- Page 1 ƒ VKO ƒ VKO1 ƒ M ƒ MA ƒ M1 ƒ M3 ƒ MAO1 ƒ MAO2 ƒ M1OK2 ƒ R ƒ R1 ƒ K ƒ K1 ƒ PF ƒ PF1 ƒ F ƒ F1 ƒ D ƒ D1 ƒ LD ƒ...
- Page 2 CONTENTS Delivery set ................................................8 Brief description ..............................................9 Operation guidelines ............................................9 Product sales ................................................. 9 Designation key ..............................................10 Mounting and set-up ............................................11 Electronics operation algorithm ......................................22 Troubleshooting ..............................................26 Storage and transportation regulations ....................................26 Manufacturer’s warranty ..........................................
- Page 3 The manual contains information about purpose, technical details, operating principle, design, and installation of the Vents VKO, VKO1, M, MA, M1, M3, MAO1, MAO2, M1OK2, R, R1, K, K1, PF, PF1, F, F1, D, D1, LD, LD1, S, S1, X, X1, Xstar, Silenta-M, Silenta-S unit and all its modifications.
- Page 4 This unit is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the unit by a person responsible for their safety. Children should be supervised to ensure that they do not play with the unit.
- Page 5 Connection to the mains must be made through a disconnecting device, which is integrated into the fixed wiring system in accordance with the wiring rules for design of electrical units, and has a contact separation in all poles that allows for full disconnection under overvoltage category III conditions.
- Page 6 All operations described in this manual must be performed by qualified personnel only, properly trained and qualified to install, make electrical connections and maintain ventilation units. Do not attempt to install the product, connect it to the mains, or perform maintenance yourself. This is unsafe and impossible without special knowledge.
- Page 7 Do not use the unit in a hazardous or explosive environment containing spirits, gasoline, insecticides, etc. Do not close or block the intake or extract vents in order to ensure the efficient air flow. Do not sit on the unit and do not put objects on it.
- Page 8 BEFORE INSTALLING ADDITIONAL EXTERNAL DEVICES, READ THE RELEVANT USER MANUALS. DELIVERY SET – 1 pc. Screws and dowels – 4 pcs. (except for VKO/VKO1/MAO1/MAO2/M1OK2 models) Screw, bolt, nut, plastic nut – 4 pcs. of each (for MAO1/MAO2/M1OK2 models) Sealant – 2 pcs. (for MAO1/MAO2/M1OK2 models) Connecting screws –...
- Page 9 The product is an axial fan for exhaust ventilation of small and medium-sized premises. The fans of the VKO/VKO1 series can be used for both supply and exhaust ventilation and are installed in the ventilation duct. The fan (except for the VKO/VKO1/MAO/M1OK series) is designed for wall or ceiling mounting.
- Page 10 N – polished stainless steel (for the LD series) Fan series VKO, VKO1, M, MA, M1, M3, MAO1, MAO2, M1OK2, R, R1, K, K1, PF, PF1, F, F1, D, D1, LD, LD1, S, S1, X, X1, Xstar, Silenta-M, Silenta-S Outlet spigot diameter [mm]...
- Page 11 MOUNTING AND SET-UP The designation of the fan, schematic representation of its appearance, overall and mounting dimensions, as well as design features are given below. VKO, VKO1 Model А 100 VKO/VKO1 91/113 125 VKO/VKO1 93/118 150 VKO/VKO1 108/128 The VKOk and VKO1k models are equipped with a mounting bracket for mounting on a flat surface.
- Page 12 MAO1, MAO2, M1OK2 Model А 125 MAO1 – – 125 MAO2 – 150 MAO1 – – 150 M1OK2 – M3, F, F1 Model А 100 M3 125 M3 150 M3 100 F/F1 104/128 125 F/F1 110/134...
- Page 13 K, K1, D, D1, M, MA, M1, LD, LD1, S, S1, PF, PF1, X, X1, Xstar, R, R1, Silenta-M, Silenta-S Model А 100 K/K1 105/109 15/19 125 K/K1 112/116 15/19 150 K 100 D/D1 108/93 12,5 120 D 125 D/D1 114/96 12,5 150 D...
