- Page 1 IFP1900 INOX PRO Preface Product description SIMATIC Safety instructions Installing the device Industrial monitors IFP1900 INOX PRO Commissioning the device Maintaining and repairing the device Compact Operating Instructions Specifications Technical support 07/2019 A5E35751632-AC...
-
Page 2: Safety Instructions
Note the following: WARNING Siemens products may only be used for the applications described in the catalog and in the relevant technical documentation. If products and components from other manufacturers are used, these must be recommended or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems. -
Page 3: Preface
6AV7484-6AB01-0AA0 ● IFP1900 INOX PRO Support arm variant, article number 6AV7484-6AB11-0AA0 In relation to the operation, the IFP1900 INOX PRO is identical with the base unit IFP1900 Touch Standard. This document describes the mechanical and electrical differences between the device and the base device IFP1900 Touch Standard. -
Page 4: Table Of Contents
Resetting the device to factory settings ................24 Repair ..........................24 Specifications ..........................25 Certificates and approvals ....................25 Guidelines and declarations ....................26 Dimension drawings ......................27 6.3.1 IFP1900 INOX PRO ......................27 6.3.2 Mechanical interface of the device ..................28 Technical specifications ......................28 6.4.1 General technical specifications ..................28 6.4.2 Environmental conditions....................30... -
Page 5: Product Description
Product description The IFP1900 INOX PRO devices are mounted to a support arm or stand by means of the mechanical interface. The IFP1900 INOX PRO devices are not intended for installation in a control cabinet. The figures below show the front view and rear view using a device with operator controls and stand mounting as an example. - Page 6 Product description Features Properties of the IFP1900 INOX PRO: INOX stainless steel, material number 1.4301 • Enclosure material: FPM (fluorinated rubber) • Sealing material: Polyester-based • Front membrane: IP66 all-round • Degree of protection: • Front operator controls: 2 illuminated pushbuttons, 1 EMERGENCY OFF button, wired to...
- Page 7 ● 4 screws for fastening the stainless steel tube with flange from a mounting kit to the mechanical interface of the device ● 1 connecting terminal for the power supply ● Documentation Article number 6AV7675-1JD21-0AA0 IFP1900 INOX PRO Compact Operating Instructions, 07/2019, A5E35751632-AC...
- Page 8 The work described in the service manual may only be carried out by qualified specialist personnel who have been trained correspondingly by Siemens. The service manual is available online under "Product Support" next to this document in the same branch of the product tree.
-
Page 9: Safety Instructions
Safety instructions Intended use The IFP1900 INOX PRO touch screen front panel devices are designed to be used for high- performance visualization tasks (operator control and monitoring) and in ambient conditions such as those found in the food, beverage and pharmaceutical industries. - Page 10 Siemens’ products and solutions undergo continuous development to make them more secure. Siemens strongly recommends that product updates are applied as soon as they are available and that the latest product versions are used. Use of product versions that are no longer supported, and failure to apply latest updates may increase customer’s exposure to...
-
Page 11: Notes About Usage
2.3 Notes about usage Disclaimer for third-party software updates This product includes third-party software. Siemens AG only provides a warranty for updates/patches of the third-party software, if these have been distributed as part of a Siemens software update service contract or officially released by Siemens AG. Otherwise, updates/patches are undertaken at your own risk. -
Page 12: Installing The Device
● Four hexagon screws M5 according to screw standard ISO 4017, material X5CrNi18-10 The length of the screws have to be dimensioned so that the penetration depth of the screw thread in the device-side flange lies in the range of 6 to 10 mm. IFP1900 INOX PRO Compact Operating Instructions, 07/2019, A5E35751632-AC... - Page 13 Note The device is fastened to a stand or a support arm via the mechanical interface with four screws. Siemens AG assumes no liability for the consequences of a faulty installation. WARNING The device must be mounted securely Inadequately dimensioned fastening material may cause the device to fall down. Serious bodily injury may result.
- Page 14 3.5 Nm. The degree of protection IP66 is only ensured with this torque. The device is mounted on the stand. The following steps describe the installation in the connection compartment. IFP1900 INOX PRO Compact Operating Instructions, 07/2019, A5E35751632-AC...
- Page 15 Use copper (Cu) cables for all supply lines that are connected to the device with terminals, e.g. 24 V DC power supply cables on the 24 V DC power supply connector. Use only shielded standard cables as data connecting cables, order information is available on the Internet Industry Mall (https://mall.industry.siemens.com). Note External interface cable Lay external interface cables only indoors or up to a maximum length of 42.6 m outdoors.
- Page 16 The power supply must meet the requirements of NEC Class 2 or LPS according to IEC/EN/DIN EN/UL 60950‑1. The supplying source must be fused for a power rating < 240 VA; recommended fuse rating ≤ 8 A. IFP1900 INOX PRO Compact Operating Instructions, 07/2019, A5E35751632-AC...
- Page 17 Ensure that the latches of the seal lie in the associated notches and that the seal lies flush on the device rear panel. 6. Fasten the connection compartment cover with 6 screws. Tighten the screws using a torque of 3.5 Nm. IFP1900 INOX PRO Compact Operating Instructions, 07/2019, A5E35751632-AC...
