If a fault code appears, the setpoint operation
continues to function. Rotate the dial slightly and the
backlight on the LCD lights up. The fault code
disappears and the setpoint reappears. You can adjust
the setpoint. The fault reappears after approximately
35 seconds of adjusting the setpoint.
°F/°C Temperature Mode Selection
Certain models include a °F/°C push button on the face
of the network sensor to provide temperature scale
options for display. Pressing the push button toggles
the temperature mode between Fahrenheit and Celsius
on the LCD.

Network Sensor Addressing

Most network sensors have a default device address of
199 on the SA Bus. For averaging models, the sensor
address must be set on the dual-switch DIP switch
block on the network sensor Printed Wire Board
(PWB).
Averaging models are shipped with both switches set
to ON, resulting in a device address of 203. Device
addresses can be DIP switch set from 200 to 203; see
4 NS Series Network Sensors with Fault Code Capability Installation Instructions
Figure 4 and Table 1 for more details.
O
N
Figure 4: Dual-Switch
DIP Switch Block
Table 1: Network Sensor Addressing
DIP Switch Switch 2
Address
200 OFF
201 OFF
202 ON
203 ON
ON
2 1
Switch 1
OFF
ON
OFF
ON
