4.
Before powering up the ESP-WROVER-KIT, please make sure that the board has been
received in good condition with no obvious signs of damage on it.
1. If using the USB power supply, please use shorting jumpers on JP7 (Power Select), as
shown:
- If using the 5V Input power supply, please use shorting jumpers on JP7, as shown:
2. To enable UART communication, please use shorting jumpers on JP11, as shown:
