OE Max Controls NX7-28ADR Manual page 12

Item
Catalog number
Output points
Insulation method
Rated load voltage
Load voltage range
Polarity
Max. load current
Max. inrush current
Off state leak current
Off → On
Respons
e time On → Off
Internal current
consumption (5V)
Common method
Status display
External connection
method
Recommended wire size
Internal circuit and wiring diagram
28 points (12 output points)
10 to 30V dc
48 points (20 output points)
14
28xxT for transistor output
12 points
Photocoupler
12 to 24V dc
10 to 30V dc
- common (Sink type, NPN)
0.4A per point, 1.0A per common
3A, 10 ms or less
100 A or less
1 ms or less
1 ms or less
80 mA or less
1, 4, and 6 points per common
LED
Terminal block (M3.0), terminal width: 6.4 mm or less
2
0.5 to 1.25 mm
Transistor output
48xxT for transistor output
20 points
Internal circuit
24V dc Int'
Power
Int' OV
60 to
200mA
COM
10 to 30V dc
