TOOLS AND PARTS

IMPORTANT:
Installer: Leave Installation Instructions with the
homeowner.
Homeowner: Keep Installation Instructions for future
reference. Save these Installation Instructions for the
local electrical inspector's use.
TOOLS NEEDED:
Gather the required tools and parts before starting
installation.
Read and follow the instructions provided with any tools
listed here.
Cordless drill
Drill bits
Adjustable wrenches (2)
Phillips screwdriver
Small level
3/32" hex key
(panel kits only)
11/32" nut driver
PARTS NEEDED:
#8 x 3" (7.6 cm) wood screws (longer screws may be
needed) (6)
2" x 4" x 32" (5 cm x 10 cm x 81 cm) wood boards (2)
Custom wood overlay panels—consult a qualified
cabinetmaker or carpenter to make the custom wood
panels.
See "Custom Wood Overlay Panels" for more
information.
OR
Panel kit—See "Variants and Accessories" for panel kit
information.
Flexible, codes-approved water supply tubing, a
ferrule, a union and a 1/4" (6.35 mm) compression
fitting.
Slotted Hex-head Screw
W10141645 (21)
Hex-head Blunt Screw
W10142233 (4)
6

INSTALLATION REQUIREMENTS

3/8" and 1/2" open-end
wrenches
5/32" and 3/16" hex key
1/4" and 5/16" socket
drivers
Tape measure
Utility knife
Tape (painters)
Appliance dolly
Hex-head Pointed Screw
W10141189 (8)
Shoulder Washer (use with
hex-head pointed screw)
W10471946 (4)
Phillips-head Flat Screw
8281252 (28)
Door Adjustment Pin
(preinstalled)
W10234194 (2)
Drawer Panel Bracket
W10606815 (2)
Fully Integrated Grille
Bracket
W10260890—Left (1)
W10260891—Right (1)
Panel Top Bracket
W10667450 (2)
Round-head Screw
1163283 (24)
Door Stop Pin
W10234202 (2)
Standard Integrated Grille
Bracket
W10182743—Left (1)
W10182741—Right (1)
Filler Board "L" Bracket
W10234199 (2)
Top Grille Lower Trim
W10634858—36" BM (1)
W10606812—42" BM, SxS (1)
