Pottery Barn Seville Series Mounting Instructions

Medicine cabinet lrg esp

Download this manual

• This hanging system is meant for drywall/stud mounting only.

• If walls are concrete, brick or plaster, please consult your local hardware store for assistance.

• For safety, installation by two people is recommended.

Tool Required (Not Included):

Stud Finder Phillips Screwdriver

Parts Included:

Wooden Cabinet (1pc) - A

Hardware Included

Shelf pin (8pcs) -a

Rubber Pad (2PC) - e

Pre-Assembly:

•

Remove all parts and hardware from the box and lay out on a clear workspace, along with any plastic protective

packaging. Do not dispose of any contents until assembly is complete to avoid accidentally discarding small parts or

hardware.

•

Use the parts and hardware lists above to identify and separate each of the pieces included.

•

The illustrations provided allow for easier assembly when used in conjunction with the assembly instructions.

Seville Medicine Cabinet Lrg Esp

Glass Shelf (2pcs) –B

Toggle (2pcs) – b

Toggle Screw (2pcs) -c

Pencil

Wall rail (1pc) -C

Page 1 of 3

Wood Screw (1pc) -d

Page 1 Seville Medicine Cabinet Lrg Esp • This hanging system is meant for drywall/stud mounting only. • If walls are concrete, brick or plaster, please consult your local hardware store for assistance. • For safety, installation by two people is recommended. Tool Required (Not Included): Stud Finder Phillips Screwdriver Pencil...
Page 2 Seville Medicine Cabinet Lrg Esp MOUNT WALL RAIL TO THE WALL 1. Find wall studs and determine the desired placement on the wall for the product. Position the wall rail (C) on the wall and adjust so that the rail is level. It is better to mount the wall rail to at least (1) stud. Then, use a felt-tipped pen to mark the wall through the three pre-drilled holes of the rail to indicate the locations of the drywall toggles.
Page 3 Seville Medicine Cabinet Lrg Esp Figure 2 To install shelves: Insert the Shelf pins (a) into the pre-drilled holes on the interior side of the cabinet at desired level. Gently place Glass shelf(B) onto Shelf pins. Optional: Attach the rubber pad (e) into the magnet in the cabinet. See Figure 3. Figure 3 Care Instructions: Wipe cabinet with a soft, dry cloth.
