PRO03479
Rev 3
USER'S MANUAL
GAS ANALYZER
SMOKE-METER
EOBD
1130, rue des Marels
34 000 MONTPELLIER France
Tél : (33) 04-67-156-156
Fax : (33) 04-67-224-224
e-mail :contact@capelec.fr
www.capelec.fr

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EOBD and is the answer not in the manual?

Questions and answers

Related Manuals for Capelec EOBD

Summary of Contents for Capelec EOBD

  • Page 1 PRO03479 Rev 3 USER’S MANUAL GAS ANALYZER SMOKE-METER EOBD 1130, rue des Marels 34 000 MONTPELLIER France Tél : (33) 04-67-156-156 Fax : (33) 04-67-224-224 e-mail :contact@capelec.fr www.capelec.fr...
  • Page 3 CAUTION In order to avoid any trouble, please respect the following instructions before using the equipment:  Use the equipment according to this manual instructions  Do not use the equipment if the power cord or any of the accessories seem to be damaged or if the equipment seems not to work properly.

  • Page 4: Table Of Contents

    III.3. TECHNICAL FEATURES ....................41 III.4. INSTALLATION AND CAUTIONS ..................42 III.5. OPACITY TESTING PROCEDURE ..................43 III.6. OPACIMETER MESSAGES ....................49 EOBD MODULE .......................... 51 IV.1. Overview ........................51 IV.2. Principle ......................... 52 IV.3. Measure and control ..................... 52 CONFIGURATION ........................

  • Page 5: Station Overview

    STATION OVERVIEW I.1. OVERALL DIAGRAM The diagrams presented below allow to understand the menu hierarchy; the user can thus easily follow the various sub-parts architecture. I.1.1. Main menu: 23/04/2019 Rev 3...
  • Page 6 I.1.2. Configurations: I.1.3. Secured access: Strategical parts of the software are locked by password. Only maintenance have the access. 23/04/2019 Rev 3...

  • Page 7: Overview

    I.2. Overview I.2.1. The Station 23/04/2019 Rev 3...
  • Page 8 All the accessories supplied are exclusively dedicated to the CAPELEC equipment they have been designed for. Furthermore, they exclusively have to be used in Very Low Voltage situations. CAPELEC responsibility cannot be engaged in case of use of the equipment not complying with the instructions hereby.
  • Page 9 I.2.3. Gas Box FRONT FACE _1_ Identification plate _2_Settling tank filter (FD) _3_Measured gas outlet (GAS) _4_Condensate outlet (COND) _5_Intake of gas to be measured (GAS) _6_ surrounding air intake for zero setting _7_Intake of calibration gases (CAL) _8_Ventilator filter (FV) _9_Mains filter with fuse, 230V switch _10_Serial Port COM1 _11_gas pump protection filter (FG)
  • Page 10 I.2.4. Smoke-meter Exhaust probe 23/04/2019 Rev 3...
  • Page 11 I.2.5. Temperature module and tachometer CAP85XX: Tachometer on battery or Vibration For operation please refer to RPM tester manual. I.2.5.1. Technical features  Measurement characteristics  Automatic initialization  Measurement range: 400 - 9 990 rpm.  Maximum error: <20 rpm at speeds below 2000 rpm <2 % in other cases ...
  • Page 12 I.2.5.3. Connecting the tachometer Connected to the cigar lighter plug This is the simplest solution. It allows you measure the engine speed with no need to open the vehicle hood. On some vehicles, however, the engine speed measurement may be less accurate than with the unit connected directly to the battery, because of filters installed in the vehicle in order to avoid interferences coming from the engine.
  • Page 13 CAP4XXX: RPM via the EOBD Allows to measure the RPM from the vehicle embedded computer. 23/04/2019 Rev 3...
  • Page 14 I.2.6. Remote control This product is composed of:  1 remote control with IR emitter (« knob box »)  1 USB dongle with IR receiver (with led active on data activity) Navigator Function Equipement Keys Selection (1 from 4) Equipement Selection (1 from 4) Customisation area (by user)
  • Page 15 - press F1 to launch the selection page in gas analysis mode. - press F2 to launch the selection page in opacimeter mode. - press F3 to launch the selection page in EOBD scantool mode. 2 –browsing: Use the arrow keys to select the function desired. The active one is blue lighted.

