75000 Series C
Service Manual
Keysight E1463A 32-Channel
5-Amp Form C Switch

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VXI bus 75000 C Series and is the answer not in the manual?

Questions and answers

Related Manuals for Keysight VXI bus 75000 C Series

Summary of Contents for Keysight VXI bus 75000 C Series

  • Page 1 75000 Series C Service Manual Keysight E1463A 32-Channel 5-Amp Form C Switch...
  • Page 3 Warranty © Keysight Technologies, Inc. 1997-2019 No part of this manual may be repro- To contact Keysight for sales and techni- THE MATERIAL CONTAINED IN THIS duced in any form or by any means cal support, refer to the support links on DOCUMENT IS PROVIDED “AS IS,”...
  • Page 4 In Case of Damage Cleaning Instruments that appear damaged or Clean the outside of the Keysight mod- defective should be made inoperative ule/chassis with a soft, lint-free, and secured against unintended oper- slightly dampened cloth. Do not use ation until they can be repaired by detergent or chemical solvents.
  • Page 5 Safety Symbols A CAUTION denotes a hazard. It calls attention to an operating pro- cedure or practice, that, if not cor- rectly performed or adhered to could result in damage to the product or loss of important data. Do not proceed beyond a CAUTION notice until the indicated condi- tions are fully understood and met.

  • Page 7: Table Of Contents

    Keysight E1463A Description ........18...
  • Page 8 Post-Repair Safety Checks ........62 Component Locators and Schematic Diagrams ......62 Keysight E1463A Form C Switch Service Guide...

  • Page 9: General Information

    Keysight E1463A 32-Channel Form C Switch Service Guide General Information Introduction This manual contains information required to test, troubleshoot, and repair the Keysight E1463A 32-Channel Form C Switch Module (see Figure 1-1). Figure 1-1 Keysight E1463A Form C Switch...

  • Page 10: Relay Life

    However, this method requires knowledge of the applied load and life specifications for the applied load. For the Keysight E1463A, maximum relay life is specified at 5 X 107 operations with no load and 3.5 X 104 operations at the worst-case rated load.

  • Page 11: Safety Considerations

    An uninterruptible safety earth ground must be provided from the main power source to the supplied power cord set. Keysight E1463A 32-Channel Form C Switch Service Guide...
  • Page 12 SHOCK HAZARD. Only service-trained personnel who are aware of the hazards involved should install, remove, or configure the Keysight E1463A 32-Channel Form C Switch Module . Before you remove any installed module, disconnect AC power from the mainframe and from other modules that may be connected to the Switch Module.

  • Page 13: Inspection/Shipping

    Verification Tests are optional. To avoid possible hazardous electrical shock, do not perform electrical tests if there are signs of shipping damage to the shipping container or to the instrument. Keysight E1463A 32-Channel Form C Switch Service Guide...
  • Page 14 General Information Inspection/Shipping Figure 1-2 Initial (Incoming) Inspection Guidelines Keysight E1463A 32-Channel Form C Switch Service Guide...

  • Page 15: Shipping Guidelines

    Inspection/Shipping General Information Shipping Guidelines Follow the steps in Figure 1-3 to return the Module to an Keysight Technologies Sales and Support Office or Service Center. Figure 1-3 Packaging/Shipping Guidelines * We recommend that you use the same shipping materials as those used in factory packaging (available from Keysight Technologies).

  • Page 16: Environment

    C to +40 Shipment Switch Module Description The Keysight E1463A 32-Channel Form C Switch Module is an "instrument" in the slots of a VXIbus mainframe. Each module is assigned an error queue, input and output buffers, and a status register.

  • Page 17: Switch Module Serial Numbers

    Devices covered by this manual are identified by a serial number prefix listed on the title page. Keysight Technologies uses a two-part serial number in the form XXXXAYYYYY, where XXXX is the serial prefix, A is the country of origin (A=USA), and YYYYY is the serial suffix.
  • Page 18 General Information Recommended Test Equipment Keysight E1463A 32-Channel Form C Switch Service Guide...

