Specifications; General Specifications; Power Supply Specifications - OE Max Controls NX7-28ADR Manual

Specifications

General Specifications

Item
Operating
Temperature
Storage
Humidity Operating
Withstand voltage
Allowed momentary power
failure
Noise immunity
Insulation resistance
Vibration immunity
Dust condition
Chemicals
Corrosive gas
Shock immunity
Grounding
Case material
Cooling method
Ambience

Power Supply Specifications

Item
Rated voltage
Allowable voltage range
Rated current consumption
Input power frequency
Inrush current
Rated output current
AC power circuit configuration
10
0 to 55° C
-20 to 70° C
10 to 90% RH (Non-condensing)
1500V ac for 1 minute between external terminal (ac) and frame
ground (FG)
500V ac for 1 minute between external terminal (dc) and frame
ground (FG)
20 ms or less
1500 Vp-p pulse width 50 ns, 1
Ω
10 M
10 to 55 Hz /1 min, amplitude 0.75 mm, each direction of X, Y, Z
for 10 min
No conductive dust
No cutting oil and organic solvents
No corrosive gas
2
98m/S or more, 4 times X, Y, Z each direction
Class 3 grounding (100
PC/ABS
Natural air cooling
No corrosive gas, no excessive dust
AC input power
110 to 220V ac, free voltage
85 to 264V ac
33 Watts
47 to 63 Hz
3A or less
For internal power: 2.0A at 5V
For external output: 0.4A at 24V
85 to 264V ac
Specifications
µ s (generated by noise simulator)
Ω
or less)
DC input power
24V dc
24V ± 10% dc
33 Watts
-
5A or less
For internal power: 2.0A at 5V
For external output: 0.4A at 24V
Internal
circuit