  • Page 16: Installation, Commissioning

    I.3. Installation, Commissioning I.3.1. Advises The device can remain switched on 24/24. Nevertheless, it is recommended to cut the power supply during the night if the device is not used. When turning it on in the morning, getting operational again can take the gas module a few minutes. As for the smoke head, it will take a maximum of 9 minutes to reach the right operating temperature (preheating).
  • Page 17 I.3.3. Navigation, user’s interface The user’s interface has been designed for an optimal use of the touch screen. All the functions are very accessible with a simple touch. The touch function can also be replaced by the use of a remote control, giving access to the same functionalities.

  • Page 18: Preventive Maintenance, Cautions

    I.4. Preventive maintenance, cautions I.4.1. Overview Every single device is checked before being shipped by a skilled technician who will stick on it the primary check marks. The seals, preventing anybody from influencing the metrological results quality, cannot be removed excepted by an approved person. They guarantee the equipment conformity. Electric Risks Caution: in case of gas analyzer or opacimeter opening, be careful to electric risks of electrocution.

  • Page 19: Gas Analyzer

    II. GAS ANALYZER II.1. Principle The gas analyzer is a module dedicated to PTI and automotive workshops. It allows measurement of carbon monoxide (CO), carbon dioxide (CO ), hydrocarbons (HC) in hexane equivalent (C6H14), and oxygen (O ) concentration of the gases from spark-ignition vehicles (petrol, high-octane petrol, LPG), with or without catalytic converter.
  • Page 20 N° Descriptions IR detector Sample cell IR transmitter O rings Optical window Principle of NDIR measurement: The CAP3201 is based on non-dispersive infrared technology. Instead of using a refractory prism to achieve the very high spectral definition of infrared light (like those used in laboratory high performance equipment), the machine uses NDIR.
  • Page 21 II.1.1.Corrected CO Corrected CO is calculated as follows: )  15 then corrected CO = CO If (%CO + % CO If (%CO + % CO ) < 15 then corrected CO = CO x (15 II.1.2.Lambda The lambda value is calculated using the simplified BRETTSCHNEIDER equation as follow:. Where: [] = concentration in per cent volume, K1 = conversion factor for NDIR measurement to FID measurement,...
  • Page 22 CNG, LPG EFFECT (Only on special version) On special version, on the measure page you can select LPG, CNG or PETROL cars. The only effect is to change HC calculation:  LPG involves HC*0.5  CNG involves HC*0.3  PETROL involves HC*1. 23/04/2019 Rev 3...
  • Page 23 II.1.3.Gas flow circuit diagram 23/04/2019 Rev 3...

  • Page 24: Ii.2. Operating Conditions

    II.2. Operating conditions The gas analyzer is equipped with an automatic monitoring system of parameters that have an influence on measurements. If at least one of these parameters is out of bounds, and might have a metrological impact on results, then the gas analyzer automatically prevents any measurement from being performed until operating conditions are stabilized.

  • Page 25: Ii.3. Technical Features

     II.3. Technical features  Preheating duration: < 9 minutes at 0°C (1 minute minimum)  Response time: 13 seconds for HC, CO, CO2, 28 seconds for oxygen (transition from 20.9% to 0.1% for a gas with 0% O2)  Nominal pump delivery: 6 l/min.

  • Page 26: Ii.4. Emission Test

    Any maintenance operation, other than those described below, must be entrusted to a certified CAPELEC agent. On the other hand, failing to maintain the machine in conformity with these instructions may lead to the warranty abolition.
  • Page 27  Replace the activated charcoal filter. (FCC),  Check with a calibration gas that the error is less than the maximum allowed error. 1) Put into measuring mode. 2) Disconnect the sampling probe from the separator. 3) Connect the cylinder of calibration gas in its place. If the cylinder contains propane HC, select display of C6 HC, even though display is usually in C3 (hexane).
  • Page 28 II.4.2.5.Replacing a filter If one of the filters looks dirty or if an error message is referred in the user manual to a filter replacement, the following actions must be done: - Turn the machine off. - Remove the filter to be replaced (behind the location designated for each filter, the reference is silkscreen printed on the case).

