F01_GB_ROC2407
6. Should the set not switch off, repeat step 2. Then
type in the next 4-digit code. Try to switch off the set
by pressing key B
B once. Repeat this procedure by
trying out each of the 4-digit codes.
Check of the programming:
In principle, your set is ready for receiving the remote
control commands.
Check your remote control for proper functioning by
performing the test described on page 2.
Method C – Programming by means
of code retrieval
Should none of the codes work, you still have the
possibility of retrieving the appropriate code without
having to perform any input.
1. Switch on the set you want to control.
2. Hold down the SETUP key until the key that
corresponds to the last mode you selected blinks
and then remains lit.
3. Press the key that corresponds to the type of
equipment you want to control:
TV: television set,
DVD/VCR: video recorder - DVD player.
4. Direct the remote control towards the set and try to
switch it off by pressing the key B
5. If the set you want to control switches off, press OK
to memorise the code.
6. Should the set not switch off, press key B
times as required (up to 200 times), until the set
switches off. Between two key presses, leave
enough time for the key corresponding to the
selected mode enough time to light up again (about
1 second). Proceeding this way will enable you to
see whether the set responds or not.
7. Immediately upon the switching-off of the set to be
controlled, press OK to store the code.
Check of the programming:
In principle, your set is ready for receiving the remote
control commands.
Check your remote control for proper functioning by
performing the test described on page 2.
Try out other remote control keys to find out the range
of functions you can control. If you think that not all of
the keys are active, repeat the procedure of this
programming method to find out the code supporting a
wider range of features.
Method D - Automatic
code search
With this method, the remote control scrolls through the
full code list by sending an IR signal to the set to be
controlled remotely. Proceed as follows:
1. Check that your equipment is on. If not, switch it on
manually.
2. Hold down the SETUP key until the key that
corresponds to the last mode you selected blinks
and then remains lit (the indicator light remains on
for a few seconds to give you the time to proceed
with the following steps. The indicator lamp flashes
to signal that this time is almost up, and then goes
off).
3. Release the SETUP key.
4. Press the key corresponding to the type of
equipment (for example TV).
5. Press the PROG+ or standby B
(DVD/VCR only) key. After a few seconds, the
remote control begins to scroll through the whole
code list included in the library (at a rate of roughly
1 code per second). Press the PROG+ key once
again to slow down the test speed (1 code every 3
seconds). As soon as the set changes channels, you
must press OK to save the code and stop the
remote control scrolling through the list. If you do
not react quickly enough, you can go back to the
previous code by pressing PROG- or G
(DVD/VCR only) as many times as necessary (you
can go forward by pressing B
(DVD/VCR only) if you have gone back too far).
As soon as the set responds again, press OK to
save the code.
5/02/07
10:57
B .
B as many
B or
B , PROG+ or
2
Page 2
Method E – Programming for control of
a COMBO (combined TV-VCR,TV/DVD,
VCR/DVD, ... set)
Depending on the COMBO group (TV/VCR,
VCR/DVD, etc.) and the make, you will be required to
enter a single code for both devices in the COMBO, or
to enter two codes, one code per device. Consult the
separate list to discover this.
Before you start programming, you must find the
subcode or code of the subset to be controlled
(television or video recorder). Refer to the list supplied
with this user manual (see page subcodes or codes).
1. Switch on the COMBO you want to control.
2. Hold the SETUP key down until the key
corresponding to the last selected mode blinks and
then remains lit.
3. Press the key of the first device to control, and then
follow one of the programming methods A, B, C or
D previously described.
4. If a second code programming is required, then
repeat steps 2 and 3 above.
How to retrieve
a programmed code
It may be useful to retrieve the code programmed in the
remote control.
1. Hold down the SETUP key until the key that
corresponds to the last mode you selected blinks
and then remains lit.
2. Press the key that corresponds to the type of
equipment you want to control:
TV: television set,
DVD/VCR: video recorder - DVD player.
3. Press the SETUP key briefly, so that the last mode
selected blinks once.
4. Press the numbered keys in ascending order (0 to
9) until the selected mode blinks once.
5. The number that caused the selected mode to blink
is the first of the four numbers that make up your
code. Make a note of it below.
6. Repeat step 4 to find out the two other numbers of
the code.
7. When the fourth number has been found, the
indicator light for the selected mode goes out.
Check of
the programming
- For a television set: turn on the set and press, for
example, 2 to change channels.
- Video recorder: load a tape and then press
- DVD player: load a DVD and then press
Try other remote control keys to find out the range of
functions you can control. If you think that not all of the
keys are active, try the programming Method B or C.
When you have retrieved the code of your
set, jot it down so that you can use it
whenever needed.
After battery replacement, you'll have to
programme the remote control again.
TV CODE
VCR CODE
OR
DVD CODE
.
.
