PREPARING THE BREAKER

Important: Make sure that the mains voltage matches
the voltage stated on the machines rating plate.
Note: Remove the plug from the socket before carrying
out adjustment, servicing or maintenance.
8.1 AUXILIARY HANDLE – FIGS. 1 – 4
Warning: Use auxiliary handle supplied with the tool.
Loss of control can cause personal injury.
To assemble auxiliary handle:
– Fit 'U' bracket
– Place bolt
the locking spacer through 1st slot of 'U' bracket,
then back into 2nd slot of bracket.
– Place bracket
holding bolt head.
– Screw on auxiliary handle
– To reposition handle for side holding, simply loosen
auxiliary handle, rotate to desired position and
retighten.
10
over front housing.
through locking spacer
over bolt and with forefinger
until tight.
FIG.1
and slide
FIG.2
FIG.3
FIG.4
