EQUIPMENT
SELECTION
. . . . . . . . . . . . .
Models ERS--1
42 V, 3 phase, 50 Hz
380/220 V, 3 phase, 60 Hz
400/230 V, 3 phase, 50 Hz
460/230 V, 3 phase, 60 Hz
Blades
Coarse (32 Teeth)
Fine (64 Teeth)
. . . . . . . . . . . . .
Balancer (for all models)
JARVIS
6205013.
Ordering No.
. . . . . . . .
4005106
. . .
4005108
. . .
4005107
. . .
4005109
. . . . . . . . . .
1023573
1023574
. . .
4042051
Model ERS- -1
Electric Reciprocating Saw
TABLE OF
CONTENTS
• Notice to Employer and Safety
Director
• Notice to Operators, Maintenance
and Cleanup Personnel
• Parts Diagram and List
• Specifications
• Installation Instructions
• Operation Instructions
• Maintenance Instructions
PRODUCTS CORPORATION
®
33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457-4926
UNITED STATES OF AMERICA
TEL. 860-347-7271
. . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . .
. . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . .
. . . . . . . . . . . . .
. . . . . . . . . .
jarvis.products.corp@snet.net
E--MAIL
jarvisproducts.com
FAX. 860-347-6978
WWW.
Page
2
3
4
7
7
7
8

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ERS-1 and is the answer not in the manual?

Questions and answers

Related Manuals for Jarvis ERS-1

Summary of Contents for Jarvis ERS-1

  • Page 1 ... . . Balancer (for all models) • Maintenance Instructions ... . . 4042051 JARVIS PRODUCTS CORPORATION ® 33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457-4926 jarvis.products.corp@snet.net UNITED STATES OF AMERICA E--MAIL jarvisproducts.com...

  • Page 2: Notice To Employer And Safety Director

    10. Avoid injury. Do not permit the tool to be misused. 11. If you resell or distribute a Jarvis product, you must provide the purchaser with the appropriate safety sheets and tool brochure. Additional copies of safety sheets and tool brochures will be provided upon request.

  • Page 3: Notice To Operators, Maintenance And Cleanup Personnel

    11. Always use both hands when starting and operating the tool to avoid the risk of possible “kick back” or “recoil”. Continue holding the tool with both hands until the saw blade comes to a complete stop. JARVIS PRODUCTS CORPORATION ®...
  • Page 4 Hanger 1071064 Weight 1036342 Hanger Bushing 1028137 Connecting Rod 1004337 Washer 1021475 Ball Bearing 1055994 Hex Head Screw JARVIS PRODUCTS CORPORATION ® 33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457-4926 jarvis.products.corp@snet.net UNITED STATES OF AMERICA E--MAIL 6205013. .jarvisproducts.com TEL. 860-347-7271 FAX. 860-347-6978...
  • Page 5 Cord Connector 1001045 Signal Cord to Control Box 20 ft Assemblies 1063209 Electric Plug 1063623 Rubber Grommet for item 83 JARVIS PRODUCTS CORPORATION ® 33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457-4926 jarvis.products.corp@snet.net UNITED STATES OF AMERICA E--MAIL 6205013. .jarvisproducts.com TEL. 860-347-7271...
  • Page 6 Contactor 1017085 Danger Label 1072117 Overload Relay 1017459 Connection Diagram 1063822 Terminal Block Base 3063454 Control Box Assembly JARVIS PRODUCTS CORPORATION ® 33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457-4926 jarvis.products.corp@snet.net UNITED STATES OF AMERICA E--MAIL 6205013. .jarvisproducts.com TEL. 860-347-7271 FAX. 860-347-6978...

  • Page 7: Specifications

    If the tool malfunctions, remove it 1 Install the Model ERS- -1 saw above the work station from service and report the problem to your supervi- from a balancer. Jarvis part number 4042051 is sor immediately. Always use both hands when available.

  • Page 8: Maintenance Instructions

    4.3.1 The front end of the ERS- -1 should be point- ing upward while sawing through the tail 1.2 Apply Jarvis 1315 White Grease to grease fittings bone. (items 26 and 33). The fittings can be reached by inserting a grease gun through two of the three ac- 4.4 When the tail bone hits the housing of the ERS- -1,...
  • Page 9 11.7 Inspect all parts for wear and replace if necessary. 8 MOTOR ASSEMBLY: 12 FRAME AND GUIDE ASSEMBLY: 8.1 Reverse steps and procedures outlined in section 12.1 Reverse steps and procedures outlined in section JARVIS PRODUCTS CORPORATION ® 33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457-4926 jarvis.products.corp@snet.net...
  • Page 10 Model ERS--1 page 10 of 12 JARVIS PRODUCTS CORPORATION ® 33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457-4926 jarvis.products.corp@snet.net UNITED STATES OF AMERICA E--MAIL 6205013. .jarvisproducts.com TEL. 860-347-7271 FAX. 860-347-6978...
  • Page 11 Model ERS--1 page 11 of 12 JARVIS PRODUCTS CORPORATION ® 33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457-4926 jarvis.products.corp@snet.net UNITED STATES OF AMERICA E--MAIL 6205013. .jarvisproducts.com TEL. 860-347-7271 FAX. 860-347-6978...
  • Page 12 Model ERS--1 page 12 of 12 PRODUCTS CORPORATION JARVIS JARVIS PRODUCTS CORPORATION ® PRODUCTS CORPORATION ® 33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457--4926 33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457-4926 jarvis.products.corp@snet.net UNITED STATES OF AMERICA E--MAIL jarvis.products.corp@snet.net UNITED STATES OF AMERICA E--MAIL •...
