- Page 1 Model AXIAL FANS VENTS MA Reverse user's manual VENTS MAO1 Reverse www.ventilation-system.com...
- Page 2 Follow the user's manual requirements to ensure durable and trouble-free operation of the fan. WARNING Disconnect the fan from power supply prior to any connection, servicing and repair operations. Mounting and maintenance are allowed for duly qualified electricians with valid electrical work permit for electric operations at the units with operating voltage up to 1000 V after careful study of the present user's manual.
- Page 3 Follow the user's manual requirements to ensure durable and trouble-free operation of the fan. WARNING While mounting the fan avoid the casing compression! Deformation of the casing may result in the motor jam and excessive noise. Misuse of the unit or any unauthorized modifications are not allowed. Take steps to prevent ingress of smoke, carbon monoxide and other combustion products into the room through open chimney flues or other fire-protection devices.
- Page 4 Do not use the fan in a hazardous or explosive environment containing spirits, gasoline, insecticides, etc. Do not close or block the fan intake or extract vents in order to ensure the efficient air stream. Do not sit on the unit and do not put any objects on it.
- Page 5 Follow the user's manual requirements to ensure durable and trouble-free operation of the fan. WARNING The product is allowed to be used by children aged from 8 years and above and persons with reduced physical, mental or sensory capacities, or lacking the appropriate training provided that they have been given supervision or instruction regarding a safe use of the product and understand the risks involved.
- Page 6 2. Control unit – 1 piece; 3. 5-wire cable – 4 m; 4. Self-tapping screws with expansion pegs – 12 pieces each (MA Reverse) or 8 pieces (MAO1 Reverse); 5. Metric bolts and nuts, plastic nuts – 4 pieces each (MAO1 Reverse only);...
- Page 7 ATTENTION! All the electrical connections to the control unit and the fan must be made using bolted connectors (terminal blocks). Each terminal block receptacle has a numeric marking with a corresponding marking on the circuit board for quick and convenient connection. The colour markings of the wires correspond to the cable supplied with the unit.
- Page 8 FAN CONTROL The fan control unit enables four operating modes (Fig. 24): 1. Ventilation (extraction/supply)* at Speed 1. 2. Ventilation (extraction/supply)* at Speed 2. 3. Double action at Speed 1. The fan reverses the air flow direction every 70 seconds. 4.
- Page 9 The defects are eliminated by means of replacement or repair of the complete fan or a faulty part thereof. The warranty repair does not include: routine technical maintenance fan installation / dismantling fan setup To benefit from warranty repair the user must provide the fan, the user's manual with the purchase date stamp and the payment document certifying the purchase.
- Page 10 MA Reverse 0.5°...1° MAO1 Reverse...
- Page 12 180 mm...
- Page 13 2 radii Exhaust/supply* mode Second speed Activation Deactivation First speed Reverse operation...
- Page 14 Control unit JMP1 Flow out Flow in (exhaust) (supply) 40 39 38 37 Marking "11...15" on the ~ 230 V controller socket connector JMP1 Marking "11...15" on the White controller socket connector White Speed1 Speed2 ~ 230 V Speed0 Timer Grey Brown Grey...
-
Page 16: Acceptance Certificate
Member States relating to electromagnetic compatibility. This certificate is issued following test carried out on samples of the product referred to above. Seller (name and stamp of the seller) 150 MA Reverse 150 MAO1 Reverse Date of Sale V01-(MA_MAO1_REVERSE)_EN-04 www.ventilation-system.com...
