Starting up
You need power supply to get enough electricity to drive the HDDs. With the
USB 3.1 Type-C
USB 3.1 Type-C
port with DisplayPort
2.0 Charging a USB 3.1 (Gen 2) port with USB Power Delivery 2.0 support
for
5 V/3 A, 9 V/2 A or 12 V / 2 A is necessary.
Attention: Depending on the host system, most won´t charge while in use.
The delivered power is suitable for charging the host computer while it is idle
or turned off.

HDD/SSD Installation

1. Mount your hard drives onto the removable drive tray and secure it
with the screws included in the
HDD
2. Connect the enclosure unit to the computer via the delivered USB 3.1
Type-C
™
3. Attach the AC power cable to the DC power adapter then con-
nect one end to the power socket on the enclosure unit and the
other end to the power socket.
4. Once completed, you may power on the unit. Once your compu-
ter has also booted, your operating system should recognize the
drive automatically.
5. If the hard drive installed requires formatting, follow the formatting
instructions given by the operating system to format the drive volu-
me to your preference. Once the formatting has been completed,
the device is ready for use.
Application − Using the external drive
Connect the device via the USB cable to the computer. Then connect the
power adapter and switch the power button on.
Manual IB-367-CPD+
data cable you can connect the IB-367-CPD+ to a
™
interface. For mini DP usage a USB 3.1 (Gen 2) Type-C
™
alternate mode is necessary. For USB Power Delivery
™
cable.
or
™
SSD