  • Page 29: Ii.5. Gas Free Test

    II.5. Gas Free Test Select the F1 icon from the main menu for gas. This menu allows either to open a window for several gases to be checked, or to choose a submenu related to technical inspection and according to the vehicle 1 operating day.
  • Page 30 II.5.2.Description of graphic interface HC = Hydrocarbons expressed as hexane (display as propane is possible) given in ppm (parts per million). CO = Carbon monoxide expressed in % by volume. COcorr. = Corrected CO = Oxygen expressed in % by volume. = Carbon dioxide given in % by volume.
  • Page 31 F1 :The printer key: it is displayed only when printing is possible. Press this key to print the report. F2 :The storage key: Press this key to store values. These values will be printed out on the same test report. Up to 6 current values can be stored.
  • Page 32 II.5.3.Preliminary checks Before undertaking any measurement, the operator must verify that the engine is operating correctly. The following points are to be observed: The vehicle exhaust line must be gas-tight. The gearbox must be in neutral, with the clutch engaged, for vehicles with manual or semi- automatic transmissions;...
  • Page 33 II.5.4.RPM mode selected: Every time a gas check procedure is launched, the RPM value is displayed. RPM mode can be changed by pressing the rpm key  This mode will retrieve the RPM value from the vehicle embedded computer. « E.O.B.D »: ...
  • Page 34 II.5.5.Preparation to measurement - Tachometer Install the sensor, then press the operating speed key to determine the appropriate mode. This mode is automatically saved. The value of the operating speed must immediately appear. - Oil or engine temperature Replace the oil level measurement gauge with the oil temperature sensor. Adjust the probe length in order for it to soak into the oil when the sealing cone acts as a stopper.
  • Page 35 Automatic ON/OFF system check Warmup duration < 9 min Time remaining is displayed The pumps are running Calibration, auto-zero check No gas measurements for Auto-zero a certain time > Pumps active standby time Touche Touche Stand-by mode. Pumps resting, Elapsed time > 30 min. and no no measurements measurement in progress.
  • Page 36 Activating the pump has the effect of triggering automatic calibration. This phase is launched as soon as the pump is started. While this procedure is in progress, the message “auto-zero in progress” is displayed in the message box. When the message disappears, measurement operations become available on the screen. Automatic zeroing occurs every 30 minutes if the analyzer is in measurement mode.

  • Page 37: Ii.6. Messages

    II.6. Messages : Call Do it yourself Message displayed Maintenance Leak present Data invalid HC out of bounds CO out of bounds CO2 out of bounds O2 out of bounds NOx out of bounds Lowflow detected HC residue in gas inlet Error com.
  • Page 38 Check that the ambient air is not polluted and re-zero. Perform a further adjustment if the problem persists. II.6.4.CO out of bounds Out of range. Check that the ambient air is not polluted and re-zero. Perform a further adjustment if the problem persists. II.6.5.CO2 out of bounds Out of range.
  • Page 39 2) If the probe is disconnected, the message remains active: Check the flow with a flow meter. If the flow is between the minimum flow and the nominal flow, it is necessary for Maintenance to open the machine to check the pressure switch and if necessary calibrate it using a pressure sensor at a trigger pressure of 160 mbar, or even to replace it.
  • Page 40 II.6.12.Change O sensor During a zero operation, the system associates the oxygen concentration in air (20.9%) with the corresponding potential at the terminals of the oxygen sensor. This potential is usually in the range [6mV - 13mV]. If the potential is not in this range, the message “Change O2 sensor” appears.
  • Page 41 This is shown on screen by a “----“ display. If the ambient temperature is below 0°C or if a measurement is in progress, this means that the measured value is outside the range 0-150°C. If not, check that the oil temperature probe is correctly connected to the connector assigned to it. If not, replace the sampling probe.

  • Page 42: Smoke-Meter

    III. SMOKE-METER III.1. OPERATING PRINCIPLE In the composition of the exhaust gas emitted by diesel engines, the pollutant component is considered to be carbon in suspension. A polluting vehicle emits on acceleration a puff of gas that is darker (and thus more opaque) than a vehicle in good conditions. The partial flow opacimeter is used to give a measure of this phenomenon based on a given measure unit called K (m The principle of opacity measurement is the following: a beam of light (transmitter aimed at a receiver, with a constant distance between the two) is passed through a sample of gas.

