OPTION 1—OPEN TO CEILING
6" (15.24 cm)
OPTION 2—FALSE FRONT (CABINET FACE ONLY)
6" (15.24 cm)
min.
12
PERMISSIBLE INSTALLATION OPTIONS
min.
84"
(213.4 cm)
84"
(213.4 cm)
OPTION 3—CLOSED SOFFIT
1/8" (3.2 mm) gap
1/8" (3.2 mm) gap
STAINLESS STEEL PANEL KIT
INSTALLATION REQUIREMENTS
Refer instructions received with full height door panel kit.
CUSTOM WOOD PANEL DIMENSIONS
AND INSTALLATION REQUIREMENTS
Refer instructions received with Armoire kit.
1/8" (3.2 mm) gap
84"
(213.4 cm)