- Page 14 100 X 125 X 150 X 100 X1 11,5 120 X1 12,5 125 X1 12,5 150 X1 100 Xstar 125 Xstar 150 Xstar 100 R 100 R1 100 Silenta-M 88,5 125 Silenta-M 150 Silenta-M 25,5 100 Silenta-S 120 Silenta-S 125 Silenta-S 150 Silenta-S For fans with a K option, the overall length of the outlet pipe increases by 14 mm.
- Page 15 The fan shown in the figures may slightly differ from your model, while the installation sequence is maintained. The fan is designed for wall or ceiling mounting with direct air exhaust to the ventilation shaft or into the round air duct of matching diameter.
- Page 16 K/K1/PF/PF1/F/F1 series...
- Page 17 M/M1/M3/МА/Silenta-M series...
- Page 18 MAO/M1OK series 180 mm 150MAO1 160 mm 125M1OK2 125MAO1 125MAO2...
- Page 19 D/D1/LD/LD1/S/S1/X/X1/Xstar/Silenta-S series...
- Page 21 R/R1 series...
- Page 22 ELECTRONICS OPERATION ALGORITHM The fan with the T timer activates upon control voltage application to input LT (ST, SL) by an external switch (e.g. indoor light switch). After the control voltage is off, the fan continues to operate within the set time period adjustable from 2 to 30 minutes by the timer.
- Page 23 The fan with the timer and the TP motion sensor – the fan starts when a person moves at a distance of 1 to 4 meters with a horizontal viewing angle of the sensor of 100°. After the movement stops, the fan continues to operate within the set time period adjustable from 2 to 30 minutes by the timer.
- Page 24 Wiring diagram for a fan equipped with a timer/timer and a humidity sensor, without a built-in switch. L(~) LT (ST) N (~) Wiring diagram of the Xstar fan with separate switching on of the fan and the built-in lamp. L(~) N(~) L(~) Wiring diagram of the Xstar fan with the simultaneous switching on of the fan and the integrated lamp.
- Page 25 For T, TH and TP timers VKO1/F1/PF1 R/R1 D/D1/S/S1/LD/X/X1/Silenta-S M/M1/M3/MA/MAO/M1OK2/Silenta-M For T1 timers M/M1/M3/MA/MAO/M1OK2/Silenta-M D/D1/S/S1/LD/X/X1/Silenta-S Jumper Jumper...
- Page 26 TROUBLESHOOTING Problem Possible reasons Troubleshooting Make sure the power supply line No power supply. is connected correctly, otherwise When the unit is connected to power troubleshoot the connection error. mains, the fan does not rotate and does not respond to any controls. Internal connection fault.
- Page 27 MANUFACTURER’S WARRANTY The product is in compliance with EU norms and standards on low voltage guidelines and electromagnetic compatibility. We hereby declare that the product complies with the provisions of Electromagnetic Compatibility (EMC) Directive 2014/30/ EU of the European Parliament and of the Council, Low Voltage Directive (LVD) 2014/35/EU of the European Parliament and of the Council and CE-marking Council Directive 93/68/EEC.
- Page 28 • Replacement and use of any assemblies, parts and components not approved by the manufacturer. • Unit misuse. • Violation of the unit installation regulations by the user. • Violation of the unit control regulations by the user. • Unit connection to power mains with a voltage different from the one stated in the user's manual. •...
- Page 29 MAINTENANCE Disconnect the fan from power supply prior to maintenance and servicing operations. The fan surfaces must be regularly cleaned from dirt and dust. To clean the fan, use a soft cloth or a brush wetted in a mild detergent solution. Do not allow water or liquid come into contact with electric components.
- Page 31 Quality Inspector’s Stamp Sold by (name and stamp of the seller) Manufacture Date Purchase Date...
- Page 32 Certificate of acceptance The fan is recognized as serviceable. V01EN_16-01...