  • Page 43: Iii.2. Operating Conditions

    measurement. All this information is directly taken into account by the central unit which is responsible for detecting maximum opacity, displaying the results on a LCD screen, printing to a thermal printer or an external A4 format printer and guiding the operator throughout the procedure.

  • Page 44: Iii.3. Technical Features

    III.3. TECHNICAL FEATURES  Power supply 115-230V / 1.5A; 47Hz à 63Hz.  Preheating duration: from 3 to 6 min depending on ambient temperature.  Zero adjustment and calibration before use: automatic.  Control of adjustment: automatic by electrical filter at around 50%. ...

  • Page 45: Iii.4. Installation And Cautions

    III.4. INSTALLATION AND CAUTIONS III.4.1.Installation, commissioning: Place the cell in the place desired. The surface has to be horizontal and not too much exposed to vibrations, dirt and cold temperature.  Check that the opacity cell is correctly connected to the station and connect it to the 230 VAC 50 Hz mains.

  • Page 46: Iii.5. Opacity Testing Procedure

    III.5. OPACITY TESTING PROCEDURE This procedure allows to determine, for a given vehicle, of whether or not its opacity is lower than the current limit. Opacity check for official test procedure Smoke free Test for to determine the opacity of the vehicle III.5.1.Client data entry From the moment the test procedure is launched, the user may, if he wants, enter information about the client and his car (name, vehicle brand, mileage and ID plate number).
  • Page 47 III.5.2.Description of the graphic interface: This graphic interface is composed of several elements:  The tachometer: The tachometer reading may run from 0 to 9999 rpm. In addition, a graphic drawing allows the trend in engine operating speed to be quickly visualized. Only one of the sensors allowing the engine speed to be catched is needed for reading the rotation speed.
  • Page 48 sensor type used at the input.  The “print” key: This key allows the results to be printed or transferred to a central computer in a technical testing centre for example. III.5.3.Displays the selected operating speed mode: Each time the opacity program is launched, the operator knows the operating speed mode that is selected, RPM mode can be changed by pressing the rpm key ...
  • Page 49 III.5.4.Detecting the cell At the beginning of the test, the cell presence is checked. After a few seconds, the cell is detected. If not, the following message is displayed: COMMUNICATION PROBLEM CHECK CONNEXION In this case, check whether the cell is properly connected. III.5.5.Auto-zero and error checking Following the phase which consists in preparing the vehicle for measurement and ensuring that it is operating correctly, the opacimeter needs to perform an auto-zero.
  • Page 50 ZERO IN PROGRESS The auto-zero operation is a procedure which, taking ambient air as a reference, establishes the signal levels for zero opacity. It is therefore important not to put the measurement probe into the exhaust pipe until required by the software. III.5.6.Probe and sensors Insertion Once the auto-zero operation is carried out, the following messages appear on the screen: INSERT THE PROBE INTO...
  • Page 51 III.5.6.2.The oil temperature sensor or engine temperature: Select, according to the mode chosen:  With the 85XX mode or « WIRED » mode, it is necessary to insert the probe into the gauge. Do not insert it too deep. Adjust the probe length in order for it to soak into the oil when the sealing cone acts as a stopper.

  • Page 52: Iii.6. Opacimeter Messages

    III.6. OPACIMETER MESSAGES III.6.1.Error messages III.6.1.1.« Mains voltage out of bounds » The cell power supply should be between 195 and 253 VAC. Beyond that, the cell cannot operate correctly. Have the mains power checked. III.6.1.2.« Windows dirty » You must turn the equipment off and proceed a cell lens cleaning as described in the maintenance chapter of this manual.
  • Page 53 III.6.1.9.« Measurement invalid » The opacity curve contains several peaks, making it impossible to determine opacity. Use more vigorous foot pressure on the accelerator III.6.2.User guidance messages III.6.2.1.« Zero in progress» This message should disappear after a few seconds at the end of the auto-zero operation. Maximum duration should be 4 seconds.

  • Page 54: Eobd Module

    IV. EOBD MODULE IV.1. Overview The Scantool is a tool allowing access to the internal data of on-board systems. It connects to the OBDII auto diagnostic plug (SAE J1962 standard) of the vehicle and scans the information stored in memory or current data made available and accessible by one of the 5 standardized protocols.

