- Page 1 QK-CE220BATRLE CONTROL BOARD FOR 1/2 230V ac SINGLE-PHASE MOTORS 230V 230V 433,92 MHz 433,92 MHz PLUG & PLUG & PLAY PLAY V03/2011...
-
Page 2: Table Of Contents
CONTENTS INTRODUCTION MAIN FEATURES OF THE CONTROL BOARD TECHNICAL DATA INSTALLATION LAYOUT AND CONNECTIONS OTHER SETTINGS RADIORECEIVER SETUP SETUP FINAL TESTING TROUBLESHOOTING DECLARATION OF COMPLIANCE ® QUIKO GUARANTEE: GENERAL CONDITIONS... -
Page 3: Introduction
INTRODUCTION This manual is enclosed with control unit QK-CE220BATRLE and may not be used for different products. Moreover it has been especially written for use by qualified fitters. Important note: disconnect the panel before operating on the control unit. QK-CE220BATRLE control unit has been designed to control electromechanical gear motors such as swing gates. -
Page 4: Layout And Connections
LAYOUT AND CONNECTIONS DIP SWITCHES for SETUP JP1 Jumper for SETUP RADIO PROG. button for transmitters programming BREAK TRIMMER for Break/pause time setting POWER TRIMMER for Power / force setting OPEN/CLOSE SWITCH KEY SELECTOR COMMON COMMON 230V 50/60Hz CLOSE CLOSE OPEN OPEN STO P... -
Page 5: Other Settings
27+(5 6(77,1*6 &KHFN WKDW -3 MXPSHU LV RSHQ &RQGRPLQLXP PRGH 1XGJH VWDUW IRU 3DXVH UHJXODWLRQ $XWRPDWLF RSHQLQJ ZLWK GRHVQ W DFFHSW 67$57 )RUFH UHJXODWLRQ $XWRP DWLF FORVLQJ WKH HOHFWULFDO ORFN RQO\ Z LWK ',3 LQ 67$57 FRPPDQG FRPPDQG GXULQJ GXULQJ FORVLQJ UHOHDVH SDXVH DQG RSHQLQJ 5HJXODWH WKH %5($. -
Page 6: Setup
DIP3 to OFF = pre flashing enabled DIP3 to ON = pre flashing disabled... -
Page 7: Final Testing
FINAL TESTING Once all connections have been done and the gate is closed, check that LEDs status is as follows: LED STATUS TABLE TROUBLESHOOTING Problem Solution F1 or F2A fuses are fired or not properly inserted. Please check The LD0 led isn't switched ON so the control board isn't supplied with electricity 230Vac (connectors 23 and 24) aren't connected. -
Page 8: Declaration Of Compliance
Via Seccalegno,19 36040 Sossano (VI) Italia declares under his own responsibility that the product: Control board QK-CE220BATRLE complies with the main safety requirements issued by the following directives: Radio Sets - 1999/05/EC; Low Voltage - 2006/95/EC; Electromagnetic Compatibility - 2004/108/EC and any revisions thereof, and complies with the provisions that implement said directives in the National Legislation of the Country of destination where the products are to be used. -
Page 9: Quiko ® Guarantee: General Conditions
This guarantee covers the repair with free replacement (ex-works Quiko Italy: packing and transport at the customer’s expense) of parts that Quiko Italy recognises as being faulty with regard to workmanship or material. - Page 12 Quiko Italy Via Seccalegno, 19 36040 Sossano (VI) - Italy Tel. +39 0444 785513 Fax +39 0444 782371 info@quiko.biz www.quikoitaly.com The Manufacturer can technically improve the quality of its products without any prior notice.