  • Page 19: Verification Tests

    Verification Tests Introduction The three levels of test procedures described in this chapter are used to verify that the Keysight E1463A 32-Channel Form C Switch Module: – is fully functional (Functional Verification) – meets selected testable specifications (Operation Verification) – meets all testable specifications (Performance Verification) Test Conditions and Procedures See Table 1-1 for test equipment requirements.

  • Page 20: Switch Module Functional Verification

    Switch Module Functional Verification Switch Module Functional Verification The Functional Verification Test for the Keysight E1463A 32-Channel Form C Switch Module consists of sending the *TST? command and checking the response. This test can be used at any time to verify that the device is connected properly and is responding to basic commands.

  • Page 21: Operation Verification

    Verification tests are usually a subset of the Performance Verification tests and are suitable for checkout after performing repairs. For the Keysight E1463A Switch Module, Operation Verification is performed by completing the Closed Channel Resistance Test as described in the Performance Verification test procedures (Test 2-1).

  • Page 22: Performance Verification

    You may want to order an extra terminal module to use as a test fixture, so you don’t have to re-wire each time the tests are performed. The Keysight E1463A terminal module part number is E1463-80011 (for modules with serial numbers prior to 3126A01817, the terminal module part number is E1463-80001).

  • Page 23: Test 2-1: Closed Channel Resistance Test

    3 Repeat for Channels 1 through 31 C to NO – Repeat step 2 for channels 1 through 31 – Use OPEN (@nncc) and CLOS (@nncc), where nn = card # and cc = channel # (omit leading zeroes in nn) Keysight E1463A 32-Channel Form C Switch Service Guide...

  • Page 24: Channel 0 C To Nc Measurements

    – Send OPEN (@nn00) to open channel 0, where nn = card # (typically 01) – Trigger the DMM with TRIG SGL and note reading – Enter the result in Table 2-1 for Channel 0 C to NC Keysight E1463A 32-Channel Form C Switch Service Guide...
  • Page 25 31 relay contact resistances. If the relay contact resistance for a channel is >2.0 ? the program prints a message indicating which channel has failed the test. Use this list in Chapter 4 when troubleshooting a failing relay. Keysight E1463A 32-Channel Form C Switch Service Guide...
  • Page 26 This test assumes that the module is configured without protection varistors, fuses, or resistors and that jumpers JM1 through JM8 are installed on the Keysight E1463A Component Assembly (factory setting). Refer to the Keysight E1463A User’s Manual for details and locations of user installed protection circuits 10!RE-SAVE "CLOS_TEST"...
  • Page 27 460PRINT "Repair problem and re-run test" 470STOP 480END IF 490FOR I=0 TO 31 500IF J<1 THEN 510IF I <10 THEN 520OUTPUT @Sw;"CLOS (@"&Cc$&Ph$&VAL$(I)&")" 530ELSE 540OUTPUT @Sw;"CLOS (@"&Cc$&VAL$(I)&")" 550END IF 560ELSE 570IF I <10 THEN 580OUTPUT @Sw;"OPEN (@"&Cc$&Ph$&VAL$(I)&")" Keysight E1463A 32-Channel Form C Switch Service Guide...
  • Page 28 830 IF Opc<>1 THEN GOTO 810 840 IF Result(J,I)<0 THEN Result(J,I)=0 850 IF Result(J,I)>2.0 THEN 860 PRINT "Resistance for Channel ";I;" "&Path$(J)&" contacts is >2.0 Ohms" 870 END IF 880 NEXT I Keysight E1463A 32-Channel Form C Switch Service Guide...
  • Page 29 0.2628 Ohms CH 5 0.1226 Ohms 0.1389 Ohms CH 6 0.1499 Ohms 0.1678 Ohms CH 7 0.1547 Ohms 0.1817 Ohms CH 8 0.3347 Ohms 0.2257 Ohms CH 9 0.4932 Ohms 0.3096 Ohms Keysight E1463A 32-Channel Form C Switch Service Guide...
  • Page 30 0.1723 Ohms CH 27 0.2362 Ohms 0.1876 Ohms CH 28 0.2808 Ohms 0.1874 Ohms CH 29 0.4140 Ohms 0.2340 Ohms CH 30 0.1692 Ohms 0.1412 Ohms CH 31 0.1822 Ohms 0.1833 Ohms Keysight E1463A 32-Channel Form C Switch Service Guide...

