IB505024EN
Installation Instructions for Field Installing the Sure-Lites Two Circuit (2C) Exit Sign
Conversion Kit
WARNING
Risk of Fire/Electric Shock
If not qualified, consult an electrician.

Important Safeguards

WHEN USING ELECTRICAL EQUIPMENT, BASIC SAFETY
PRECAUTIONS SHOULD ALWAYS BE OBSERVED INCLUDING
THE FOLLOWING.
1. READ AND FOLLOW ALL SAFETY INSTRUCTIONS
2. Do not use outdoors.
3. Do not use in hazardous locations, or near gas or electric
heaters.
4. Do not let power supply cords touch hot surfaces.
5. Use caution when servicing batteries. Battery acid can
cause burns to skin and eyes. If acid is spilled on skin
or in eyes, flush acid with fresh water and contact a
physician immediately.
6. Do not use this equipment for other than the intended use.
7. Installation is to be performed only by qualified personnel.
8. Install in accordance with National Electric Code and local
regulatory agency requirements.
9. The use of accessory equipment not recommended by the
manufacturer may cause an unsafe condition.
10. Equipment should be mounted in locations and at heights
where it will not readily be subjected to tampering by
unauthorized personnel.
11. SAVE THESE INSTRUCTIONS

Contents Of This Kit

2nd Circuit Power Supply Printed Circuit Board (PCB)
Insulating Paper-LPX (1 pc.)
Insulating Paper-CX (1 pc.)
Insulating Paper-SLX (1 pc.)
Double Sided Tape (2 pcs.)
049-278
Risk of Electric Shock
Disconnect power at fuse or circuit breaker before
installing or servicing.

INSTALLATION - LPX

1. De-energize the circuit at the junction box (J-box) where
2. Open the fixture by placing a flat head screwdriver in the
3. Slide the 2C circuit board in the pocket provided in the
4. Rout the wires through the opening, and plug the 2C
5. Place the insulating paper over the PCB in the pocket.
6. Connect the incoming wires from the auxiliary source
7. Replace the Exit face.
8. Energize the primary power supply. The sign should light.
9. De-energize the primary power supply. Energize the
Figure 1 - LPX Assembly
SURE-LITES
WARNING
the emergency light is to be installed.
slots at the top or bottom of the fixture and releasing the
snaps.
fixture frame (See Figure 1).
connector to its corresponding location on the main LED
PCB (see Schematic).
to the 2C PCBs power supply wires using the wire nuts
provided. Connect the white wire to neutral. If using
120V, connect the black wire to the hot lead. If using 277V,
connect the orange wire to the hot lead. Cap the unused
lead (see schematic).
auxiliary power supply. The sign should light.
2C Power Supply PCB
Insulating Paper
INS #