  • Page 55: Iv.2. Principle

    Everything appears to show that they are equipped with OBD. IV.3.2.CAP4XXX First connect the device to the vehicle EOBD connector. The device red led will light on. It will start blinking when the communication with the embedded computer is established.
  • Page 56 Oxygen sensor data (from lambda sensors),  Test procedures,  Reset procedure (erases memorized breakdowns and turns the board leds off),  Information about vehicle (serial number, model, ...) Choose “DIAGNOSIS » from the EOBD main menu to view these data. 23/04/2019 Rev 3...

  • Page 57: Configuration

    V. CONFIGURATION V.1. Clock/date: Allows to change hour and date in the system. The field must be selected using the OK key; to change the value, press the UP and DOWN arrows. Finally, to save the new values, press OK. Exit with the ESC key.

  • Page 58: Operator

    V.3. Operator: Up to 9 operator names can be stored on that page. The principle is identical to the entry of the garage header and client entry. In the main menu, to select the current operator name, just click the name area. This name will appear on the printed report at the end of test.
  • Page 59 V.4.1.Time settings : The stand-by allows to stop pumps after a test. This time can be set between 7 and 30 minutes. The temporisation time allows adding additional time before starting a gas or smoke test. V.4.2.Digits CO: The DIGIT CO submenu allows selection of the number of figures after the decimal that you want to have when CO is displayed V.4.3.O2 sensor status: This window provides information on the oxygen sensor status.
  • Page 60 necessary to keep the inlet hermetically shut. This phase lasts at most 11 seconds. At the end of this phase, a diagnosis of “Leak present” or “Leak absent” is given. Push “OK” key to exit. The presence of a leak disables measurement until a new test is carried out with a final result of “Leak absent”.
  • Page 61 V.4.6.Secured access Enter the 5-digit secret code. Then push on OK. The machine requires the entry of the operator’s name “Carried out by:” This information will be stored in memory and is not erasable. This part of the program is dedicated to persons I charge of the equipment itself periodic inspection.
  • Page 62 a) CO, HC, CO2 adjustment procedure:  Adjusting calibration gas concentrations: HC must be entered in propane equivalent. Remember that the cylinder containing the gas required for analyser adjustment contains the following concentrations: CO: 2,00 % vol. : 13,0 % vol. HC: 1600 ppm vol.
  • Page 63 23/04/2019 Rev 3...

  • Page 64: Smoke-Meter

    V.5. Smoke-meter: This menu is composed of 3 sub-menus detailed hereafter: V.5.1.Routine Check: The « routine check » sub-menu allows the operator to control the smoke-meter is working properly, by accessing the various cell parameters: This window provides useful information. Information about the cell status : Current status Information about version...
  • Page 65 A window will appear showing the result. If this last shows “smoke-meter not conform”, clean the cell and launch the test again. V.5.2.Secured access : This menu is exclusively accessible by the manufacturer, CAPELEC, as it gives access to secured parameters. 23/04/2019...

  • Page 66: Centralization

    V.6. Centralization: This menu allows to manage centre communication network. V.7. Printing: This menu consists of 2 sub-menus:  « number of tickets » : allows to print 1, 2 or 3 reports once the test is finished  « Printer » : for the operator to choose to printer to be used. V.8.

  • Page 67: Parameters By Default

    V.9. OPTION: This sub-menu is dedicated to persons in charge of installing new functions. It is secured by a 5- digit code. Select the configuration menu in order to install a new feature. This windows shows all the functions and options already installed. V.10.Parameters by default : WARNING: This window has to be used with caution because it allows resetting all the configuration values.

  • Page 68: Information

    V.13.Information : This window includes the manufacturer and maintenance company details, as well as information about software version. For more information on our products, visit our Internet site: www.capelec.fr. 23/04/2019 Rev 3...
  • Page 69 This symbol indicates that, in accordance with directive DEEE (2002/96/CE) and with the regulation of your country, this product should not be thrown with the household refuse. You must deposit it in a place of collecting envisaged to this end, for example, an official site of collection of the electric components and electronics (EEE) for their recycling or a terminal point of products authorized which is accessible when you acquire of a new product of the same...

Table of Contents