  • Page 31: Test 2-2: Dc Isolation Test

    DMM indicates an overload, record the reading as >Rmax, where Rmax is the highest resistance that the DMM can measure. For example, if the DMM is an Keysight 3458A, a typical return for an overload is 1.E+38 and the entry in Table 2-1 should be >1.2 G .

  • Page 32: Nc (&C) To Chassis Isolation

    2 Set DMM to 2-wire ohms, 1 G  range 3 Send *RST to Module 4 Trigger the DMM with TRIG SGL 5 Record the DMM reading in Table 2-1 (NC to Chassis) Figure 1-8 NO and NC to Chassis Isolation Keysight E1463A 32-Channel Form C Switch Service Guide...

  • Page 33: No (&C) To Chassis Isolation

    60 DIM Result(2) 70 PRINT "Equipment Connections " 80 PRINT 90 PRINT " 1. Turn Mainframe and Keysight 3458A DMM power OFF" 100PRINT " 2. Connect GPIB Cable between mainframe and DMM" 110PRINT " 3. Install E1463A Component Assembly into Mainframe "...
  • Page 34 510PRINT "DC Isolation tests complete" 520DISP "Press Continue to print measurement results" 530PAUSE 540CLEAR SCREEN 550PRINT TABXY(1,1),"DC Isolation Tests" 560PRINT TABXY(1,3),"NC to NO (Ohms)";Result(0) 570PRINT TABXY(1,4),"NC to Chassis (Ohms)";Result(1) 580PRINT TABXY(1,5),"NO to Chassis (Ohms)";Result(2) Keysight E1463A 32-Channel Form C Switch Service Guide...
  • Page 35 Test 2-2: DC Isolation Test Verification Tests 590END Typical Result DC Isolation Tests NC to NO (Ohms) 1E+38 NC to Chassis (Ohms) 1E+38 NO to Chassis (Ohms) 1E+38 Keysight E1463A 32-Channel Form C Switch Service Guide...

  • Page 36: Performance Test Record

    Test Limits Test limits are defined for Closed Channel Resistance Test and DC Isolation Test using the specifications in Appendix A of the Keysight E1463A 32-Channel Form C Switch Module User’s Manual. The specifications are single-sided, (i.e., there is an upper limit or a lower limit, but not both). In the Performance Test Record, the Minimum or Maximum column will be blank.

  • Page 37: Test Accuracy Ratio (Tar)

