- Page 1 Rev C USER MANUAL CAP2600 Camera headlamp adjustment system Universal Light and Heavy vehicle 1130, rue des Marels 34 000 MONTPELLIER France Tél : (33) 04-67-156-156 Fax : (33) 04-67-224-224 e-mail :contact@capelec.fr www.capelec.fr...
-
Page 3: Table Of Contents
2.1 Viewing touch screen ....................... 3 2.3 Main functions ........................4 2.4 Power supply ........................5 III Placing the CAP2600 ......................6 3.1 Vehicle preparation ......................6 3.2 Positioning in the length axis of the vehicle ..............7 3.3 Positioning the optical block in front of the headlamp..........8 IV. -
Page 4: Introduction
I. Introduction Thank you for having purchased the CAP2600 headlamp adjustment system. This system, which is fitted with camera technology developed by CAPELEC, is an autonomous control and adjustment system adapted to all types of headlamp. Please read this manual carefully before using the appliances in order to obtain the best results. Keep it in a safe place to be able to consult it if necessary. -
Page 5: Overview
II. Overview 2.1 Viewing touch screen Battery charge level WIFI Signal IT connection Access to the shared folder Turn off the machine For a more precise use it is recommended to use the stylus. 29/06/16 Rev C... -
Page 6: Main Functions
This mode displays the angle measured on the fog lamps so that the operator can proceed with an optimum angle adjustment. Configuration This menu gives access to several sub-menus used to configure the different CAP2600 functions, such as the printer mode, the date and time etc. 29/06/16... -
Page 7: Power Supply
2.4 Power supply The CAP2600 operates on lithium-iron batteries. It has a 10 hour autonomy in continuous operation. The charger supplied with the appliance has a battery load indicator: Remark on the charger: The connection point is the adapter block which must remain accessible. -
Page 8: Placing The Cap2600
III Placing the CAP2600 3.1 Vehicle preparation Firstly, check the tyre pressure. If the pressure is not correct, either inflate or deflate to the recommended pressure within the - 0 bar and + 0.3 bar limit. In all cases, the pressure must be balanced. -
Page 9: Positioning In The Length Axis Of The Vehicle
3.2 Positioning in the length axis of the vehicle 1 - Bring the CAP2600 in front of the centre of the vehicle, such that the lens of the adjustment system is located between 20 and 50 cm in front of each lamp for the measurement (the ideal distance being 35 cm);... -
Page 10: Positioning The Optical Block In Front Of The Headlamp
3.3 Positioning the optical block in front of the headlamp. Electronic positioning assistance will help you when positioning the optical block in front of the headlamps. It is automatically activated before each angle measurement for passing beams. The indications displayed on the screen indicate in which direction the box is to be moved. When the optimum position is reached "Ok"... - Page 11 WARNING: During this operation make sure that the front of the appliance is not exposed to a parasite external light source (sunlight, spotlight), this could cause incorrect positioning. Visual positioning: If you do not have the electronic assistance, manual positioning is carried out by placing the lens and the centre of the headlamp opposite each other.
-
Page 12: Control
During this step you will control the left and right side lamps of the vehicle. First you must position the CAP2600 in front of the headlamp to be controlled. (See chapter III). The example above corresponds to the measurement of the left dipped beam lamp. The measured vales displayed in red indicate a value that is outside the statutory limits. - Page 13 Step: Controlling high beam lamps During this step you will control the left and right side high beam lamps of the vehicle. First you must position the CAP2600 in front of the headlamp to be controlled. (See chapter III). Step 6: Test result In this step the appliance indicates the result of the test.
-
Page 14: Configuration
V. Configuration The configuration menu gives access to different sub-menus used to configure the appliance. Connection This menu has secure access and is used to select the method used to send the data, configure the IT link and printing. Company name This menu is used to record the name, address and other information about your company. -
Page 15: Maintenance Of The Appliance
Information sub-menu This menu gives access to the following data: Model of the appliance Software version Appliance serial number CPU card serial number Approval number Battery level Power of the WIFI signal Language sub-menu This menu is used to select the language used by the appliance. Maintenance sub-menu This menu has a secure access and is only for use by approved maintenance companies. -
Page 16: Technical Specifications
IX. Technical specifications Specifications: Weight: 25kg LxWxH: 590 x 670 x 1900 m 15 hours battery autonomy during continuous use Rapid 4 hour recharge with automatic stop Operating conditions: Batteries: Rechargeable Lithium Iron batteries Charger power supply: 15.2V 2.3A ... - Page 17 This symbol indicates that, in compliance with the WEEE directive (2002/96/EC) and with your local regulations, this product must not be disposed of with household waste. It must be deposited in a zone specific to this effect, for example an electric and electronic waste official collection centre (EEE), in order to be recycled, or at an approved product exchange...
