaline or the Li-ion rechargeable pack. For standard 3 x “D” alkaline operation simply insert into the standard battery caddy in the direction indicated, insert caddy into recess and tighten the locking screw.

  • Page 7: Tilt Mode

    Note that the power button on the remote only operates the remote and not the laser. The DGL1010VS has a massive self levelling range, in other words the body of the laser can be set up on the tripod along way out of level and the electronic mechanism will self level the rotating head to be level.
  • Page 8 In Slope (Grade) mode the “TILT” and “V-W-S” features can still be used. The DGL1010VS is dual grade, so a grade can be set on the X and Y axis simultaneously. Slope (Grade) can be set from either the laser’s keypad or the remote and the grade being selected is shown on both LCD displays.
  • Page 9 NOTE: In grade mode if nothing is entered for 8 seconds, whatever has already been entered will be set and the laser will grade and rotate. If you have not entered all the numbers then re-enter grade mode by pressing the X/Y button and finish entering all the digits you require.
  • Page 10 Rotation Speed Button. LCD Display Light The DGL1010VS has a backlight feature for the LCD display which is turned on and off with the Level/Light button a long press will toggle between on and off.
  • Page 11 90 degree square for site layout. The DGL1010VS can be placed on its side either directly on a tripod or on its included side plate with the datum marker and roughly levelled using the adjustment feet and bubble vial, this brings the laser into self levelling range where the electronics take over.

  • Page 12: Remote Control Operation

    The receiver has multiple channels the default being channel #1 the channel number is displayed on both the LCD on the DGL1010VS and the remote bottom left corner. If you have a second DGL1010VS on site the channel...

  • Page 13: Receiver Instructions

    RECEIVER INSTRUCTIONS The DGL1010VS sold as a standard package includes the RedBack LR715 receiver. The DGL1010VSR720P special package includes the LR720 receiver. Laser Receiver LR715 standard issue (refer to diagram page 5) The LR715 is a heavy duty dual sided display rotating laser receiver, it can be either hand held or with the staff bracket clamped onto a staff.
  • Page 14 Laser Receiver LR720 special R720 package (refer to diagram page 5) Unit of Measure Sound Options, Measurement Above Back Light Custom Zero Set or Below Level Accuracy Options (1,5 or 9mm) Custom Zero Indicator Accuracy Indicator Change Units Measured Power Button (mm, inch) Sound Indicator Battery Level Light Indicator LR720 is supplied with the DGL1010SVR720 special package and differs from the...
  • Page 15 Remove batteries when not used for an extended period of time to prevent leakage. • The DGL1010VS is a precision instrument and should not be subjected to excessive knocks, drops or vibrations. • Self check calibration from time to time.
  • Page 16 “Workmanship” refers to handling, assembly and manufacturing processes done by or for CMI Industries Pty Ltd in order to manufacture the products. “Warranty Period” For the DGL1010VS is Five Years. Warranty period is from original purchase date, no extension is made in the event of warranty replacement products supplied or time spent being repaired.