    Test Facility: Name ____________________________Report No. ________________________________ Address ___________________________Date _____________________________________ City/State _________________________ Phone _____________________________________ Customer __________________________ Tested by ___________________________________ Special Notes: _________________________________________________________________________ _____________ _________________________________________________________________________ _____________ _________________________________________________________________________ _____________ _________________________________________________________________________ _____________ _________________________________________________________________________ _____________ _________________________________________________________________________ _____________ Keysight E1463A 32-Channel Form C Switch Service Guide...
  • Page 38 Verification Tests Performance Test Record Test Equipment Record Test Equipment Used: Description Model No. Trace No. Cal Due Date Keysight E1463A 32-Channel Form C Switch Service Guide...
  • Page 39 Channel 24 8.000E-5 Channel 25 8.000E-5 Channel 26 8.000E-5 Channel 27 8.000E-5 Channel 28 8.000E-5 Channel 29 8.000E-5 Channel 30 8.000E-5 Channel 31 8.000E-5 *Single-sided specification - Minimum value does not apply Keysight E1463A 32-Channel Form C Switch Service Guide...
  • Page 40 Channel 21 8.000E-5 Channel 22 8.000E-5 Channel 23 8.000E-5 Channel 24 8.000E-5 Channel 25 8.000E-5 Channel 26 8.000E-5 Channel 27 8.000E-5 Channel 28 8.000E-5 Channel 29 8.000E-5 Channel 30 8.000E-5 Channel 31 8.000E-5 Keysight E1463A 32-Channel Form C Switch Service Guide...
  • Page 41 Verification Tests Test 2-2 DC Isolation (values in Ohms) NO to NC 1.2E9 6.1E6 NC to Chassis 1.2E9 6.1E6 NO to Chassis 1.2E9 6.1E6 * Single-sided specification - Minimum/Maximum value does not apply Keysight E1463A 32-Channel Form C Switch Service Guide...
  • Page 42 Verification Tests Performance Test Record Keysight E1463A 32-Channel Form C Switch Service Guide...

  • Page 43: Replaceable Parts

    This chapter contains information for ordering replaceable parts for the Keysight E1463A 32-Channel Form C Switch Module. Ordering Information To order a part listed in this chapter, specify the Keysight Technologies part number and the quantity required. Send the order to your nearest Keysight Technologies Sales and Support Office.

  • Page 44: Replaceable Parts List

    CAPACITOR-FXD 1000pF +-5% 100 V 0160-4801 CAPACITOR-FXD 100pF +-5% 100 V C402 0160-4822 CAPACITOR-FXD 1000pF +-5% 100 V C403 CAPACITOR-FXD 100pF +-5% 100 V 0160-4801 C404 CAPACITOR-FXD 0.1uF +-10% 50 V 0160-4835 C405-C406 Keysight E1463A 32-Channel Form C Switch Service Guide...
  • Page 45 RESISTOR 200 +-1% .125W TF TC=0+-100 R303-R304 0757-0407 RESISTOR 10 +-1% .125W TF TC=0+-100 R305-R306 0757-0346 RESISTOR 200 +-1% .125W TF TC=0+-100 R401-R402 0757-0407 RESISTOR 10K +-1% .125W TF TC=0+-100 R403-R404 0757-0442 Keysight E1463A 32-Channel Form C Switch Service Guide...
  • Page 46 U401-U402 1820-4086 TRANSISTOR ARRAY 18-PIN PLASTIC DIP U403-U404 1858-0069 † NOTE: For modules with serial numbers prior to 3126A01817, the following parts must be used for replacement (see inset in figure 3-1). Keysight E1463A 32-Channel Form C Switch Service Guide...
  • Page 47 E1400-84106 SCREW-MACHINE ASSY M2.5 X 12MM-LG *PNL1 E1463-00201 PAN-HD *SCR1-*SCR2 0515-0368 SCREW-MACHINE M2.5 X 0.45 6MM-LG *SCR9-*SCR10 0515-1375 FLAT-HD SCREW PH M2.5 X 11TX *SCR11-*SCR12 0515-1968 Figure 3-9 E1463A Mechanical Replaceable Parts Keysight E1463A 32-Channel Form C Switch Service Guide...
  • Page 48 Replaceable Parts Replaceable Parts List Table 3-2 Keysight E1463A Terminal Case Replaceable Parts (for modules with serial numbers after 3126A01818) Reference Keysight Part Part Description Designator Number E1400-84405 Case Assembly - Terminal E1400-45103 Top Lever E1400-45104 Bottom Lever 1460-2552 Torsion Spring - Left Hand Wound...
  • Page 49 Replaceable Parts List Replaceable Parts Table 3-3 Keysight E1463A Terminal Case Replaceable Parts (for modules with serial numbers prior to 3126A01817) Reference Keysight Part Part Description Designator Number E1400-84401 TERMINAL MODULE CASE ASSY (See Figure 3-1) 03852-01201 CLAMP 03852-86701 PAD-CLAMP 0515-2109 SCREW-MACHINE 10-24 .625-IN-LG...
  • Page 50 Replaceable Parts Replaceable Parts List Table 3-4 Keysight E1463A Terminal Module PCA Replaceable Parts Reference Keysight Part Part Description Designator Number E1463-66510 TERMINAL MODULE PC ASSEMBLY (See Figure 3-3) P1-P2 1252-1577 CONNECTOR-POST TYPE 5.08-PIN-SPCG 48-CONTACT TB1-TB8 0360-2391 TERMINAL MODULE 12 P. POLYAMIDE NOTE: For option A3G replaceable parts, see Table 3-2.
  • Page 51 J ....electrical connector (jack) SCR..... screw JM ....jumper SHD .... shield K ....relay SW ....switch MNL .....manual TB ....terminal block (module) MP ....mechanical part U ....integrated circuit Keysight E1463A 32-Channel Form C Switch Service Guide...
  • Page 52 Replaceable Parts Replaceable Parts List Keysight E1463A 32-Channel Form C Switch Service Guide...

