Page 2: Operating Instructions
CONTENTS User Safety Introduction and ARL509™ Accessories ARL509™Diagram Operating Instructions Batteries Power and Rotation Speed Laser Receiver LR715 Calibration Self Check & Technical Specifications Care & Maintenance, Trouble Shooting Warranty User Safety • Laser output sign lies near the output aperture. - Page 3 Then using the supplied LR715 receiver you can set up your levels. The ARL509™ is manual levelling when set up on its side mount for vertical alignment.
- Page 4 ARL509 DIAGRAMS ARL509 Laser Unit 1. Rubberised Casing 2. Laser Output Window 3. Side/Wall Mounting Plate 4. Battery Compartment 5. Levelling Knob Side Mounted 6. Charging Socket/LED 7. Pendulum Locking Knob 8. Keypad www.redbacklasers.com.au...
- Page 5 Keypad Rotation Speed Power On/Off Power LED Low, Medium & High Speed LED’s Manual Bubble Vial for Side Mounted Vertical Operation Receiver - LR715 Magnetic Mounting Rubber Casing LCD Display Reception Sensors (Repeated on rear) Fine/Coarse Mode Bubble Vial Speaker Control Display back light Power On/Off www.redbacklasers.com.au...
- Page 6 OPERATING INSTRUCTIONS Battery Instructions The ARL509 has two battery options either 4 x standard “AA” size Alkaline or the Ni-Mh rechargeable packs. For standard 4 x “AA” alkaline operation simply insert into standard battery holder in the direction indicated and tighten the locking screw.
- Page 7 Turning Laser On (Horizontal Operation) Before the ARL509 can be powered up for normal horizontal rotation the pendulum locking knob first needs to be rotated to the “ON” position, this disengages the protective pendulum lock. Now when the power button is pressed the laser will be powered up and the head...
- Page 8 • Once the dot is on the target use the receiver to pick up the rotating line on the second line of the 90 degree. Your square is now set. Using the ARL509 with the built in Wall Mount ARL509...
- Page 9 LR715 RECEIVER INSTRUCTIONS Laser Receiver LR715 (refer to diagram page 5) The LR715 is a heavy duty dual sided display rotating laser receiver, it can be either hand held or with the staff bracket clamped onto a staff. The bubble vials can be used to keep the receiver level.
-
Page 10: Technical Specifications
We at Redback Lasers provide a once off free calibration and check within the duration of the warranty period see page 16 for details. - Page 11 • Self check calibration from time to time. See page 9 • For service contact Redback Lasers. www.redbacklasers.com.au Trouble Shooting - FAQ I hear a continuous beeping in side (Vertical rotation) mode! Check the pendulum lock is in the “OFF” Locked position when used in vertical rotation mode on its side mount.
- Page 12 “Workmanship” refers to handling, assembly and manufacturing processes done by or for CMI Industries Pty Ltd in order to manufacture the products. “Warranty Period” For the ARL509 Two Years. Warranty period is from original purchase date, no extension is made in the event of warranty replacement products supplied or time spent being repaired.
