7. Components

12
8
1. Adjusting mechanism (genius)
2. Piston seat
3. Outer sleeve
4. Volume selector
5. Piston
6. Cylinder sleeve
7. Glass cylinder
8. Valve head (Size 2.5 - 10 ml, GL 32 /
Size 25 - 100 ml, GL 45)
9. Valve ball
10. Intake valve
11. Telescopic intake tube
12. Plug
13. Valve switch (genius)
1
2
3
4
genius
5
6
7
15
9
10
11 22
simplex
13
14
15
16
17
18
19
14. Discharge tube support
15. Securing clip
16. Discharge/recirculation valve (genius);
discharge valve (simplex)
17. Discharge tube securing nut
18. Discharge tube
19. Discharge tube closure cap
20. Tool (Size 2.5 - 10 ml, size 25 - 100 ml)
21. Tool adapter (size 100 ml)
22. Recirculation tube
23. Stopper
20
21
23
19