  • Page 53: Service

    Keysight E1463A 32-Channel Form C Switch Service Guide Service Introduction This chapter contains service information for the Keysight E1463A Form C Switch Module, including troubleshooting techniques and repair and maintenance guidelines. Do not perform any of the service procedures shown unless you are a qualified, service-trained technician, and have read the WARNINGS and CAUTIONS in Chapter 1.

  • Page 54: Troubleshooting

    See Table 4-4 for information on self-test errors. *TST? command. Operator Errors Non-zero error code in response to the See Appendix C of the the Keysight E1463A User’s SYST:ERR? command. Manual for Switch Module errors and causes. See Appendix B of the Keysight E1405 User’s Manual for additional information on operator errors.

  • Page 55: Testing The Assembly

    – ? Check connectors J1, J2, P1, and P2 for damage. – ? Perform Test 2-1 in Chapter 2. Matching Relays to Channels Use Table 4-3 to help match channel numbers to relay and drive circuit reference designators. Keysight E1463A 32-Channel Form C Switch Service Guide...
  • Page 56 Service Troubleshooting Table 4-8 Channel Relays/Reference Designators Channel Relay Driver Driver Register U303 U301 U304 U302 U403 U401 U404 U402 Keysight E1463A 32-Channel Form C Switch Service Guide...

  • Page 57: Self-Test Error Codes

    Busy bit was not held ≈10.5 to 18.5 msec +ss11 *ss = card number (with leading zero deleted) Disassembly Use the following procedures to disassemble the Keysight E1463A Switch Module. For disassembly refer to Figure 4-1. Switch Module Disassembly 1 To remove the covers: –...
  • Page 58 Service Troubleshooting Figure 4-13 Keysight E1463A Disassembly Keysight E1463A 32-Channel Form C Switch Service Guide...

  • Page 59: Repair/Maintenance Guidelines

    Repair/Maintenance Guidelines Service Repair/Maintenance Guidelines This section provides guidelines for repairing and maintaining the Keysight E1463A Switch Module, including: – ? ESD precautions – ? Soldering printed circuit boards – ? Post-repair safety checks ESD Precautions Electrostatic discharge (ESD) may damage static-sensitive devices in the switch modules.

  • Page 60: Post-Repair Safety Checks

    E1463A Form C Switch - Relay Drivers/Relays 0-15 S-E1463-66501 (4 of 5) E1463-66501 E1463A Form C Switch - Relay Drivers/Relays 16-31 S-E1463-66501 (5 of 5) E1463-66501 E1463A Form C Switch - VXI P1 and P2 Conn Keysight E1463A 32-Channel Form C Switch Service Guide...