-
Page 18: Dismantling The Device
7. Remove the device from the support arm or pedestal. Make sure that the connection cables are not damaged. 8. Fasten the connection compartment cover with 6 screws on the device, torque 3.5 Nm. IFP1900 INOX PRO Compact Operating Instructions, 07/2019, A5E35751632-AC... -
Page 19: Commissioning The Device
Procedure 1. Switch on the IPC. 2. Switch on the power supply of the IFP1900 INOX PRO. 3. Insert the "Documentation and Drivers" DVD into the CD/DVD drive of the IPC. Alternatively, insert the USB stick with the copy of the DVD into a USB port on the device. -
Page 20: Maintaining And Repairing The Device
Damage to the device due to impermissible cleaning agents Impermissible and unsuitable cleaning agents can cause damage the device. Use dish soap or foaming screen cleaner only as cleaning agents. Do not use aggressive solvents or scouring powder. IFP1900 INOX PRO Compact Operating Instructions, 07/2019, A5E35751632-AC... -
Page 21: Clean Screen
When the clean screen is active, operations on the device are not possible. Wait for the period of the clean screen to lapse. Then you can operate the system again with the device. IFP1900 INOX PRO Compact Operating Instructions, 07/2019, A5E35751632-AC... -
Page 22: Chemical Resistance
If the stainless steel parts are unintentionally contaminated with hydrochloric acid, rinse these off immediately with plenty of water. ● Clean the stainless steel surface with a cleansing agent without active chlorine. IFP1900 INOX PRO Compact Operating Instructions, 07/2019, A5E35751632-AC... - Page 23 – Remove any stains or rust immediately. – Remove new rust spots with a mild abrasive detergent in order to prevent any further corrosion. – Rinse the part thoroughly after you cleaned it. IFP1900 INOX PRO Compact Operating Instructions, 07/2019, A5E35751632-AC...
-
Page 24: Resetting The Device To Factory Settings
The reset button is used to reset the device to factory settings, for example, when the IFP1900 INOX PRO can no longer communicate with the IPC for a longer period. During the reset to factory settings, the IP address of the IFP1900 INOX PRO, for example, is reset to the default value "192.168.1.2". -
Page 25: Specifications
DE-90766 Fürth DIN ISO 9001 certificate The Siemens quality management system for all production processes (development, production and sales) meets the requirements of DIN ISO 9001:2000. This has been certified by DQS (the German society for the certification of quality management systems). -
Page 26: Guidelines And Declarations
(EMC Directive), and is designed for operation in the following fields of application according to this CE marking: Field of application Requirement for emissions Requirement for interference immunity Industrial area EN 61000-6-4:2007 +A1:2011 EN 61000-6-2:2005 IFP1900 INOX PRO Compact Operating Instructions, 07/2019, A5E35751632-AC... -
Page 27: Dimension Drawings
Specifications 6.3 Dimension drawings Dimension drawings 6.3.1 IFP1900 INOX PRO The figures below show the dimension drawings using a device with operator controls and stand mounting as an example. IFP1900 INOX PRO Compact Operating Instructions, 07/2019, A5E35751632-AC... -
Page 28: Mechanical Interface Of The Device
6.4.1 General technical specifications Weight Approx. 15 kg Quality assurance In accordance with ISO 9001 DC power supply IFP1900 INOX PRO Rated voltage 24 V DC Permitted voltage range +19.2 V to +28.8 V Rated current 2.0 A Inrush current I 0.5 A... - Page 29 Pixel error class in accordance with ISO 9241-307 Interfaces 2 × USB 2.0, high current LAN interface X1 P1, RJ45 Intel distance connection via Gigabit Ethernet; 10, 100, 1000 Mbps Keyboard, mouse Connection via USB interface IFP1900 INOX PRO Compact Operating Instructions, 07/2019, A5E35751632-AC...
-
Page 30: Environmental Conditions
The IP66 degree of protection is not covered by the UL approval and was not tested as part of the UL approval. Degree of pollution / overvoltage category according to IEC 61131 ● Degree of pollution 2 ● Overvoltage category II IFP1900 INOX PRO Compact Operating Instructions, 07/2019, A5E35751632-AC... -
Page 31: Description Of The Interfaces
The figure below shows the pin assignment of the internal 20-pin terminal strip. ● Pins 1 to 12 are wired with the front operator controls. ● Pins 13 to 20 are not assigned. IFP1900 INOX PRO Compact Operating Instructions, 07/2019, A5E35751632-AC... -
Page 32: Technical Support
You can find additional information and support for the products described on the Internet at the following addresses: ● Technical support (https://support.industry.siemens.com) ● Support request form (http://www.siemens.com/automation/support-request) ● After Sales Information System SIMATIC IPC/PG (http://www.siemens.com/asis) ● SIMATIC Documentation Collection (http://www.siemens.com/simatic-tech-doku-portal) ● Your local representative (http://www.automation.siemens.com/mcms/aspa-db/en/Pages/default.aspx) ●...
