Installing and Wiring
Product Dimensions
* 28 points (base and expansion)
* 48 points
Installation Dimensions
* 28 points
81.0 mm
(31.9 in)
9.5
3.0
16
100 mm
146 mm
100 mm
87.0 mm
(3.43 in)
79.0 mm
90 mm
76.6 mm
90 mm
* 48 points
146.0 mm
126.0 mm
(4.96 in)
87.0 mm
(3.43 in)
3.0
35 mm DIN
rail mounting
holder
unit: mm
Φ 4.2
10.0
