Output Specifications

Item
Catalog number
Output points
Insulation method
Rated input voltage
Load voltage range
Max. load current
Off → On
Response time
On → Off
Surge absorber
Internal current consumption
Common method
Status display
External connection method
Recommended wire size
Internal circuit and wiring diagram
28 points (12 output points)
48 points (20 output points)
Relay output module
28xxR for relay output
12 points
Relay insulation
250V ac, 30V dc
85 to 264V ac, 10 to 30V dc
2A per point. 6A per common (for 6 points)
10 ms or less
10 ms or less
Not applicable
300 mA or less at 5V
1, 4 and 6 points per common
LED
Terminal block (M3.0), terminal width: 6.4 mm or less
2
0.5 to 1.25 mm
48xxR for relay output
20 points
500 mA or less at 5V
Internal circuit
2A
Vcc OUT
LOAD
COM 5 to 30V dc
100/200V ac
13
